Genuine SIEMENS 6ES7222-1HF22-0XA8 SIMATIC S7-200 - Industrial Automation Part

SIEMENS 6ES7222-1HF22-0XA8 Digital Output Module | S7-200 Series

SKU: 6ES7222-1HF22-0XA8 Category: Siemens

Description

Genuine SIEMENS 6ES7222-1HF22-0XA8 Digital Output Expansion Module | S7-200 Series – Verified Source

Sourced directly through authorized industrial distribution channels, the SIEMENS 6ES7222-1HF22-0XA8 is an 8-channel digital output expansion module designed for the S7-200 Micro PLC family. At Konmask.com, every unit we ship has passed our documented verification process — so your engineering team receives exactly what the datasheet specifies, every time.

Technical Specifications

Part Number: 6ES7222-1HF22-0XA8
Series: SIMATIC S7-200
Module Type: Digital Output Expansion Module (EM 222)
Number of Outputs: 8 × Digital Output (DO)
Output Type: Transistor (Solid-State), Sourcing
Output Voltage: 24 VDC
Output Current per Channel: 0.75 A
Total Output Current: 6 A (all channels simultaneously)
Isolation: Optocoupler isolation between field and logic side
Power Supply: 24 VDC sensor supply from CPU or external
Dimensions (W × H × D): 46 × 80 × 62 mm
Weight: Approx. 100 g
Operating Temperature: 0 °C to +55 °C
Storage Temperature: −40 °C to +70 °C
Degree of Protection: IP20
MLFB / Order Number: 6ES7 222-1HF22-0XA8
Firmware Version: Compatible with S7-200 CPU 221/222/224/224XP/226

Our 4-Step Quality Verification Process

Every SIEMENS module shipped from Konmask.com undergoes the following documented checks before dispatch:

Step 1 — Visual Inspection: Housing integrity, label authenticity, hologram verification, and connector condition checked against OEM reference standards.
Step 2 — Firmware & Serial Number Validation: Serial number cross-referenced against SIEMENS production batch records where accessible; firmware version confirmed.
Step 3 — Functional Bench Test: Module powered and output channels cycled under controlled load to confirm correct switching behavior and isolation integrity.
Step 4 — Packaging & Documentation Review: Original SIEMENS packaging, CE/UL markings, and accompanying documentation verified before final sealing and dispatch.

A verification checklist is available upon request for procurement and quality assurance teams.

Key Features & Benefits

✅ Genuine SIEMENS OEM hardware — not refurbished, not grey-market
✅ 8 independent transistor outputs for high-density discrete control
✅ Solid-state switching — no mechanical wear, extended service life
✅ Optocoupler isolation protects CPU from field-side voltage transients
✅ Plug-and-play expansion — connects directly to S7-200 CPU via expansion bus
✅ Compact DIN-rail form factor — minimizes panel space consumption
✅ RoHS compliant — suitable for environmentally regulated installations
✅ Traceable supply chain — full procurement documentation available on request

Typical Applications

Conveyor and material handling control systems
Packaging machinery and filling line automation
HVAC and building management system (BMS) integration
Water treatment and pump station control panels
Machine tool and CNC auxiliary I/O expansion
Food & beverage processing equipment
OEM equipment requiring compact, reliable discrete output expansion

Compatible System Components

Compatible CPUs: S7-200 CPU 221, CPU 222, CPU 224, CPU 224XP, CPU 226
Compatible Software: STEP 7-Micro/WIN V4.0 SP9 and above
Expansion Bus: Direct side-mount expansion connector (no additional cable required)
Accessories: 6ES7290-6AA20-0XA0 (Expansion Cable), 6ES7291-8BA20-0XA0 (Memory Cartridge)
Power Module: 6EP1332-1SH43 (SITOP 24VDC PSU, recommended for multi-module racks)

Global Sourcing & Shipping Capabilities

Stock Location: Mainland China warehouse with bonded export capability
Lead Time: In-stock orders typically dispatched within 1–3 business days
Shipping Methods: DHL Express, FedEx International Priority, SF International, sea freight for bulk orders
Export Documentation: Commercial invoice, packing list, certificate of origin, and SIEMENS datasheet provided as standard
Customs Support: HS Code 8537.10 — we assist with customs declaration documentation upon request
Bulk & OEM Orders: Contact us for volume pricing, consolidated shipments, and blanket purchase agreements
Regions Served: Southeast Asia, Middle East, Europe, Africa, South America, and beyond

Certifications & Compliance Statement

CE Marking: Compliant with EU Machinery Directive and EMC Directive
UL Listed: UL 508 (Industrial Control Equipment)
RoHS: Restriction of Hazardous Substances Directive compliant
ISO 9001: Konmask.com operates under ISO 9001-aligned procurement and quality management procedures
SIEMENS Authenticity: All units sourced through documented industrial distribution channels; counterfeit-free guarantee backed by our verification process

Compliance certificates and test reports are available upon written request for regulated industries (energy, rail, medical auxiliary).

How to Order

Step 1: Confirm part number: 6ES7222-1HF22-0XA8 matches your BOM or existing system configuration
Step 2: Select quantity and add to cart, or contact us directly for bulk pricing
Step 3: At checkout, specify any special requirements (export docs, inspection reports, delivery deadline)
Step 4: Receive order confirmation with estimated dispatch date within 24 hours
Step 5: Track your shipment via the provided waybill number; our team is available for pre-delivery coordination

📧 Email: support@konmask.com | 📞 Phone/WhatsApp: +0086 19859288691

Authenticity & Trust FAQ

Q: How do I know this is a genuine SIEMENS module?
A: Every unit passes our 4-step verification process (detailed above). We provide the original SIEMENS packaging, hologram labels, and serial number documentation. Procurement teams may request a pre-shipment inspection report.

Q: Do you offer a warranty?
A: Yes. We offer a 12-month warranty against manufacturing defects on all genuine SIEMENS modules. DOA (Dead on Arrival) units are replaced or refunded within 7 days of confirmed receipt.

Q: Can I request a sample before placing a bulk order?
A: Yes. Sample orders (1–2 units) are available at standard pricing. Contact us to discuss sample evaluation arrangements for OEM or system integrator accounts.

Q: What if the part number I need is not listed?
A: We maintain access to a broad catalog of SIEMENS SIMATIC S7-200, S7-300, S7-400, and S7-1200/1500 components. Contact us with your full BOM and we will respond with availability and pricing within 24 hours.

Q: Are you able to provide export/import documentation for customs clearance?
A: Yes. We routinely prepare commercial invoices, packing lists, certificates of origin, and product datasheets for international shipments. Special documentation requests (e.g., Form E for ASEAN, EUR.1 for EU) can be arranged.
