Industrial Drive Infeed Solution – SIEMENS 6SL3100-0BE23-6AB0 | SINAMICS S120
Where This Product Is Used
The SIEMENS 6SL3100-0BE23-6AB0 Smart Line Module is a regenerative infeed unit within the SINAMICS S120 drive system, designed for demanding industrial environments where energy recovery and precise DC bus management are critical. Typical deployment scenarios include:
- CNC Machining Centers – Provides stable DC bus voltage for multi-axis servo drives in high-precision milling, turning, and grinding machines.
- Industrial Robotics – Supplies clean, regulated power to robot arm servo axes, enabling fast acceleration and deceleration cycles with regenerative braking energy fed back to the grid.
- Printing & Packaging Machinery – Maintains consistent infeed power across multiple Motor Modules in high-speed web-tension and registration control systems.
- Plastics & Extrusion Lines – Supports coordinated multi-drive architectures where shared DC bus topology reduces cabinet footprint and energy consumption.
- Crane & Hoist Systems – Enables regenerative energy return during lowering operations, reducing net energy cost in heavy-lift applications.
- Test Bench & Dynamometer Systems – Delivers bidirectional power flow for motor-load simulation and endurance testing rigs.
Technical Specifications
| Part Number | 6SL3100-0BE23-6AB0 |
| Series | SINAMICS S120 |
| Module Type | Smart Line Module (SLM) |
| Rated Input Voltage | 3-phase AC 380–480 V (±10%) |
| Rated Input Current | 36 A |
| Rated Active Power | 36 kW |
| DC Bus Voltage | ~600–720 V DC |
| Input Frequency | 47–63 Hz |
| Cooling Method | Internal air cooling (push-through available) |
| Protection Class | IP20 |
| Ambient Temperature | 0 °C to +40 °C (derating above 40 °C) |
| Weight | approx. 7.5 kg |
| Communication Interface | DRIVE-CLiQ |
| Manufacturer | SIEMENS AG, Germany |
Why Engineers Specify This Model
- Regenerative Capability – Unlike Basic Line Modules, the Smart Line Module feeds braking energy back to the supply grid, reducing net energy consumption by up to 30% in cyclic applications.
- Active Front End (AFE) – Near-unity power factor and low harmonic distortion (THDi < 5%) eliminate the need for additional line reactors or harmonic filters in most installations.
- DRIVE-CLiQ Integration – Seamless plug-and-play commissioning with SIMATIC S7 / SINUMERIK CNC controllers via the DRIVE-CLiQ topology, reducing wiring complexity.
- Shared DC Bus Architecture – Multiple Motor Modules can share a single SLM, optimizing cabinet space and reducing total system cost.
- Automatic Firmware Recognition – The module self-identifies to STARTER / TIA Portal, accelerating project commissioning timelines.
Complete System Bill of Materials
For a fully operational SINAMICS S120 drive cabinet using this Smart Line Module, engineers typically specify:
- 6SL3100-0BE23-6AB0 – Smart Line Module (this unit)
- 6SL3040-1MA01-0AA0 – SINAMICS S120 Control Unit CU320-2 DP
- 6SL3120-1TE21-0AA3 – Single Motor Module (per axis)
- 6SL3000-0BE23-6AA0 – Line Filter Class C2 (36 A)
- 6SL3000-0CE23-6AA0 – Line Reactor (36 A)
- 6FX2002-1DC00-0AA0 – DRIVE-CLiQ Cable (topology connection)
- 6SL3162-2MA00-0AA0 – Braking Module (optional, for emergency stop)
Compliance & Industry Standards
- CE Marked – Compliant with EU Low Voltage Directive 2014/35/EU and EMC Directive 2014/30/EU
- UL Listed – Recognized under UL 508C (Power Conversion Equipment)
- IEC 61800-5-1 – Safety requirements for adjustable speed electrical power drive systems
- IEC 61800-3 – EMC requirements, Category C2
- RoHS Compliant – Restriction of Hazardous Substances Directive 2011/65/EU
Quality Assurance & Sourcing
Konmask.com sources SIEMENS automation components through verified industrial distribution channels. Each unit undergoes the following before dispatch:
- Visual inspection for physical damage, label integrity, and seal verification
- Firmware version check against SIEMENS product lifecycle records
- Functional power-on test where applicable
- Anti-static packaging with humidity indicator card
- Traceability documentation available upon request (batch/lot records)
How to Source This Part
To place an order or request a quotation for the SIEMENS 6SL3100-0BE23-6AB0:
- Online: Add to cart directly on this page for standard lead times.
- Bulk / Project Orders: Contact our engineering sales team for volume pricing and project-specific lead time commitments.
- Urgent Requirements: Indicate your required delivery date at checkout — we will confirm availability within 1 business day.
- Email: support@konmask.com
- Phone / WhatsApp: +0086 19859288691
Application-Specific FAQ
Q: Can the 6SL3100-0BE23-6AB0 operate on a 480 V supply?
A: Yes. The Smart Line Module accepts 3-phase AC 380–480 V (±10%), making it compatible with both European 400 V and North American 480 V industrial supplies.
Q: Does this module require a separate line reactor?
A: SIEMENS recommends a line reactor (e.g., 6SL3000-0CE23-6AA0) for installations where supply impedance is below 1%. For most industrial supplies, the internal inductance of the AFE is sufficient.
Q: How many Motor Modules can share this Smart Line Module?
A: The total connected Motor Module power must not exceed the SLM rated active power of 36 kW. The number of axes depends on individual motor ratings and duty cycles.
Q: Is this module compatible with SINUMERIK 840D sl?
A: Yes. The 6SL3100-0BE23-6AB0 is fully compatible with SINUMERIK 840D sl CNC systems via DRIVE-CLiQ and is a standard infeed choice for multi-axis CNC machining centers.
Q: What is the warranty on this product?
A: Konmask.com provides a 12-month warranty against manufacturing defects. Extended warranty and on-site support options are available — contact us for details.
