PROFIBUS DP Distributed I/O Solution — Siemens 6ES7153-2BA01-0XB0 | ET 200M Series
Where This Product Is Used
The Siemens 6ES7153-2BA01-0XB0 (IM 153-2) is the interface module that bridges an ET 200M distributed I/O station to a PROFIBUS DP fieldbus network. When this module is absent or fails, the entire remote I/O rack goes dark — the PLC loses visibility of every sensor and actuator connected to that station, triggering an unplanned line stoppage that can cost thousands of dollars per minute in automotive, pharmaceutical, or power generation environments. Its role is not optional; it is the communication backbone of the distributed control architecture.
Within the ET 200M family, the 6ES7153-2BA01-0XB0 occupies the high-reliability tier: it is the only IM 153-2 revision that supports both isochronous mode and Y-Link redundancy, making it the preferred choice for PCS 7 high-availability systems and motion-critical applications worldwide. Siemens has shipped this module into more than 60 countries, and it remains one of the most widely installed PROFIBUS DP slave interfaces in the global installed base.
Where This Product Is Used
Engineers specify the 6ES7153-2BA01-0XB0 across a broad range of industries and equipment types:
- Automotive body-shop lines — robot cell I/O distributed across welding fixtures up to 1,200 m from the PLC cabinet
- Water & wastewater treatment plants — pump-station RTUs connected to a central SIMATIC S7-400 via PROFIBUS DP at 1.5 Mbit/s
- Pharmaceutical packaging lines — GMP-compliant distributed I/O with hot-swap capability for zero-downtime module replacement
- Power generation & substations — DCS integration where ET 200M acts as a remote I/O slave under a SIMATIC PCS 7 system
- Food & beverage conveyor systems — washdown-area I/O expansion using IP20 modules inside sealed enclosures
- Machine-tool CNC cells — axis-enable and safety I/O routed through PROFIBUS DP to a SINUMERIK controller
- Oil & gas processing skids — ATEX Zone 2 installations requiring certified distributed I/O in hazardous areas
- Pulp & paper mills — high-availability PCS 7 architectures with Y-Link redundancy for continuous-process protection
Technical Specifications
| Order Number (MLFB) | 6ES7153-2BA01-0XB0 |
| Series | ET 200M / SIMATIC S7-300 |
| Function | IM 153-2 — PROFIBUS DP Interface Module (slave) |
| Fieldbus Protocol | PROFIBUS DP (EN 50170), up to 12 Mbit/s |
| DP Address Range | 0 – 125 (rotary switch, front panel) |
| Max. I/O Modules per Station | 8 standard / up to 12 with active bus modules |
| Supply Voltage | DC 24 V (20.4 – 28.8 V) |
| Current Consumption | ≤ 300 mA |
| Backplane Bus | S7-300 rail (35 mm DIN) |
| Hot Swapping | Supported (requires active bus module) |
| Isochronous Mode | Supported |
| Y-Link Redundancy | Supported (PCS 7 high-availability) |
| Dimensions (W × H × D) | 40 × 125 × 120 mm |
| Weight | approx. 280 g |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | −40 °C to +70 °C |
| Protection Class | IP20 |
| Certifications | CE, UL, cUL, FM Class I Div 2, ATEX II 3 G (Zone 2) |
Why Engineers Specify This Model
- Proven PROFIBUS DP slave — fully compliant with EN 50170; interoperable with any DP master (S7-300, S7-400, PCS 7, third-party)
- Isochronous operation — deterministic cycle times down to 1 ms for motion-control and high-speed process applications
- Hot-swap ready — paired with active bus modules, individual I/O modules can be replaced under power without stopping the line
- Broad S7-300 module compatibility — supports the full SM 321/322/331/332/334/338 signal module range and CP 343 communication processors
- Y-Link redundancy — the -2BA01 revision supports redundant PROFIBUS DP architectures for high-availability PCS 7 systems
- Simple address assignment — rotary switch on the front panel; no software tool required for basic commissioning
- Long-term availability — widely stocked in the global industrial surplus market; Konmask.com maintains verified inventory for MRO and project needs
Complete System Bill of Materials
A typical ET 200M station built around the 6ES7153-2BA01-0XB0 requires the following components:
- 6ES7153-2BA01-0XB0 — IM 153-2 Interface Module (this item)
- 6ES7390-1AE80-0AA0 — S7-300 DIN rail (482 mm or 530 mm)
- 6ES7195-7HD10-0XA0 — Active bus module (enables hot-swap)
- 6ES7321-1BH02-0AA0 — SM 321 DI 16 × DC 24 V digital input module
- 6ES7322-1BH01-0AA0 — SM 322 DO 16 × DC 24 V / 0.5 A digital output module
- 6ES7331-7KF02-0AB0 — SM 331 AI 8 × 13-bit analog input module
- 6ES7307-1EA01-0AA0 — PS 307 24 V / 5 A power supply module
- 6ES7972-0BA52-0XA0 — PROFIBUS DP bus connector 90°
- 6ES7197-1LB00-0XA0 — Y-Link module (for PCS 7 redundancy, if required)
Contact support@konmask.com to source any of the above companion parts.
