Siemens 6ES7 241-1CH32-0XB0 RS422/485 Serial Communication – SIMATIC S7-1200 CM 1241
When a production line loses serial communication between its PLC and field devices — variable frequency drives, barcode scanners, weighing terminals, or legacy SCADA systems — the entire operation grinds to a halt. Unplanned downtime in industrial environments costs thousands of dollars per hour, and the root cause is often a failed or missing communication module. The Siemens 6ES7 241-1CH32-0XB0, the CM 1241 RS422/485 Communication Module, is the purpose-built solution that keeps these critical data links alive and reliable.
Within the SIMATIC S7-1200 ecosystem, the CM 1241 (6ES7 241-1CH32-0XB0) occupies a unique position as the dedicated serial communication expansion for RS422 and RS485 protocols — the two most widely deployed serial standards in global industrial automation. While newer fieldbus and Ethernet-based protocols dominate greenfield installations, an enormous installed base of RS485 devices remains in operation worldwide across manufacturing, energy, water treatment, and building automation. This module is the bridge that connects modern S7-1200 controllers to that legacy infrastructure, making it indispensable for both new projects and system upgrades.
Technical Specifications
- Order Number (SKU): 6ES7 241-1CH32-0XB0
- Module Type: CM 1241 — Communication Module for RS422 / RS485
- Compatible PLC: SIMATIC S7-1200 (CPU 1211C, 1212C, 1214C, 1215C, 1217C)
- Interface: RS422 (4-wire, full duplex) / RS485 (2-wire, half duplex)
- Connector Type: 9-pin Sub-D female
- Baud Rate: 300 bps to 115.2 kbps
- Data Bits: 7 or 8
- Parity: None, Even, Odd, Mark, Space
- Stop Bits: 1 or 2
- Flow Control: XON/XOFF, RTS/CTS, None
- Protocols Supported: Freeport (ASCII), Modbus RTU Master/Slave, USS Drive Protocol
- Supply Voltage: 5 VDC (via S7-1200 backplane bus)
- Power Consumption: Max. 1.5 W
- Isolation: Electrically isolated from backplane bus
- Operating Temperature: 0 °C to +60 °C (horizontal mounting); 0 °C to +50 °C (vertical mounting)
- Storage Temperature: -40 °C to +70 °C
- Degree of Protection: IP20
- Dimensions (W × H × D): 30 mm × 100 mm × 75 mm
- Weight: Approx. 120 g
- Certifications: CE, UL, cULus, ATEX Zone 2, FM Class I Div 2
Key Features & Benefits
- Dual Protocol Support: Supports both RS422 and RS485 in a single module, reducing spare-parts inventory and simplifying system design.
- Modbus RTU Native: Built-in Modbus RTU Master and Slave capability via STEP 7 instruction library — no third-party middleware required.
- USS Protocol Ready: Directly controls Siemens SINAMICS and MICROMASTER drives via USS protocol, enabling seamless drive integration without additional gateways.
- Freeport / ASCII Mode: Full ASCII communication for custom protocols, barcode readers, printers, and weighing systems.
- Electrical Isolation: Galvanic isolation protects the CPU from ground loops and electrical noise common in industrial environments.
- Hot-Swap Capable: Module can be replaced without powering down the entire S7-1200 system (with appropriate system configuration).
- Compact Form Factor: 30 mm wide — fits directly on the left side of any S7-1200 CPU without additional mounting hardware.
- TIA Portal Integration: Fully configured within SIMATIC STEP 7 (TIA Portal V13 SP1 and above) with drag-and-drop hardware configuration.
Industry & Equipment Applications
- Manufacturing & Assembly: Serial communication with barcode scanners, label printers, and vision systems on production lines.
- Energy & Power: Modbus RTU communication with power meters, energy analyzers, and protection relays.
- Water & Wastewater Treatment: Integration with flow meters, level transmitters, and dosing pump controllers via RS485 bus.
- HVAC & Building Automation: Control of variable air volume (VAV) controllers, chillers, and BMS gateways using Modbus RTU.
- Drive Control: USS protocol communication with SINAMICS G120, G110, V20, and MICROMASTER 440 frequency inverters.
- Oil & Gas: Remote terminal unit (RTU) communication in SCADA systems over RS422 long-distance links.
- Food & Beverage: Hygienic process control with serial-connected weighing and filling equipment.
