Siemens 6GK5646-2GS00-2AC2 Industrial Ethernet Switch | Replacement, Equivalent & Selection Guide
The Siemens 6GK5646-2GS00-2AC2 is a managed industrial Ethernet switch from the SCALANCE XC-200 series, engineered for demanding industrial automation environments. Konmask.com supplies genuine and compatible units with full traceability, supporting your procurement, replacement, and system integration needs.
Technical Specifications
| Part Number | 6GK5646-2GS00-2AC2 |
| Brand | Siemens |
| Series | SCALANCE XC-200 |
| Type | Managed Industrial Ethernet Switch |
| Ports | 24 × RJ45 (10/100/1000 Mbps) + 4 × SFP (Gigabit) |
| Switching Capacity | Up to 56 Gbps |
| Power Supply | 100–240 V AC, 50/60 Hz |
| Operating Temperature | -40 °C to +70 °C |
| Protection Rating | IP30 |
| Mounting | DIN Rail / Rack |
| Protocols | PROFINET, SNMP, RSTP, MRP, IGMP Snooping |
| Certifications | CE, UL, ATEX (Zone 2) |
| Dimensions (W×H×D) | Approx. 60 × 125 × 124 mm |
| Weight | ~500 g |
Compatible Replacement & Equivalent Models
If the 6GK5646-2GS00-2AC2 is unavailable or you need a cost-effective alternative, the following models offer compatible functionality:
| Model | Brand | Key Difference | Compatibility |
|---|---|---|---|
| 6GK5648-2GS00-2AC2 | Siemens | Extended port count variant | Direct SCALANCE XC-200 family |
| 6GK5624-0GS00-2AC2 | Siemens | 24-port, fewer SFP slots | Same series, reduced uplink |
| FL SWITCH 2024 | Phoenix Contact | 24-port managed, DIN rail | Functional equivalent |
| EDS-G512E-8GSFP | Moxa | Gigabit SFP-focused design | Functional equivalent |
| RSG2100 | Hirschmann | Managed Gigabit switch | Functional equivalent |
Note: Always verify firmware, protocol support, and cabinet dimensions before substitution in live systems.
Why Choose the Original Model
- Native PROFINET IO integration with Siemens S7 PLCs and TIA Portal engineering
- MRP (Media Redundancy Protocol) for sub-200 ms ring recovery in critical processes
- ATEX Zone 2 certification for use in potentially explosive atmospheres
- Seamless SINEMA Remote Connect compatibility for remote diagnostics
- Long-term availability backed by Siemens industrial lifecycle policy
Typical Applications
- Factory automation and production line networking (automotive, food & beverage, pharma)
- Process control DCS backbone switching
- Power generation and utility SCADA networks
- Railway and transportation control systems
- Building automation and smart infrastructure
- Oil & gas field control panels (ATEX zones)
System Compatibility
- Siemens PLCs: S7-300, S7-400, S7-1200, S7-1500, ET 200SP
- Engineering Tools: TIA Portal V14+, STEP 7 V5.x, SINEMA Network Manager
- Protocols: PROFINET RT/IRT, Modbus TCP, EtherNet/IP (via gateway)
- Fiber SFP Modules: Compatible with standard 1000BASE-SX / 1000BASE-LX SFP transceivers
Selection Guide
Use the table below to select the right SCALANCE XC-200 variant for your project:
| Requirement | Recommended Model |
|---|---|
| 24 RJ45 + 4 SFP, AC power, standard temp | 6GK5646-2GS00-2AC2 ✓ This model |
| 24 RJ45 + 4 SFP, DC power (24 V) | 6GK5646-2GS00-2DC2 |
| 16-port, AC power | 6GK5616-0GS00-2AC2 |
| ATEX Zone 1 required | Consult Siemens SCALANCE XB-200 ATEX series |
| Budget alternative, non-PROFINET | Phoenix Contact FL SWITCH 2024 |
Quality Assurance & Sourcing
- ✅ Genuine units sourced from authorized Siemens distribution channels
- ✅ Full traceability — batch records and certificates of conformity available on request
- ✅ Pre-shipment inspection — functional test and visual check before dispatch
- ✅ Secure packaging — ESD-safe, anti-static foam, original or equivalent carton
- ✅ Export compliance — HS code classification and customs documentation provided
How to Order
- Click Add to Cart or Request a Quote above
- Specify required quantity and preferred delivery timeline
- Our team confirms stock availability and lead time within 24 hours
- Payment via T/T, PayPal, or trade credit (approved accounts)
- Dispatch from Xiamen, China — worldwide shipping via DHL / FedEx / sea freight
For urgent requirements or bulk orders (>10 units), contact us directly at support@konmask.com or +0086 19859288691.
Replacement & Compatibility FAQ
Q: Can the 6GK5646-2GS00-2AC2 replace an older SCALANCE X-200 switch?
A: In most cases yes — the XC-200 series is backward-compatible with X-200 at the port and PROFINET level, but verify MRP ring configuration and firmware version in TIA Portal before swapping.
Q: Is a third-party SFP module compatible?
A: Siemens recommends its own SFP modules; however, standard 1000BASE-SX/LX SFPs from reputable vendors typically work. Konmask can supply matched SFP pairs on request.
Q: What is the lead time for this part?
A: In-stock units ship within 1–3 business days. Out-of-stock lead time is typically 2–6 weeks depending on Siemens production schedule.
Q: Do you provide a warranty?
A: Yes — 12-month warranty against manufacturing defects. DOA (Dead on Arrival) units are replaced at no charge.
Q: Can I get a datasheet or GSDML file?
A: Yes, contact us and we will provide the official Siemens datasheet and GSDML file for TIA Portal integration.
