SIEMENS 6SN1145-1BA01-0BA1 Feedback Module | Replacement, Equivalent & Selection Guide
The SIEMENS 6SN1145-1BA01-0BA1 is a feedback module designed for the SIMODRIVE 611 drive system, providing encoder signal processing and closed-loop position feedback for high-precision CNC and servo applications. This page serves as a comprehensive selection, replacement, and compatibility reference for engineers and procurement teams.
Technical Specifications
- Part Number: 6SN1145-1BA01-0BA1
- Manufacturer: SIEMENS
- Series: SIMODRIVE 611
- Module Type: Feedback / Encoder Interface Module
- Encoder Interface: Incremental / TTL encoder input
- Supply Voltage: 24 V DC (via drive bus)
- Weight: approx. 2,400 g
- Mounting: DIN rail / drive rack integrated
- Protection Class: IP20
- Operating Temperature: 0 °C to +55 °C
- Standards: CE, UL
Compatible Replacement & Equivalent Models
The following models are commonly evaluated as replacements or equivalents. Always verify electrical and mechanical compatibility before substitution:
- 6SN1145-1BA02-0BA1 — Upgraded revision with extended encoder support
- 6SN1145-1BA00-0BA1 — Earlier revision, functionally similar
- 6SN1118-0DM31-0AA1 — SIMODRIVE 611 control module with integrated feedback
- 6SN1145-1AA01-0AA1 — Single-axis feedback variant
- Third-party compatible feedback modules for SIMODRIVE 611 (consult Konmask for verified alternatives)
Note: Replacement compatibility depends on firmware version, drive configuration, and encoder type. Contact our technical team for confirmation.
Why Choose the Original Model
- Factory-tested and certified for SIMODRIVE 611 drive systems
- Guaranteed signal integrity and EMC compliance
- Full traceability and SIEMENS quality assurance
- Seamless integration with SINUMERIK CNC controllers
- Long-term spare parts availability through authorized channels
Typical Applications
- CNC machining centers (milling, turning, grinding)
- Industrial servo drive systems
- Automated production lines requiring closed-loop position control
- Retrofit and upgrade projects for legacy SIMODRIVE 611 installations
- High-precision motion control in automotive and aerospace manufacturing
System Compatibility
- Drive System: SIEMENS SIMODRIVE 611 (analog and digital variants)
- CNC Controllers: SINUMERIK 840D, 810D, 802D
- Encoder Types: Incremental TTL, sin/cos 1 Vpp (verify per revision)
- Motor Series: 1FT6, 1FK6, 1PH7 SIEMENS servo/spindle motors
- Bus Interface: SIMODRIVE 611 internal drive bus
Selection Guide
Use the following criteria to select the correct feedback module for your application:
- Step 1 — Identify encoder type: TTL incremental, sin/cos, or absolute (EnDat/SSI)
- Step 2 — Check axis count: Single-axis (1BA) vs. dual-axis configurations
- Step 3 — Verify revision suffix: -0BA1 suffix indicates specific hardware revision; confirm with drive documentation
- Step 4 — Match CNC controller: Ensure compatibility with your SINUMERIK version
- Step 5 — Confirm power supply: Module is bus-powered; no external 24 V required in standard configurations
Not sure which model fits your system? Contact our engineers with your drive order number and motor nameplate data.
Quality Assurance & Sourcing
- All units sourced from verified industrial supply channels
- Pre-shipment functional inspection and visual QC
- Original packaging preserved where available
- Batch traceability records maintained
- Warranty: 12 months from date of shipment
- Returns accepted within 30 days for unused, uninstalled units
How to Order
- Add the 6SN1145-1BA01-0BA1 to your cart, or contact us for bulk/project pricing
- Provide your application details (drive type, CNC model, encoder specs) for technical confirmation
- Receive order confirmation and lead-time estimate within 1 business day
- Shipping via DHL / FedEx / SF Express — worldwide delivery available
📧 support@konmask.com | 📞 +0086 19859288691
Replacement & Compatibility FAQ
Q: Can I use 6SN1145-1BA02-0BA1 as a direct replacement for 6SN1145-1BA01-0BA1?
A: In most cases yes, as the -1BA02 is a later revision with backward compatibility. However, always verify with your drive commissioning documentation or contact us.
Q: Is this module compatible with SINUMERIK 840Di?
A: The 840Di uses a different drive interface (PROFIBUS-based). This module is designed for the analog/digital SIMODRIVE 611 platform. Please consult us for 840Di-compatible alternatives.
Q: Do you supply refurbished units?
A: We supply both new and professionally refurbished units. Refurbished units are clearly labeled and carry a 6-month warranty.
Q: What is the lead time for this part?
A: In-stock units ship within 1–3 business days. Out-of-stock items typically have a 2–4 week lead time. Contact us for real-time availability.
Q: Can Konmask provide a cross-reference for other brands?
A: Yes. We maintain cross-reference databases for major drive brands. Contact our team with your current part number for a verified equivalent recommendation.
