PROFINET Distributed I/O Solution – Siemens 6ES7153-4AA01-0XB0 | SIMATIC ET 200M
The Siemens 6ES7153-4AA01-0XB0 is the IM 153-4 PN IO interface module for the SIMATIC ET 200M distributed I/O station. It connects the ET 200M rack directly to a PROFINET IO network, enabling high-speed, deterministic communication between field-level I/O and the S7-300/S7-400 controller — without requiring a PG/PC for local operation. Engineered for demanding industrial environments, this module is the backbone of scalable, modular automation architectures across process and discrete manufacturing.
Where This Product Is Used
- Automotive Assembly Lines — Distributed I/O nodes on PROFINET rings for body-in-white welding, paint shop conveyors, and final assembly stations requiring deterministic cycle times.
- Chemical & Petrochemical Plants — Remote I/O marshalling cabinets connected to S7-400H redundant controllers via PROFINET, replacing long home-run cable runs.
- Water & Wastewater Treatment — Pump station and filtration skid I/O expansion where ET 200M racks are mounted in field enclosures up to 1,000 m from the control room.
- Food & Beverage Processing — Hygienic-zone I/O panels on filling, capping, and labelling lines integrated into SIMATIC PCS 7 process control systems.
- Power Generation & Utilities — Turbine auxiliary panel I/O connected to PROFINET-based DCS architectures for real-time monitoring and control.
- Machine Tool & Press Shops — Modular I/O expansion for CNC transfer lines and hydraulic press cells where S7-300 CPUs manage multiple ET 200M stations.
- Pharmaceutical Manufacturing — GMP-compliant I/O marshalling in cleanroom environments, supporting GAMP 5 validation requirements.
Technical Specifications
| Order Number (MLFB) | 6ES7153-4AA01-0XB0 |
| Product Family | SIMATIC ET 200M |
| Module Type | IM 153-4 PN IO Interface Module |
| Communication Interface | PROFINET IO (2-port integrated switch) |
| PROFINET Topology | Line, star, ring (MRP supported) |
| Max. I/O Modules per Station | Up to 8 signal modules (SM) / function modules (FM) |
| Supply Voltage | 24 V DC (20.4 – 28.8 V) |
| Current Consumption (from 24 V) | Max. 1.2 A |
| Transmission Rate | 10/100 Mbit/s (auto-negotiation) |
| Isochronous Mode | Supported |
| PROFIsafe | Supported (F-modules compatible) |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | -40 °C to +70 °C |
| Degree of Protection | IP20 |
| Dimensions (W × H × D) | 40 × 125 × 117 mm |
| Weight | Approx. 240 g |
| PG Operation Required | No (without PG operation) |
| Firmware Upgradeable | Yes, via PROFINET |
Why Engineers Specify This Model
- No PG/PC Required for Operation — The 0XB0 variant operates fully autonomously after commissioning; no programming device needs to remain connected, reducing hardware costs and simplifying cabinet design.
- Integrated 2-Port PROFINET Switch — Enables line topology wiring without external switches, cutting BOM cost and reducing single points of failure.
- MRP Ring Redundancy — Supports Media Redundancy Protocol for sub-200 ms network recovery, meeting high-availability requirements in continuous process industries.
- PROFIsafe Compatibility — Allows mixing of standard and safety I/O modules on the same ET 200M rack, simplifying safety architecture and reducing panel footprint.
- Isochronous Real-Time (IRT) — Deterministic cycle times down to 250 µs for motion control and synchronized multi-axis applications.
- Broad S7 CPU Compatibility — Works with S7-300, S7-400, S7-400H (redundant), and SIMATIC PCS 7 controllers, protecting existing infrastructure investments.
- Hot-Swap Module Replacement — Signal modules can be replaced under power without shutting down the ET 200M station, maximizing plant uptime.
