Siemens 6AV2181-8XP00-0AX0 SIMATIC HMI SD Memory Card 2GB | SIMATIC HMI Platform
Engineering Background
The Siemens 6AV2181-8XP00-0AX0 is an OEM-grade industrial SD memory card engineered specifically for the SIMATIC HMI product family. Designed to meet the rigorous demands of continuous industrial operation, this 2 GB card provides reliable non-volatile storage for HMI project data, firmware updates, recipes, data logs, and system backups. It is a factory-certified accessory that ensures full compatibility and data integrity across the SIMATIC HMI ecosystem.
Product Positioning
Targeted at automation engineers, system integrators, and MRO procurement teams, the 6AV2181-8XP00-0AX0 is the standard-specified memory card for Siemens KTP, TP, and MP series HMI panels. It eliminates compatibility risk associated with third-party cards and is the only card type recommended by Siemens for firmware flashing and project transfer in production environments.
Complete Technical Specifications
- Part Number / SKU: 6AV2181-8XP00-0AX0
- Product Family: SIMATIC HMI Accessories
- Card Type: SD (Secure Digital)
- Storage Capacity: 2 GB
- Interface: SD / SDHC compatible slot
- Operating Temperature: -20 °C to +60 °C
- Storage Temperature: -40 °C to +85 °C
- Humidity: 5–95% RH (non-condensing)
- Protection Class: IP20 (when installed in panel)
- Vibration Resistance: Per IEC 60068-2-6
- Shock Resistance: Per IEC 60068-2-27
- Dimensions (W × H × D): 24 × 32 × 2.1 mm
- Weight: Approx. 2 g
- Country of Origin: Germany
- HS Code: 8523.51
- MLFB: 6AV2181-8XP00-0AX0
Compatible HMI Panels
- SIMATIC KTP400 Basic, KTP700 Basic, KTP900 Basic, KTP1200 Basic
- SIMATIC TP700 Comfort, TP900 Comfort, TP1200 Comfort, TP1500 Comfort, TP1900 Comfort, TP2200 Comfort
- SIMATIC MP377, MP377 Pro
- SIMATIC Comfort Panels (all variants requiring SD card slot)
- SIMATIC Mobile Panels 177, 277, 277 IWLAN
Proven Application Environments
- Discrete Manufacturing: Automotive assembly lines, CNC machine tool HMI stations requiring frequent recipe changeover and data logging
- Process Industry: Chemical and pharmaceutical plants where HMI firmware must be version-locked and audit-trailed
- Energy & Utilities: Substation automation and water treatment SCADA panels with remote firmware update requirements
- Food & Beverage: Hygienic production lines with wash-down environments (card protected inside IP65/IP66 panel enclosure)
- MRO & Spare Parts: Maintenance teams requiring a certified replacement card to restore HMI operation without re-engineering
Engineering Advantages
- OEM Certified: Factory-tested and approved by Siemens AG; eliminates compatibility risk from generic SD cards
- Industrial-Grade Endurance: Rated for extended read/write cycles under continuous industrial duty cycles
- Firmware Flash Ready: Pre-formatted and validated for SIMATIC HMI firmware update procedures via WinCC flexible and TIA Portal
- Data Integrity: Supports HMI project backup, recipe management, alarm logging, and trend data archiving without data corruption risk
- Plug-and-Play: No driver installation required; recognized immediately by SIMATIC HMI operating system
- Long-Term Availability: Siemens industrial lifecycle management ensures multi-year spare parts availability
System Architecture & Signal Flow
The 6AV2181-8XP00-0AX0 integrates into the SIMATIC HMI panel via the dedicated SD card slot on the rear or side of the panel housing. Data flow is managed by the HMI runtime (WinCC flexible Runtime or WinCC RT Advanced) through the panel’s internal SD controller. Typical data paths include:
- Project Transfer: Engineering PC → USB/Ethernet → HMI Panel → SD Card (project backup)
- Firmware Update: SD Card (firmware image) → HMI Boot Loader → Panel Flash Memory
- Runtime Logging: HMI Runtime → SD Card (alarm logs, recipe files, trend archives)
- Restore: SD Card → HMI Panel (full project and configuration restore after hardware replacement)
Sourcing & Quality Verification
- Source: Procured directly from Siemens-authorized distributors and certified channel partners
- Authenticity: Each unit includes Siemens OEM labeling, holographic seal, and traceable batch number
- Inspection: 100% incoming inspection including visual check, label verification, and functional test
- Documentation: Certificate of conformity and packing list available upon request
- Warranty: 12-month warranty against manufacturing defects; DOA replacement within 7 business days
Procurement Process
- Submit your inquiry with required quantity and delivery timeline via support@konmask.com or WhatsApp +0086 19859288691
- Receive formal quotation with lead time, unit price, and shipping options within 24 hours
- Confirm purchase order; payment via T/T, PayPal, or credit card accepted
- Shipment via DHL / FedEx / UPS with full tracking; typical lead time 3–7 business days
- Receive goods with packing list and optional CoC documentation
Technical FAQ
Q: Can I use a standard consumer SD card instead of 6AV2181-8XP00-0AX0?
A: Siemens does not recommend or support consumer SD cards in SIMATIC HMI panels. Using non-certified cards may cause project corruption, firmware update failures, or void the panel warranty.
Q: Is this card compatible with TIA Portal V17/V18/V19?
A: Yes. The 6AV2181-8XP00-0AX0 is compatible with all current TIA Portal versions and WinCC flexible 2008 SP5 and later.
Q: What is the maximum project size this card can store?
A: The 2 GB capacity supports HMI projects up to approximately 1.8 GB usable, sufficient for the largest Comfort Panel projects including embedded video and extensive recipe databases.
Q: Can the card be used for both project storage and data logging simultaneously?
A: Yes. The HMI runtime manages partitioned access; project files and runtime data logs coexist on the same card without conflict.
Q: Do you provide volume pricing for MRO or system integrator orders?
A: Yes. Contact us with your annual volume forecast for tiered pricing and framework agreement options.