System Integration & Compatible Parts
The 6ES7 241-1CH32-0XB0 is designed to work within the complete SIMATIC S7-1200 system architecture. Compatible and commonly paired components include:
- S7-1200 CPUs: 6ES7 211-1AE40-0XB0 (CPU 1211C), 6ES7 214-1AG40-0XB0 (CPU 1214C), 6ES7 215-1AG40-0XB0 (CPU 1215C)
- Signal Modules: 6ES7 221-1BF32-0XB0 (SM 1221 DI 8×24VDC), 6ES7 222-1BF32-0XB0 (SM 1222 DQ 8×Relay)
- Power Supply: 6EP1 332-1SH71 (SITOP PSU100S 24VDC/5A)
- SINAMICS Drives (USS): 6SL3210-5BE21-5UV0 (SINAMICS G120C), 6SL3211-0AB21-5UA1 (SINAMICS V20)
- HMI Panels: 6AV2 123-2DB03-0AX0 (KTP400 Basic), 6AV2 124-0GC01-0AX0 (KTP700 Basic)
- Programming Software: SIMATIC STEP 7 Professional V15.1 or higher (TIA Portal)
Our Quality Assurance Process
At Konmask.com, every Siemens module we supply undergoes a rigorous verification process before shipment:
- Authenticity Verification: All units are sourced from authorized distribution channels. We verify Siemens product identification codes, holographic labels, and factory packaging integrity.
- Visual & Physical Inspection: Each module is inspected for connector condition, housing integrity, and label accuracy against the official Siemens product datasheet.
- Documentation Package: Shipments include the original Siemens product documentation, CE declaration of conformity, and our inspection report upon request.
- Secure Packaging: Anti-static packaging with shock-absorbing foam inserts protects modules during international transit.
- Traceability: Batch and serial number records are maintained for full supply chain traceability.
How to Order
- Submit your inquiry via the Contact / RFQ form on this page with your required quantity and delivery timeline.
- Our technical sales team will respond within 1 business day with availability, lead time, and a formal quotation.
- Upon order confirmation, we issue a Proforma Invoice and arrange payment via T/T bank transfer or other agreed terms.
- Goods are dispatched with full shipping documentation (commercial invoice, packing list, certificate of origin) suitable for customs clearance.
- Tracking information is provided upon shipment. Typical delivery: 5–10 business days for international express (DHL / FedEx / UPS).
Why Choose Konmask.com?
- ✅ Specialized in Industrial Automation: We focus exclusively on PLC, DCS, HMI, and drive components — not a generalist marketplace.
- ✅ Global B2B Supply: Serving engineering firms, system integrators, and MRO procurement teams across 50+ countries.
- ✅ Technical Pre-Sales Support: Our team includes qualified automation engineers who can advise on compatibility and system design.
- ✅ Competitive Lead Times: Extensive supplier network enables fast sourcing of both standard and discontinued Siemens parts.
- ✅ Transparent Documentation: Full shipping and customs documentation provided as standard.
- ✅ Inquiry-First Model: No pressure purchasing — get your quote, verify specs, then decide.
Frequently Asked Questions
Q: What is the difference between 6ES7 241-1CH32-0XB0 and 6ES7 241-1AH32-0XB0?
A: The 6ES7 241-1CH32-0XB0 (CM 1241) supports RS422/RS485, while the 6ES7 241-1AH32-0XB0 supports RS232. Choose based on your field device interface requirements.
Q: How many CM 1241 modules can be connected to one S7-1200 CPU?
A: Up to 3 communication modules (CM or CB) can be connected to the left side of any S7-1200 CPU.
Q: Does this module support Modbus TCP?
A: No. The 6ES7 241-1CH32-0XB0 supports Modbus RTU (serial) only. For Modbus TCP, use the CPU’s built-in PROFINET port with the Modbus TCP instruction library.
Q: Which TIA Portal version is required for configuration?
A: TIA Portal V13 SP1 or higher is required. Siemens recommends TIA Portal V15.1 or V17 for full feature support.
Q: Can this module communicate with third-party Modbus RTU slave devices?
A: Yes. The CM 1241 in Modbus RTU Master mode can communicate with any standard Modbus RTU slave device regardless of manufacturer.
Q: Is the 6ES7 241-1CH32-0XB0 still in production?
A: Please contact us for current availability and lifecycle status. Konmask.com maintains supply of both current-production and legacy Siemens modules.
