Industrial Motion Control Solution – Siemens 6SE7024-7FD84-1HH0 | MASTERDRIVES MC Series
Where This Product Is Used
The Siemens 6SE7024-7FD84-1HH0 is a high-performance AC drive controller from the MASTERDRIVES MC (Motion Control) series, engineered for demanding industrial environments where precise speed and torque regulation are critical. Typical deployment scenarios include:
- Conveyor & Material Handling Systems – Precise belt speed control in automotive assembly lines, logistics sorting centers, and packaging plants.
- Crane & Hoist Applications – Smooth acceleration/deceleration profiles for overhead cranes, gantry systems, and port equipment.
- Pump & Fan Drives – Energy-efficient variable-speed control in water treatment facilities, HVAC systems, and process plants.
- Machine Tool Spindle Drives – High dynamic response for CNC machining centers and grinding machines.
- Paper & Printing Machinery – Tension-controlled web drives requiring synchronized multi-axis coordination.
- Steel & Rolling Mill Drives – Robust torque control under heavy cyclic loads in metal processing lines.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number / SKU | 6SE7024-7FD84-1HH0 |
| Brand | Siemens |
| Series | SIMOVERT MASTERDRIVES MC (Motion Control) |
| Product Family | 6SE70 |
| Drive Type | AC Vector / Motion Control Drive |
| Rated Output Current | ~47 A (refer to datasheet for exact rating) |
| Power Range | ~22 kW / 30 HP (400 V class) |
| Input Voltage | 3-phase AC, 380–480 V ±10% |
| Output Frequency | 0–300 Hz |
| Control Mode | Vector Control (Sensorless & Encoder Feedback) |
| Communication | PROFIBUS DP (via -1HH0 option board) |
| Protection Class | IP20 |
| Cooling Method | Forced Air Cooling |
| Weight | ~5 kg |
| Compliance | CE, UL, cUL |
Why Engineers Specify This Model
- PROFIBUS DP Integration (1HH0 option) – Seamless integration into Siemens SIMATIC S7 PLC networks without additional gateways, reducing wiring complexity and commissioning time.
- High Dynamic Vector Control – Delivers fast torque response (<5 ms) essential for servo-like positioning in motion control applications.
- Modular Architecture – The 6SE70 platform supports hot-swappable option boards (encoder, fieldbus, I/O expansion), enabling field upgrades without drive replacement.
- Proven Reliability – MASTERDRIVES MC has an established track record in heavy industry since the 1990s, with extensive global service network support.
- Regenerative Braking Capability – Supports energy recovery to the DC bus, reducing braking resistor requirements in crane and hoist applications.
- Wide Ambient Temperature Range – Operates reliably from 0°C to 40°C (up to 55°C with derating), suitable for harsh plant environments.
Complete System Bill of Materials
For a complete MASTERDRIVES MC drive system, engineers typically specify the following companion components:
- Line Filter – Siemens 6SE7024 series EMC line filter (Class C2/C3)
- Line Reactor / Choke – 3% line reactor for harmonic mitigation
- Braking Resistor – External braking resistor module (if regenerative unit not used)
- Encoder Feedback Board – Siemens SBP (Speed/Position Board) for closed-loop vector control
- PROFIBUS Board – Included in -1HH0 suffix (CBP2 Communication Board)
- Output Filter / dU/dt Filter – For long motor cable runs (>50 m)
- Control Panel / PMU – Siemens Parameterization Unit for local commissioning
- Motor – Siemens SIMOTICS 1LA / 1PH series induction or servo motor
Compliance & Industry Standards
- CE Marking – Compliant with EU Low Voltage Directive (2014/35/EU) and EMC Directive (2014/30/EU)
- UL / cUL Listed – Recognized under UL 508C (Power Conversion Equipment)
- IEC 61800-3 – Adjustable Speed Electrical Power Drive Systems EMC standard
- IEC 61800-5-1 – Safety requirements for adjustable speed drive systems
- RoHS Compliant – Restriction of Hazardous Substances
Quality Assurance & Sourcing
At Konmask.com, every unit of the 6SE7024-7FD84-1HH0 undergoes a rigorous multi-point inspection process before shipment:
- ✅ Visual Inspection – PCB, connectors, and housing checked for physical damage or counterfeit indicators
- ✅ Functional Power-On Test – Drive powered up and parameter access verified
- ✅ Firmware Version Check – Firmware version documented and matched to product specification
- ✅ Serialization Verification – Serial number cross-referenced against Siemens product database where applicable
- ✅ Anti-Static Packaging – Shipped in ESD-safe bags with foam cushioning and double-box protection
We source from authorized distributors, OEM surplus channels, and verified industrial resellers. All units are sold with a 90-day replacement warranty.
How to Source This Part
- Add to Cart – Click “Add to Cart” above and proceed to checkout. We accept T/T bank transfer, PayPal, and major credit cards.
- Request a Quote – For bulk orders (>3 units) or project-based procurement, email support@konmask.com for volume pricing.
- Lead Time – In-stock units ship within 1–3 business days. Out-of-stock items: 7–21 business days sourcing lead time.
- Export Documentation – We provide commercial invoice, packing list, and CO (Certificate of Origin) for international customs clearance.
- Technical Support – Pre-sales engineering support available via email or WhatsApp: +0086 19859288691.
Application-Specific FAQ
Q: Can the 6SE7024-7FD84-1HH0 be used with a Siemens S7-300 PLC via PROFIBUS?
A: Yes. The -1HH0 suffix denotes the integrated CBP2 PROFIBUS DP communication board, enabling direct integration with S7-300/400 and S7-1500 systems using standard SIMOVERT drive function blocks (DFBs).
Q: What motor types are compatible with this drive?
A: The MASTERDRIVES MC supports standard asynchronous induction motors (1LA series) and synchronous servo motors (1FT/1FK series) with appropriate encoder feedback boards.
Q: Is this drive suitable for crane/hoist duty cycles?
A: Yes. The drive supports S3/S4 duty cycle ratings and includes integrated brake control logic, making it well-suited for hoist and crane applications.
Q: What is the difference between MASTERDRIVES MC and MASTERDRIVES VC?
A: MC (Motion Control) variants offer higher dynamic performance, encoder feedback support, and positioning functions. VC (Vector Control) variants are optimized for standard variable-speed pump/fan/conveyor applications without positioning requirements.
Q: Can I replace a faulty 6SE7024-7FD84-1HH0 without re-parameterizing?
A: Yes, if you use the Siemens PMU or DriveMonitor to back up parameters to a memory card or PC beforehand. Parameters can be restored to the replacement unit in minutes.
