Siemens 6ES7416-5HS06-0AB0 CPU 416-5H Processor Module | Replacement, Equivalent & Selection Guide
The Siemens 6ES7416-5HS06-0AB0 (CPU 416-5H, Revision V6.0.5) is a high-availability processor module designed for the SIMATIC S7-400H redundant fault-tolerant controller system. It is engineered for mission-critical industrial automation applications where uninterrupted operation is essential. This page provides full technical specifications, compatible replacement options, and a structured selection guide to help engineers and procurement teams make informed decisions.
Technical Specifications
- Part Number: 6ES7416-5HS06-0AB0
- Revision: V6.0.5
- CPU Type: CPU 416-5H
- System: SIMATIC S7-400H (High-Availability / Redundant)
- Work Memory: 16 MB (expandable)
- Processing Speed: 0.08 µs/instruction (binary)
- Communication Interfaces: MPI/DP (PROFIBUS), Sync module interface (H-sync)
- Max. I/O Addresses: 16 KB input / 16 KB output
- Redundancy Mode: Hot-standby (1-of-2 redundancy)
- Operating Voltage: DC 24 V (via backplane bus)
- Operating Temperature: 0 °C to +60 °C
- Weight: Approx. 1,140 g
- Firmware: V6.0.5
- Programming Software: STEP 7 V5.x / TIA Portal (with HSP)
- Certifications: CE, UL, cULus, ATEX (Zone 2)
Compatible Replacement & Equivalent Models
When the original 6ES7416-5HS06-0AB0 is unavailable or end-of-life, the following models may serve as functional replacements depending on firmware compatibility and system configuration. Always verify with your system integrator before substitution.
| Model | Revision | Notes |
|---|---|---|
| 6ES7416-5HS06-0AB0 | V6.0.5 | Original — this listing |
| 6ES7416-5HS04-0AB0 | V4.x | Earlier revision; reduced memory; firmware downgrade required |
| 6ES7416-5HS05-0AB0 | V5.x | Previous generation; compatible with most S7-400H racks |
| 6ES7416-3XR05-0AB0 | — | CPU 416-3 (non-redundant); suitable for standard S7-400 only |
| 6ES7414-5HM06-0AB0 | V6.x | CPU 414-5H; lower performance tier; same H-system architecture |
Note: Cross-model substitution requires validation of rack compatibility, sync module version, and STEP 7/TIA Portal project settings.
Why Choose the Original Model
- Certified Redundancy: Native hot-standby support with sub-100ms switchover — no configuration workarounds needed.
- Firmware Continuity: V6.0.5 ensures compatibility with the latest STEP 7 V5.7 and TIA Portal HSP packages.
- Extended Lifecycle: Siemens S7-400H modules are supported through extended service agreements, reducing obsolescence risk.
- Proven Reliability: Deployed globally in oil & gas, chemical, water treatment, and power generation facilities.
- Full Diagnostics: Integrated system diagnostics via PROFIBUS DP and MPI for predictive maintenance.
Typical Applications
- Oil & gas pipeline control and emergency shutdown systems (ESD)
- Chemical plant process automation with SIL 2/3 requirements
- Water and wastewater treatment plant SCADA integration
- Power generation and substation automation
- Pharmaceutical batch processing with FDA 21 CFR Part 11 compliance
- Automotive assembly line redundant control
System Compatibility
- Rack: SIMATIC S7-400H UR2-H or UR1 (with H-sync module)
- Sync Module: 6ES7960-1AA06-0XA0 or compatible
- Power Supply: PS 407 (6ES7407-0KA02-0AA0) or PS 405
- I/O Modules: All standard S7-400 SM/FM/CP modules
- Communication: CP 443-1 (Ethernet), CP 443-5 (PROFIBUS)
- Programming: STEP 7 V5.5 SP4 or higher; TIA Portal V15+ with S7-400H HSP
- HMI: WinCC, SIMATIC HMI TP/MP series via MPI or PROFIBUS
Selection Guide
Use the following criteria to confirm the 6ES7416-5HS06-0AB0 is the right choice for your project:
- Redundancy Required? → Yes: CPU 416-5H (this model). No: Consider CPU 416-3 (6ES7416-3XR05-0AB0).
- Memory Requirement > 8 MB? → Yes: V6.0.5 (this model). No: V4.x or V5.x may suffice.
- PROFIBUS DP Master Needed? → Integrated in this CPU; no additional CP required.
- SIL Certification Required? → Pair with F-CPU or use in conjunction with S7-400 FH configuration.
- Budget-Sensitive Replacement? → Evaluate 6ES7416-5HS05-0AB0 (V5.x) with firmware validation.
- New Project vs. Retrofit? → New projects: consider SIMATIC S7-1500H as a forward-compatible alternative.
Quality Assurance & Sourcing
- All units at Konmask.com are sourced from verified industrial supply channels.
- Each module undergoes visual inspection and functional verification before dispatch.
- Original Siemens packaging and documentation preserved where available.
- Traceability records maintained for B2B procurement compliance.
- Warranty: 12 months from date of shipment (defective-on-arrival replacement policy).
How to Order
- Confirm your rack type and sync module revision with your system documentation.
- Verify firmware version compatibility with your STEP 7 or TIA Portal project.
- Add 6ES7416-5HS06-0AB0 to cart or contact us for bulk/project pricing.
- Provide your PO number and delivery address for B2B invoicing.
- Expedited shipping available for urgent plant maintenance requirements.
📧 Email: support@konmask.com
📞 Phone/WhatsApp: +0086 19859288691
🌐 Website: https://Konmask.com
Replacement & Compatibility FAQ
Q: Can I replace 6ES7416-5HS06-0AB0 with 6ES7416-5HS05-0AB0?
A: In most cases yes, but you must downgrade the firmware and re-validate the H-sync configuration. Consult Siemens TIA Portal compatibility matrix.
Q: Is this CPU compatible with S7-400 standard (non-H) racks?
A: The CPU 416-5H can operate in a standard rack in simplex mode, but redundancy features require the UR2-H rack and sync modules.
Q: What is the difference between V5.x and V6.0.5?
A: V6.0.5 supports larger work memory configurations, improved PROFIBUS DP cycle times, and compatibility with TIA Portal V17+.
Q: Do you supply new or refurbished units?
A: We supply both. All units are clearly labeled. New units come with full Siemens warranty documentation; refurbished units carry Konmask’s 12-month warranty.
Q: Can this module be used as a direct drop-in replacement without reprogramming?
A: Only if the replacement unit carries the same firmware revision. Different revisions may require project re-compilation and H-system re-synchronization.