Complete System Bill of Materials
A typical ET 200M PROFINET station built around the 6ES7153-4AA01-0XB0 requires the following components:
- 6ES7153-4AA01-0XB0 — IM 153-4 PN IO Interface Module (this item)
- 6ES7195-1GA00-0XA0 — UR2 Universal Rack (18-slot) or 6ES7195-1HB00-0XA0 (9-slot)
- 6ES7307-1EA01-0AA0 — PS 307 24 V DC / 5 A Power Supply Module
- 6ES7321-1BH02-0AA0 — SM 321 Digital Input Module (16 × 24 V DC) — as required
- 6ES7322-1BH01-0AA0 — SM 322 Digital Output Module (16 × 24 V DC / 0.5 A) — as required
- 6ES7331-7KF02-0AB0 — SM 331 Analog Input Module (8 × 13-bit) — as required
- 6GK1901-1BB10-2AE0 — IE FC RJ45 Plug 180 (PROFINET connector)
- 6XV1840-2AH10 — PROFINET IE FC TP Standard Cable GP 2×2 (per metre)
Compliance & Industry Standards
- CE Marking — EU Low Voltage Directive & EMC Directive compliant
- UL Listed — UL 508 (Industrial Control Equipment)
- cULus — Canadian market approval
- PROFINET Conformance Class B (CC-B) certified
- IEC 61131-2 — Programmable Controllers: Equipment Requirements & Tests
- IEC 61784-1 — Communication Profile Families (PROFINET)
- ATEX / IECEx — Not rated for Zone 0/1; use appropriate barriers for hazardous areas
- RoHS 2 (2011/65/EU) compliant
Quality Assurance & Sourcing
Every 6ES7153-4AA01-0XB0 unit offered through Konmask.com is sourced from verified Siemens-authorized distribution channels or directly from Siemens AG factory stock. Each unit undergoes the following before dispatch:
- Visual inspection for physical damage, label integrity, and firmware version verification
- Functional power-on test confirming LED status and PROFINET port link-up
- Anti-static packaging with humidity indicator card
- Original Siemens factory seal and holographic label intact
- Certificate of conformity available upon request
We maintain traceability records for all units, supporting your incoming inspection and IQ/OQ validation documentation requirements.
How to Source This Part
- In-Stock Orders — Add to cart and check out. Standard lead time: 1–3 business days for dispatch. Express options available at checkout.
- Bulk / Project Quantities — Contact our engineering sales team for volume pricing, project reservation, and staged delivery scheduling.
- Urgent / Breakdown Supply — Call or WhatsApp +0086 19859288691 for same-day quotation on emergency breakdown stock.
- Cross-Reference / Replacement — If you are replacing a 6ES7153-4AA00-0XB0 (previous hardware revision), the 4AA01 is the direct drop-in successor with identical mounting and wiring.
Application-Specific FAQ
- Q: Can the 6ES7153-4AA01-0XB0 be used with an S7-1500 controller?
- A: Not directly. The IM 153-4 PN IO is designed for S7-300/400 and PCS 7 systems. For S7-1500, Siemens recommends the ET 200MP with IM 155-5 PN ST (6ES7155-5AA01-0AB0). Contact us if you need assistance selecting the correct interface module for your CPU generation.
- Q: What is the difference between 6ES7153-4AA00-0XB0 and 6ES7153-4AA01-0XB0?
- A: The 4AA01 is the successor hardware revision (HW: 1, FW: V3.x+) with improved PROFINET diagnostics, extended IRT support, and compatibility with newer STEP 7 / TIA Portal versions. It is a direct mechanical and electrical replacement for the 4AA00.
- Q: Does this module support PROFINET IRT (Isochronous Real-Time)?
- A: Yes. The IM 153-4 PN IO supports PROFINET IRT with cycle times as low as 250 µs, suitable for synchronized motion control applications when paired with compatible IO-Controllers.
- Q: How many I/O modules can be connected to one IM 153-4 PN IO?
- A: Up to 8 signal modules (SM) or function modules (FM) can be inserted into the ET 200M rack per interface module. For larger I/O counts, multiple ET 200M stations can be daisy-chained on the same PROFINET segment.
- Q: Is PROFIsafe supported for functional safety applications?
- A: Yes. The 6ES7153-4AA01-0XB0 supports PROFIsafe, allowing F-SM safety modules (e.g., 6ES7326-1BK02-0AB0) to be mixed with standard I/O modules on the same rack, up to SIL 3 / PLe.
- Q: What STEP 7 / TIA Portal version is required for configuration?
- A: STEP 7 V5.5 SP4 or higher is required. TIA Portal V13 SP1 or higher is supported for projects migrated to the TIA environment. The GSD file (GSDML) is available from the Siemens Industry Online Support portal.
