Siemens 6ES7134-4GB10-0AB0 – 2AI Standard Analog Input Module | ET 200S Platform
Engineering Background: The 6ES7134-4GB10-0AB0 is a 2-channel standard analog input module designed for the Siemens SIMATIC ET 200S distributed I/O system. It operates within the PROFIBUS DP and PROFINET architectures, enabling precise analog signal acquisition at the field level without burdening the central PLC rack. Engineered for industrial environments where signal integrity and modularity are non-negotiable, this module is a cornerstone component in process automation, machine control, and distributed sensing applications.
Product Positioning: Targeted at procurement engineers and system integrators sourcing verified Siemens SIMATIC components, this module delivers OEM-grade performance with the flexibility of distributed I/O. It is fully compatible with the ET 200S terminal module ecosystem and integrates seamlessly into existing TIA Portal and STEP 7 engineering environments.
Complete Technical Specifications
- Order Number (SKU): 6ES7134-4GB10-0AB0
- Product Family: SIMATIC ET 200S
- Module Type: 2AI Standard Analog Input
- Number of Channels: 2 (differential)
- Input Signal Types: Voltage ±10 V, ±5 V, ±2.5 V; Current 0–20 mA, 4–20 mA
- Resolution: 13-bit + sign (14-bit total)
- Conversion Time per Channel: 2.5 ms (50 Hz suppression) / 1.7 ms (60 Hz suppression)
- Supply Voltage: 24 V DC (via backplane bus)
- Current Consumption (Bus): Max. 60 mA
- Isolation: Electrically isolated between channels and backplane
- Permissible Input Voltage (Destruction Limit): ±35 V (voltage mode)
- Dimensions (W × H × D): 15 mm × 81 mm × 52 mm
- Weight: Approx. 80 g
- Operating Temperature: 0 °C to +60 °C
- Storage Temperature: −40 °C to +70 °C
- Degree of Protection: IP20
- Certifications: CE, UL, cULus, ATEX (Zone 2)
- Compatible Terminal Module: 6ES7193-4CA30-0AA0 (TM-E15S24-01)
- Compatible Interface Module: IM 151-1 / IM 151-3 PN
- Engineering Software: STEP 7 V5.x, TIA Portal V13 and above
Proven Application Environments
- Process Automation: Temperature, pressure, and flow measurement via 4–20 mA transmitters in chemical, oil & gas, and water treatment plants
- Machine Tool Control: Analog position feedback and spindle load monitoring in CNC machining centers
- Conveyor & Material Handling: Load cell and tension sensor integration in packaging and logistics systems
- Building Automation: HVAC sensor acquisition (CO₂, humidity, temperature) in distributed BMS architectures
- Automotive Assembly: Torque and force monitoring in robotic welding and press stations
- Energy Management: Power quality monitoring and analog metering in substation automation
Engineering Advantages
- Ultra-Compact Footprint: 15 mm slot width maximizes rack density in space-constrained control cabinets
- Galvanic Isolation: Channel-to-bus isolation eliminates ground loop interference in multi-sensor installations
- Flexible Signal Range: Software-configurable input ranges eliminate the need for external signal conditioners
- Diagnostic Capability: Wire-break and overflow detection with PROFIBUS/PROFINET diagnostic messaging
- Hot-Swap Ready: Module replacement without powering down the ET 200S station (with appropriate IM)
- TIA Portal Native: Full hardware catalog support with automatic parameter download and online diagnostics
System Architecture & Signal Flow
The 6ES7134-4GB10-0AB0 mounts onto a dedicated terminal module (TM-E15S24-01, order no. 6ES7193-4CA30-0AA0) which provides the field wiring terminals and backplane bus connection. Analog signals from field sensors are routed through the terminal module’s screw terminals, converted by the module’s 13-bit ADC, and transmitted as process values over the ET 200S internal bus to the interface module (IM 151-x). The IM then forwards the data to the PROFIBUS DP master or PROFINET IO controller (e.g., S7-300/400/1500 CPU) via the fieldbus. Parameter assignment (input range, filter frequency, diagnostics enable) is performed in STEP 7 HW Config or TIA Portal Device Configuration and downloaded to the IM during startup.
Sourcing & Quality Verification
- Origin: Genuine Siemens SIMATIC product, manufactured in Germany / Singapore (lot-dependent)
- Condition: New original (factory-sealed) or tested surplus — clearly stated per order
- Traceability: Each unit ships with original Siemens packaging, date code label, and CE declaration of conformity
- Inspection: 100% functional test performed prior to dispatch; test report available on request
- Anti-Counterfeit: Holographic Siemens authenticity label verified; firmware version confirmed against Siemens product lifecycle database
- Warranty: 12-month replacement warranty against manufacturing defects
Procurement Process
- Step 1 – Inquiry: Submit your BOM or part number via email to support@konmask.com or WhatsApp +0086 19859288691
- Step 2 – Quotation: Receive a formal quotation with unit price, lead time, and shipping options within 24 hours
- Step 3 – Order Confirmation: Confirm PO; payment via T/T, PayPal, or credit card accepted
- Step 4 – Dispatch: Orders ship within 1–3 business days via DHL / FedEx / UPS with full tracking
- Step 5 – After-Sales: Technical support and warranty claims handled directly by Konmask engineering team
Technical FAQ
- Q: Is the 6ES7134-4GB10-0AB0 compatible with the S7-1500 system?
- A: Yes, when used with an ET 200S station connected via PROFINET (IM 151-3 PN) or PROFIBUS DP (IM 151-1), it is fully compatible with S7-1500 as a distributed I/O station.
- Q: Can I use this module without a terminal module?
- A: No. The 6ES7134-4GB10-0AB0 requires a compatible terminal module (e.g., 6ES7193-4CA30-0AA0) for both mechanical mounting and field wiring. The terminal module is ordered separately.
- Q: What is the difference between 6ES7134-4GB10-0AB0 and 6ES7134-4GB11-0AB0?
- A: The -4GB11- variant supports additional input ranges and enhanced diagnostics. The -4GB10- is the standard version suitable for the majority of industrial analog input applications.
- Q: How do I configure the input range?
- A: Input range is configured via software in STEP 7 HW Config or TIA Portal Device Configuration — no hardware jumpers required. Changes take effect after downloading the hardware configuration to the IM.
- Q: What happens if the input signal exceeds the configured range?
- A: The module generates an overflow diagnostic and sets the process value to the overflow code (32767 for positive overflow). A PROFIBUS/PROFINET diagnostic alarm is triggered if diagnostics are enabled in the configuration.
