SIEMENS 6SE7034-6EC85-0JA0 – High-Power Inverter Drive Module | SIMOVERT MASTERDRIVES
Engineering Background
The SIEMENS 6SE7034-6EC85-0JA0 is a high-power inverter drive module from the SIMOVERT MASTERDRIVES platform — Siemens’ flagship modular AC drive series engineered for demanding industrial motion control applications. Designed for procurement engineers and system integrators who require a proven, scalable, and field-reliable power conversion solution, this module delivers precise variable-speed control for three-phase AC motors in heavy-duty environments.
Product Positioning
This unit is a compact inverter module (not a standalone drive) intended for integration into Siemens SIMOVERT MASTERDRIVES cabinet systems. It is optimized for high-cycle, continuous-duty applications where thermal stability, harmonic performance, and long MTBF are non-negotiable. Konmask.com supplies this module as a genuine, tested, and traceable component to industrial OEMs, system integrators, and MRO procurement teams globally.
Complete Technical Specifications
| Part Number / SKU | 6SE7034-6EC85-0JA0 |
| Manufacturer | Siemens AG |
| Product Series | SIMOVERT MASTERDRIVES (6SE70) |
| Module Type | Inverter Drive Module (Compact Plus) |
| Output Power | ~160 kW (refer to Siemens datasheet for exact rating) |
| Input Voltage | 3-phase AC, 380–480 V (±10%) |
| Output Voltage | 0 – Input Voltage (3-phase AC) |
| Output Frequency | 0 – 300 Hz |
| Control Method | Vector Control / V/f Control (selectable) |
| Cooling Method | Forced air cooling (internal fan) |
| Protection Class | IP20 |
| Communication Interface | PROFIBUS DP (via CBP2 option board) |
| Weight | 8.5 kg |
| Compliance | CE, UL (refer to nameplate) |
| Operating Temperature | 0°C to +40°C (derating above 40°C) |
| Storage Temperature | -25°C to +70°C |
| Humidity | ≤ 95% RH, non-condensing |
| Altitude | Up to 1000 m (derating above) |
Proven Application Environments
- Steel & Metal Processing: Rolling mills, coilers, and tension control systems requiring precise torque regulation
- Paper & Printing: Web tension control and winder/unwinder drives
- Crane & Hoist Systems: High-dynamic hoisting with regenerative braking capability
- Pump & Fan Drives: Large-scale HVAC and process pump variable-speed control
- Extruder & Compressor Drives: Continuous-duty high-torque applications in plastics and chemical processing
- Marine & Offshore: Thruster and winch drive systems in harsh environments
- Power Generation: Auxiliary drive systems in power plants and substations
Engineering Advantages
- Modular Architecture: Plug-in module design enables rapid replacement without full drive cabinet disassembly — minimizing downtime
- High Overload Capacity: Supports 150% overload for 60 seconds, suitable for demanding start-up torque requirements
- Advanced Vector Control: Sensorless and encoder-based closed-loop control for precise speed and torque regulation
- Integrated DC Bus: Supports energy sharing between multiple inverter modules on a common DC bus — improving system efficiency
- Comprehensive Diagnostics: Built-in fault logging, parameter memory, and PROFIBUS DP communication for seamless SCADA/DCS integration
- Long Service Life: Industrial-grade IGBT modules with proven field reliability across 20+ years of global installations
System Architecture & Signal Flow
The 6SE7034-6EC85-0JA0 operates as the inverter stage within a SIMOVERT MASTERDRIVES system. The typical signal and power flow is:
- AC Mains Input → Rectifier/Active Front End (AFE) module converts to DC bus voltage
- DC Bus → 6SE7034-6EC85-0JA0 inverter module receives DC power
- IGBT Switching → PWM-controlled IGBT bridge synthesizes variable-frequency, variable-voltage AC output
- Motor Output → Three-phase AC output drives the connected induction or synchronous motor
- Control Interface → CU (Control Unit) communicates via fiber optic or PROFIBUS DP for speed/torque setpoints and feedback
This modular topology allows independent replacement of the inverter module without disturbing the rectifier, control unit, or other drive modules sharing the same DC bus.
Sourcing & Quality Verification
- Origin: Genuine Siemens-manufactured module; sourced through authorized industrial supply channels
- Condition: New / Refurbished / Tested — please confirm with our technical team at time of inquiry
- Traceability: Each unit includes manufacturer serial number and production date code for full supply chain traceability
- Pre-shipment Testing: Functional power-on test and insulation resistance check performed before dispatch
- Packaging: Anti-static ESD packaging with foam cushioning; export-grade carton for international shipment
- Warranty: 12-month warranty against manufacturing defects from date of shipment
Procurement Process
- Submit Inquiry: Contact support@konmask.com or call +0086 19859288691 with your required quantity and delivery timeline
- Technical Confirmation: Our engineering team verifies compatibility with your existing SIMOVERT MASTERDRIVES system configuration
- Quotation & Lead Time: Formal quotation issued within 24 hours; typical lead time 3–7 business days for in-stock units
- Order Placement: Purchase order accepted via email; payment terms available for qualified accounts
- Shipment & Documentation: DHL / FedEx / sea freight with full commercial invoice, packing list, and certificate of origin
- After-Sales Support: Technical commissioning support available via email and video call
Technical FAQ
Q: Is the 6SE7034-6EC85-0JA0 a standalone drive or a module?
A: It is an inverter module designed for integration into a SIMOVERT MASTERDRIVES cabinet system. It requires a compatible rectifier/AFE module, control unit (CU), and DC bus infrastructure to operate.
Q: What control unit (CU) is compatible with this module?
A: This module is compatible with Siemens SIMOVERT MASTERDRIVES CU series control units, including the CU3 and VC (Vector Control) variants. Please consult the Siemens SIMOVERT MASTERDRIVES configuration manual (Order No. 6SE7087-6QX70) for exact pairing.
Q: Can this module be used with a third-party rectifier?
A: Not recommended. The DC bus voltage and communication protocols are optimized for Siemens SIMOVERT MASTERDRIVES rectifier modules. Third-party rectifiers may cause compatibility and safety issues.
Q: What is the replacement procedure for a failed module?
A: Isolate the DC bus, discharge capacitors per Siemens safety procedure, disconnect fiber optic and power connections, slide out the module, insert the replacement, and recommission via the CU parameter set. Full procedure is documented in Siemens Service Manual 6SE7087-6CX87-2DA0.
Q: Does Konmask.com provide commissioning support?
A: Yes. Our technical team provides remote commissioning guidance via email and video call. On-site support can be arranged for large-scale projects.
