SIEMENS 6ES7414-2XK05-0AB0 – CPU 414-2 Processor Module | SIMATIC S7-400 Platform
Engineering Background: The SIMATIC S7-400 series represents Siemens’ flagship programmable logic controller platform, engineered for high-availability, large-scale industrial automation. The CPU 414-2 (6ES7414-2XK05-0AB0) is a mid-to-high performance central processing unit within this family, designed to handle complex, multi-axis process control tasks with deterministic cycle times and robust communication capabilities.
Product Positioning: Targeted at procurement engineers and system integrators managing distributed control architectures in process industries, automotive manufacturing, and critical infrastructure. This module serves as the computational core of an S7-400 rack, coordinating I/O, inter-PLC communication, and real-time program execution across demanding production environments.
Complete Technical Specifications
- Order Number (MLFB): 6ES7414-2XK05-0AB0
- Product Family: SIMATIC S7-400
- CPU Type: CPU 414-2
- Work Memory (RAM): 1.6 MB (expandable via memory card)
- Load Memory: Integrated 256 KB RAM; expandable via Flash/RAM memory card (up to 64 MB)
- Processing Speed: Binary operations: 0.1 µs; Floating-point operations: 0.3 µs
- Max. I/O Addresses: 16 KB digital I/O; 4 KB analog I/O
- Communication Interfaces: 1× MPI (187.5 Kbps – 12 Mbps); 1× PROFIBUS-DP Master/Slave (up to 12 Mbps)
- Max. DP Slaves: 125 per DP interface
- Program Blocks: OB, FB, FC, DB — up to 65535 blocks
- Timers / Counters: 2048 / 2048
- Nesting Depth: 24 levels
- Supply Voltage: 5 VDC (via S7-400 backplane bus)
- Power Consumption: Approx. 2.0 W (from backplane)
- Operating Temperature: 0 °C to +60 °C
- Storage Temperature: −40 °C to +70 °C
- Relative Humidity: 10% – 95% (non-condensing)
- Protection Class: IP 20
- Dimensions (W×H×D): 25 mm × 290 mm × 219 mm
- Weight: Approx. 700 g
- Country of Origin: Germany
- Firmware Version: V5.0 (as per order suffix 0AB0)
- STEP 7 Compatibility: STEP 7 V5.x and TIA Portal (with HSP)
Proven Application Environments
- Process Automation: Chemical plants, oil & gas refineries, and water treatment facilities requiring high-throughput data processing and redundant communication paths.
- Automotive Manufacturing: Body-in-white welding lines, paint shop conveyors, and powertrain assembly cells with multi-axis coordination via PROFIBUS-DP.
- Power Generation & Distribution: Turbine control, substation automation, and load management systems demanding deterministic scan cycles.
- Pharmaceutical & Food Processing: Batch control systems compliant with ISA-88 standards, leveraging the CPU’s large program memory for complex recipe management.
- Material Handling: High-speed sortation systems and automated storage/retrieval (AS/RS) with distributed I/O over PROFIBUS-DP.
Engineering Advantages
- Dual Communication Ports: Simultaneous MPI and PROFIBUS-DP operation enables peer-to-peer PLC networking alongside distributed I/O without additional CP modules.
- Large Addressable Memory: 1.6 MB work memory supports complex structured programs with extensive data logging, reducing the need for external data management hardware.
- Hot-Swap Compatibility: Designed for S7-400 UR1/UR2 racks supporting active bus modules, enabling module replacement without full system shutdown in redundant configurations.
- Deterministic Cycle Performance: Sub-microsecond binary instruction execution ensures predictable response times for time-critical interlocks and safety-related sequences.
- Broad Software Ecosystem: Full compatibility with STEP 7 Classic and TIA Portal (via HSP) protects existing engineering investments and simplifies migration paths.
System Architecture & Signal Flow
The 6ES7414-2XK05-0AB0 occupies a standard slot in the S7-400 central rack (UR1 or UR2). The CPU communicates with signal modules (SM), function modules (FM), and communication processors (CP) via the high-speed S7-400 backplane bus (P-bus and K-bus). The integrated MPI port connects to a SIMATIC programming device (PG/PC) or HMI panels. The PROFIBUS-DP port acts as a DP Master, polling distributed I/O stations (ET 200 series) or interfacing with DP-capable drives and instruments. Program execution follows a cyclic scan model with configurable interrupt-driven OBs for time-critical events, hardware interrupts, and diagnostic alarms.
Sourcing & Quality Verification
- Authenticity: All units sourced through verified industrial supply channels. Each module is inspected for genuine Siemens labeling, holographic seals, and firmware version consistency prior to dispatch.
- Condition Options: New-in-box (NIB), factory-refurbished (FR), and tested-used (TU) grades available — specify condition requirement at inquiry stage.
- Warranty: 12-month operational warranty on all grades. Extended warranty available upon request.
- Certifications: CE, UL, cUL, ATEX (zone 2) — confirm applicable certifications for your installation class.
- Traceability: Serial number and firmware version documented on shipping manifest for full audit trail.
Procurement Process
- Inquiry: Submit your RFQ with required quantity, condition grade, and delivery timeline via support@konmask.com or the product page inquiry form.
- Quotation: Receive a formal quotation within 1 business day including unit price, lead time, and shipping options (DHL Express, FedEx, sea freight).
- Order Confirmation: Issue PO against quotation. Payment terms: T/T, PayPal, or trade assurance.
- Quality Inspection: Pre-shipment inspection report and photos provided upon request.
- Dispatch & Tracking: ESD-safe packaging with anti-static foam insert. Real-time tracking number provided within 24 hours of shipment.
- After-Sales Support: Technical commissioning support available via email and WhatsApp (+0086 19859288691).
Technical FAQ
Q: Is the 6ES7414-2XK05-0AB0 compatible with TIA Portal?
A: Yes, with the Hardware Support Package (HSP) for S7-400 CPUs installed in TIA Portal V13 SP1 or later. Full STEP 7 V5.x compatibility is native.
Q: Can this CPU operate as a PROFIBUS-DP slave?
A: Yes. The DP interface supports both Master and Slave modes, configurable in hardware configuration (HW Config).
Q: What memory card is compatible?
A: SIMATIC S7-400 Flash memory cards (e.g., 6ES7952-1KK00-0AA0 for 4 MB) or RAM cards. Ensure the card matches the CPU’s memory card slot specification.
Q: What is the difference between firmware suffix 0AB0 vs 0AB0 variants?
A: The suffix 0AB0 denotes the standard firmware release V5.0. Always verify firmware compatibility with your existing STEP 7 project version before ordering.
Q: Can I replace this CPU without powering down the entire rack?
A: Hot-swap is supported only when active bus modules are installed in the S7-400 rack. Consult your rack configuration before attempting live replacement.