Compliance & Industry Standards
- CE Marking — EMC Directive 2014/30/EU & Low Voltage Directive 2014/35/EU
- UL 508 / cUL — Industrial Control Equipment (North America)
- FM Class I, Division 2 — Hazardous Locations
- ATEX II 3 G — Zone 2 explosive atmosphere (IECEx equivalent)
- IEC 61131-2 — Programmable Controllers, Equipment Requirements
- EN 50170 — PROFIBUS fieldbus standard
- RoHS 2011/65/EU compliant
Quality Assurance & Sourcing
Every unit offered through Konmask.com undergoes a structured inspection process before dispatch:
- Visual inspection of housing, connectors, front-panel label, and rotary switch integrity
- Firmware version verification against Siemens product lifecycle records
- Functional power-on test with PROFIBUS DP address confirmation via LED diagnostics
- Anti-static packaging with humidity indicator card and desiccant
- Traceable lot documentation available on request
We source from authorized distribution channels and verified industrial surplus. Counterfeit-risk screening is applied to all inbound stock. Our engineers have hands-on experience with SIMATIC hardware and can identify non-genuine units by physical and firmware markers.
How to Source This Part
- In-stock orders: Submit an inquiry or add to cart — our team responds within 1 business hour during CST business hours
- Bulk / project quantities: Email support@konmask.com for volume pricing and lead-time commitment
- Urgent MRO requirements: Call or WhatsApp +0086 19859288691 for expedited sourcing and same-day quotation
- Cross-reference / substitution advice: Our engineers can confirm compatible alternatives (e.g., 6ES7153-2BA02-0XB0) if the exact revision is temporarily unavailable
- Export & customs documentation: We provide commercial invoices, packing lists, and certificates of origin for international shipments
Application-Specific FAQ
Q: Can the 6ES7153-2BA01-0XB0 operate as a PROFIBUS DP master?
A: No. The IM 153-2 is a DP slave only. For master functionality, use a CP 342-5 or the integrated DP port on an S7-300 CPU.
Q: Is this module compatible with PROFINET?
A: No — this variant uses PROFIBUS DP exclusively. For PROFINET-based ET 200M, specify the IM 153-4 PN IO (6ES7153-4AA01-0XB0).
Q: How many I/O modules can I connect per station?
A: Up to 8 S7-300 signal modules in a standard configuration; up to 12 with active bus modules installed.
Q: Does it support Y-Link redundancy for PCS 7?
A: Yes. The -2BA01 revision supports Y-Link (6ES7197-1LB00-0XA0) for redundant PROFIBUS DP architectures in PCS 7 high-availability systems.
Q: What is the maximum PROFIBUS DP cable length?
A: At 1.5 Mbit/s, the maximum segment length is 200 m; at 93.75 kbit/s, up to 1,200 m per segment. Repeaters extend total network reach.
Q: Can I replace an I/O module without stopping the process?
A: Yes — when active bus modules (6ES7195-7HD10-0XA0) are installed, individual SM modules can be hot-swapped under power without interrupting the PROFIBUS DP communication.
Q: Is the 6ES7153-2BA01-0XB0 still in production?
A: Siemens has transitioned newer projects to PROFINET-based ET 200MP, but the -2BA01-0XB0 remains available through authorized distributors and industrial surplus channels. Konmask.com maintains stock specifically to support MRO and legacy system maintenance.
© 2026 Konmask.com. All rights reserved.
Original Source: https://Konmask.com
Contact: support@konmask.com | +0086 19859288691
{
