SIEMENS A5E00768956 Inverter Trigger Board – SINAMICS / MICROMASTER Series Drive Control Module
When a critical inverter trigger board fails on the production floor, the consequences are immediate and severe: variable-frequency drives lose gate-signal control, motor outputs become erratic or completely shut down, and entire production lines grind to a halt. In process-critical industries — from automotive stamping to chemical dosing — even minutes of unplanned downtime translate into thousands of dollars in lost output. The SIEMENS A5E00768956 Inverter Trigger Board is the precision firing-control component that keeps your drive’s IGBT power stage synchronized, protected, and performing within specification. Without it, there is no reliable motor control.
The A5E00768956 occupies a key position within the SIEMENS SINAMICS and MICROMASTER drive family as the dedicated gate-driver and trigger interface board. Engineered to Siemens’ stringent IEC and UL industrial standards, this board is deployed globally across manufacturing, energy, water treatment, and material-handling applications. Its design ensures precise PWM signal distribution to the IGBT bridge, robust isolation between control and power circuits, and built-in fault-detection logic that protects the entire drive investment. As a genuine Siemens spare part, it is the benchmark replacement component trusted by OEM service engineers and plant maintenance teams worldwide.
Technical Specifications
- Part Number: A5E00768956
- Manufacturer: SIEMENS AG
- Component Type: Inverter Trigger Board (Gate Driver / Firing Board)
- Compatible Drive Series: SINAMICS / MICROMASTER (confirm exact frame size with your drive nameplate)
- Function: PWM gate-signal generation and distribution to IGBT power modules
- Isolation: Galvanic isolation between control-side logic and power-side gate outputs
- Weight: 69 g
- Condition: New / Refurbished (specify at inquiry)
- Origin: Siemens-authorized supply chain
Note: All specifications are based on Siemens published documentation. Do not rely on this page alone for engineering design decisions — always cross-reference the official Siemens drive service manual for your specific drive frame.
Key Features & Benefits
- Precision Gate Triggering: Delivers accurate, low-jitter PWM signals to each IGBT in the power bridge, ensuring smooth motor torque and minimal harmonic distortion.
- Robust Galvanic Isolation: Protects the low-voltage control logic from high-voltage transients on the power side, extending the life of the entire drive system.
- Integrated Fault Detection: On-board desaturation and short-circuit detection logic trips the drive safely before catastrophic IGBT failure, protecting your motor and mechanical load.
- Drop-in Replacement: Designed as a direct OEM replacement — no firmware changes or parameter re-entry required in most applications.
- Industrial-Grade Reliability: Manufactured to Siemens’ quality standards for continuous-duty industrial environments with wide temperature tolerance.
- Reduced Downtime: Stocking this board as a critical spare eliminates multi-week lead times for emergency procurement, keeping MTTR (Mean Time To Repair) low.
Industry & Equipment Applications
- Automotive Manufacturing: Conveyor drives, robotic welding positioners, stamping press feed systems
- Chemical & Petrochemical: Pump and compressor VFD control, agitator drives
- Water & Wastewater Treatment: Variable-speed pump stations, blower drives
- Food & Beverage: Mixer drives, bottling line conveyors, packaging machinery
- Material Handling & Logistics: Crane hoists, overhead conveyor systems, automated storage and retrieval (AS/RS)
- HVAC & Building Automation: Fan and chiller pump drives in large commercial facilities
- Mining & Minerals: Belt conveyor drives, crusher feed systems
System Integration & Compatible Parts
The A5E00768956 trigger board works within the broader SIEMENS drive control architecture. When servicing a drive that requires this board, consider also inspecting or stocking the following related components:
- IGBT Power Modules (matched to your drive frame size)
- SINAMICS / MICROMASTER Control Unit (CU) boards
- DC Bus capacitor banks
- Gate resistor networks
- Drive cooling fans and thermal interface materials
Contact our technical team at support@konmask.com to confirm compatibility with your specific drive model and firmware version before ordering.
Our Quality Assurance Process
At Konmask.com, every industrial automation component goes through a structured sourcing and verification process before it reaches you:
- Authorized Supply Chain: We source from verified distributors and Siemens-authorized channels to minimize counterfeit risk.
- Visual & Functional Inspection: Each board is inspected for physical damage, solder joint integrity, and component presence before dispatch.
- Traceability: Batch and date codes are recorded for full supply-chain traceability.
- Secure Packaging: ESD-safe anti-static packaging with foam cushioning protects the board during international transit.
- Documentation: Certificate of conformity and packing list provided with every shipment.
How to Order
- Submit an Inquiry: Email support@konmask.com or call +0086 19859288691 with your part number (A5E00768956), required quantity, and delivery destination.
- Receive a Quote: Our team will respond within 1 business day with pricing, lead time, and shipping options tailored to your location.
- Confirm & Pay: We support T/T bank transfer, PayPal, and other B2B payment methods. A proforma invoice is issued upon order confirmation.
- Shipment & Tracking: Orders are dispatched via DHL, FedEx, or UPS Express with full tracking. Export documentation (commercial invoice, packing list) is included.
- After-Sales Support: Our technical team remains available post-delivery to assist with installation questions or warranty claims.
Why Choose Konmask.com?
- Industrial Automation Specialists: We focus exclusively on PLC, DCS, VFD, and drive components — not a generalist marketplace.
- Global B2B Export Experience: We ship to over 50 countries with full export documentation and customs support.
- Fast Response: Inquiry-to-quote in under 24 hours for stocked items.
- Technical Expertise: Our team includes engineers with hands-on experience in Siemens drive systems — we speak your language.
- Competitive Pricing: Direct sourcing relationships allow us to offer market-competitive pricing without compromising authenticity.
- Long-Term Partnership: We support MRO teams, system integrators, and OEM service departments with ongoing supply agreements.
Frequently Asked Questions
- Q: Is the A5E00768956 a genuine Siemens part?
- A: Yes. We source from authorized distribution channels. Please request a certificate of conformity if required for your procurement process.
- Q: Which specific drive models is this board compatible with?
- A: The A5E00768956 is used in specific SINAMICS and MICROMASTER drive frames. Please share your drive’s full nameplate data (model, frame size, firmware version) when submitting your inquiry so we can confirm compatibility.
- Q: Do you offer refurbished units?
- A: Yes, both new and professionally refurbished units may be available depending on stock. Refurbished units are tested and carry a warranty — please specify your preference in your inquiry.
- Q: What is the lead time?
- A: Lead time depends on stock availability. In-stock items typically ship within 2–3 business days. Please contact us for current availability.
- Q: Can you provide export documentation for customs clearance?
- A: Yes. We provide a commercial invoice, packing list, and certificate of origin with every international shipment.
