Siemens 6GK5224-0BA00-2AA3 SCALANCE X224 Managed Industrial Ethernet Switch | Replacement, Equivalent & Selection Guide
The Siemens 6GK5224-0BA00-2AA3 is a managed industrial Ethernet switch from the SIMATIC NET SCALANCE X-200 series, designed for demanding automation and process control environments. This page provides full technical specifications, compatible replacement models, cross-reference equivalents, and a structured selection guide to help engineers and procurement teams make the right sourcing decision.
Technical Specifications
- Part Number: 6GK5224-0BA00-2AA3
- Product Family: SIMATIC NET SCALANCE X-200
- Type: Managed Industrial Ethernet Switch
- Ports: 24 × RJ45 10/100 Mbit/s
- Management: Web-based, SNMP v1/v2c/v3, CLI
- Redundancy Protocols: RSTP, MRP (Media Redundancy Protocol)
- Power Supply: 24 V DC (18–32 V DC)
- Operating Temperature: -10 °C to +60 °C
- Protection Class: IP30
- Mounting: DIN rail / S7-300 rail
- Dimensions (W×H×D): approx. 60 × 125 × 124 mm
- Weight: approx. 1,800 g
- Certifications: CE, UL, cUL, ATEX (Zone 2)
- PROFINET: Supported (IO Device)
Compatible Replacement & Equivalent Models
The following models are commonly evaluated as replacements or functional equivalents for the 6GK5224-0BA00-2AA3. Always verify firmware compatibility and port configuration before substitution.
- Siemens 6GK5224-0BA00-2AA3 — Original model (this listing)
- Siemens 6GK5224-4GS00-2TC2 — SCALANCE XC224 successor with enhanced PROFINET support
- Siemens 6GK5224-0BA00-2AC2 — Variant with conformal coating for harsh environments
- Siemens 6GK5208-0BA10-2AA3 — 8-port managed alternative for smaller topologies
- Phoenix Contact FL SWITCH 2024 — Third-party 24-port managed IE switch, DIN rail, 24 V DC
- Hirschmann RS20-2400M2M2SDAEHH — Industrial managed switch with comparable port density
- Moxa EDS-528E — 28-port managed Ethernet switch for industrial automation
Note: Third-party replacements may require additional configuration. Contact our technical team for compatibility verification.
Why Choose the Original Model
- Native PROFINET Integration: Seamless integration as a PROFINET IO Device within Siemens TIA Portal and STEP 7 environments.
- MRP Ring Redundancy: Supports Media Redundancy Protocol for sub-200 ms failover in ring topologies.
- Proven Field Reliability: Widely deployed in automotive, chemical, and energy sectors with a long service record.
- Siemens Ecosystem Compatibility: Full compatibility with SINEMA Network Manager and SIMATIC NET diagnostics tools.
- ATEX Zone 2 Certification: Suitable for use in potentially explosive atmospheres.
Typical Applications
- Factory automation and production line networking
- Process control systems (DCS/SCADA backbone switches)
- Automotive assembly plant Ethernet infrastructure
- Energy and utilities substation communication networks
- Building automation and intelligent transport systems
- Machine-level Ethernet ring topologies requiring MRP redundancy
System Compatibility
- PLC Platforms: Siemens S7-300, S7-400, S7-1200, S7-1500 (via PROFINET)
- Engineering Software: TIA Portal V13+, STEP 7 V5.5+, SINEMA Network Manager
- Protocols: PROFINET, Modbus TCP, EtherNet/IP (passive), SNMP, HTTP/HTTPS
- Topology Support: Star, tree, ring (MRP), and redundant ring configurations
- Power Rail: Compatible with Siemens S7-300 mounting rail for compact panel integration
Selection Guide
Use the criteria below to determine whether the 6GK5224-0BA00-2AA3 is the right switch for your application, or to identify a suitable alternative:
- Port Count Required: 24 RJ45 ports — if fewer ports suffice, consider 6GK5208 (8-port) or 6GK5216 (16-port) variants.
- Redundancy Requirement: MRP ring redundancy required → 6GK5224-0BA00-2AA3 ✓ | RSTP only → lower-cost alternatives may apply.
- PROFINET IO Device: Required for Siemens PLC integration → original model recommended.
- Harsh Environment: Conformal coating needed → specify 6GK5224-0BA00-2AC2 variant.
- Budget Constraint: Third-party managed switches (Phoenix Contact, Moxa) offer cost savings but require manual PROFINET configuration.
- Fiber Uplink Needed: Upgrade to SCALANCE XC224 series (6GK5224-4GS00-2TC2) for SFP fiber ports.
Quality Assurance & Sourcing
- Authenticity: All units sourced from authorized distributors or verified surplus channels with full traceability.
- Inspection: Each unit undergoes visual inspection and functional verification prior to shipment.
- Condition Options: New (factory-sealed), Refurbished (tested & certified), and Surplus (used, tested) available — specify at inquiry.
- Documentation: Certificate of conformity and test reports available upon request.
- Warranty: 12-month warranty on all units; extended warranty available.
How to Order
- Step 1: Confirm part number: 6GK5224-0BA00-2AA3
- Step 2: Specify required quantity and condition (New / Refurbished / Surplus).
- Step 3: Add to cart or contact us directly for bulk pricing and lead time.
- Step 4: Provide shipping destination for freight quote (DDP/DAP available for international orders).
- Contact: support@konmask.com | +0086 19859288691
- Response Time: Within 24 hours on business days.
Replacement & Compatibility FAQ
Q: Can I replace 6GK5224-0BA00-2AA3 with a newer SCALANCE XC224 model?
A: Yes, the SCALANCE XC224 (e.g., 6GK5224-4GS00-2TC2) is the functional successor and is backward-compatible with most PROFINET configurations. Firmware and GSD file updates in TIA Portal are required.
Q: Is this switch compatible with non-Siemens PLCs?
A: Yes, as a standard managed Ethernet switch it supports any Ethernet-based device. PROFINET IO Device functionality is specific to Siemens controllers.
Q: What is the difference between 2AA3 and 2AC2 variants?
A: The 2AC2 variant includes conformal coating for protection against humidity, dust, and corrosive atmospheres. Functionally identical otherwise.
Q: Can I use a Phoenix Contact or Moxa switch as a drop-in replacement?
A: Electrically and functionally yes for standard Ethernet switching. However, PROFINET IO Device integration and Siemens diagnostic tools will not be natively supported without additional configuration.
Q: Do you offer quantity discounts?
A: Yes. Contact support@konmask.com with your required quantity for a volume pricing quote.
