SIEMENS 6ES7132-4BD01-0AA0 Digital Output Module | Replacement, Equivalent & Selection Guide
The SIEMENS 6ES7132-4BD01-0AA0 is a 4-channel digital output module designed for the ET 200S distributed I/O system, operating at 24 VDC with a 0.5 A per-channel output current. This page provides full technical specifications, compatible replacement options, application guidance, and a structured selection guide to help engineers and procurement teams make confident sourcing decisions.
Technical Specifications
- Part Number: 6ES7132-4BD01-0AA0
- Series: SIMATIC ET 200S
- Module Type: Digital Output (DO)
- Number of Outputs: 4 channels
- Output Voltage: 24 VDC
- Output Current: 0.5 A per channel
- Output Type: Transistor (sourcing)
- Supply Voltage: 24 VDC (via power module)
- Isolation: Electrically isolated from backplane bus
- Dimensions (W×H×D): 15 × 81 × 52 mm
- Weight: Approx. 50 g
- Operating Temperature: 0 °C to +60 °C
- Storage Temperature: −40 °C to +70 °C
- Protection Class: IP20
- Certifications: CE, UL, cULus, ATEX (Zone 2)
- Mounting: Plug-in onto ET 200S terminal module (e.g., 6ES7193-4CA30-0AA0)
Compatible Replacement & Equivalent Models
The following models are functionally equivalent or drop-in replacements for the 6ES7132-4BD01-0AA0. Always verify electrical ratings and firmware compatibility before substitution.
- 6ES7132-4BD02-0AA0 – Successor revision; identical pinout and function, updated firmware support
- 6ES7132-4BD30-0AA0 – High-feature variant with diagnostics; same channel count and voltage
- 6ES7132-4BF00-0AA0 – 8-channel DO version for higher density applications
- 6ES7132-4HB01-0AB0 – High-speed DO variant for time-critical outputs
- Third-party equivalents: Weidmüller, Phoenix Contact, and Beckhoff offer ET 200S-compatible DO modules — consult datasheet for terminal module compatibility
Note: Replacement modules must be paired with a compatible ET 200S terminal module. Contact support@konmask.com for cross-reference verification.
Why Choose the Original Model
- Proven reliability in harsh industrial environments with millions of installed units globally
- Full SIMATIC ecosystem integration — seamless configuration via STEP 7 and TIA Portal
- Compact 15 mm width maximizes cabinet density in ET 200S installations
- Transistor output provides fast switching and long service life vs. relay alternatives
- ATEX Zone 2 certification enables use in potentially explosive atmospheres
- Genuine SIEMENS warranty and long-term spare parts availability
Typical Applications
- Controlling solenoid valves, contactors, and indicator lamps in process automation
- Machine tool and packaging line I/O expansion via PROFIBUS/PROFINET
- Conveyor and material handling systems requiring distributed I/O
- Building automation and HVAC control panels
- Oil & gas field junction boxes (ATEX-rated installations)
- Automotive assembly line control cabinets
System Compatibility
- Interface Module: IM 151-1 Standard / IM 151-1 FO / IM 151-3 PN
- Terminal Module: TM-E15S24-01 (6ES7193-4CA30-0AA0) or equivalent
- Communication: PROFIBUS DP / PROFINET IO
- PLC Controllers: SIMATIC S7-300, S7-400, S7-1500 (via IM)
- Engineering Software: SIMATIC STEP 7 V5.x, TIA Portal V13 and above
- Power Module: PM-E 24VDC (6ES7138-4CA01-0AA0) required for output supply
Selection Guide
Use the criteria below to confirm the 6ES7132-4BD01-0AA0 is the right module for your application, or to identify a more suitable alternative:
- Output channels needed: 4 → this model | 8 → 6ES7132-4BF00-0AA0
- Output current per channel: ≤0.5 A → this model | ≤2 A → 6ES7132-4BD30-0AA0 HF
- Diagnostics required: No → 4BD01 (standard) | Yes → 4BD30 (high-feature)
- Hazardous area (ATEX Zone 2): Yes → this model is certified
- High-speed switching (<1 ms): Consider 6ES7132-4HB01-0AB0
- Budget-sensitive retrofit: Contact us for certified pre-owned or compatible third-party options
Quality Assurance & Sourcing
- All units sourced from authorized distributors or verified industrial surplus channels
- Each module undergoes visual inspection and functional verification prior to shipment
- Original SIEMENS packaging and labeling preserved where available
- Traceability documentation (batch/lot records) available on request
- Counterfeit-risk screening applied to all non-factory-sealed stock
- 30-day return policy for DOA (Dead on Arrival) units
How to Order
- Part Number: 6ES7132-4BD01-0AA0
- Quantity: Available individually or in packs of 5
- Lead Time: In-stock items ship within 1–3 business days; contact us for bulk orders
- Payment: T/T, PayPal, credit card, and trade terms available for qualified buyers
- Shipping: DHL / FedEx / UPS express worldwide; sea freight for large orders
- Request a Quote: support@konmask.com | +0086 19859288691
Replacement & Compatibility FAQ
Q: Can I replace 6ES7132-4BD01-0AA0 with 6ES7132-4BD02-0AA0 directly?
A: Yes. The -4BD02- is the direct successor with the same terminal module, pinout, and function. No hardware changes required; update GSD/GSDML file if needed.
Q: Does this module work with S7-1200 or S7-1500?
A: The ET 200S system connects to S7-1500 via a PROFINET interface module (IM 151-3 PN). Direct backplane connection to S7-1200 is not supported.
Q: What terminal module is required?
A: The TM-E15S24-01 (6ES7193-4CA30-0AA0) is the standard terminal module. Ensure it is ordered separately if not already installed.
Q: Is the module suitable for AC loads?
A: No. The 6ES7132-4BD01-0AA0 is a DC transistor output module (24 VDC only). For AC loads, select a relay output variant.
Q: Can I use third-party replacement modules?
A: Third-party ET 200S-compatible DO modules exist but require careful verification of terminal module compatibility and GSD file support. Contact us for a validated cross-reference list.
