CNC Machine Tool Programming Solution – Siemens A5E39206479 | SINUMERIK Teach Screen
Where This Product Is Used
The Siemens A5E39206479 Teach Screen is a dedicated human-machine interface (HMI) panel engineered for CNC machine tool environments. It is widely deployed in the following industrial applications:
- CNC Turning & Milling Centers — Operator guidance, tool offset input, and program step-through during setup and first-article inspection.
- Machining Centers & Grinding Machines — Teach-in programming for repetitive motion paths, reducing reliance on G-code for skilled operators.
- Automotive Body & Powertrain Lines — Inline machine tool HMI for high-volume production cells requiring fast operator changeover.
- Aerospace Precision Machining — Controlled axis jogging and program verification on 5-axis machining centers.
- Die & Mold Shops — Manual data input (MDI) and teach-in routines for complex contour machining.
- OEM Machine Builders — Integrated as the primary operator panel in new SINUMERIK-based machine builds.
Technical Specifications
| Part Number | A5E39206479 |
| Brand | Siemens |
| Series | SINUMERIK |
| Product Type | Teach Screen / CNC HMI Operator Panel |
| Compatible Systems | SINUMERIK 808D, 828D, 840D sl |
| Interface | USB / PROFIBUS / Ethernet (model-dependent) |
| Protection Rating | IP65 front panel (typical for SINUMERIK HMI) |
| Operating Temperature | 0 °C to +55 °C |
| Storage Temperature | -20 °C to +70 °C |
| Supply Voltage | 24 V DC (nominal) |
| Country of Origin | Germany |
| Condition | New / Surplus / Refurbished (specify at inquiry) |
Note: Confirm exact electrical and mechanical specifications against your SINUMERIK system documentation before installation.
Why Engineers Specify This Model
- Teach-In Simplicity — Allows operators to record axis positions by physically jogging the machine, eliminating manual coordinate entry errors during setup.
- Rugged Industrial Design — Sealed front panel withstands coolant splash, metal chips, and continuous shift operation in harsh shop-floor environments.
- Seamless SINUMERIK Integration — Plug-and-play compatibility with the SINUMERIK ecosystem; no additional driver configuration required on supported CNC generations.
- Ergonomic Operator Interface — Clearly labeled function keys and intuitive layout reduce training time and operator error during machine setup.
- Long Product Lifecycle — Siemens SINUMERIK components are supported for extended periods, protecting capital investment in machine tool infrastructure.
- Compact Form Factor — Designed for panel-mount or handheld use, adaptable to both fixed operator stations and mobile pendant configurations.
Complete System Bill of Materials
For a complete SINUMERIK CNC operator station, engineers typically specify the following alongside the A5E39206479:
- SINUMERIK CNC Controller Unit (e.g., 828D PPU / 840D sl NCU)
- Siemens SINAMICS Drive Module (S120 series)
- Machine Control Panel (MCP) — e.g., A5E34446952
- Handheld Unit (HHU) Cable Assembly
- 24 V DC Power Supply (SITOP series recommended)
- Profibus / PROFINET communication cable
- Emergency Stop Button Module (safety-rated)
Contact support@konmask.com for bundled BOM sourcing and volume pricing.
Compliance & Industry Standards
- CE Marking — Compliant with EU Machinery Directive and EMC Directive.
- UL / cUL Listed — Recognized for North American industrial control applications (verify specific listing on product nameplate).
- IEC 61131 — Compatible with IEC-standard CNC programming environments.
- RoHS Compliant — Meets EU Restriction of Hazardous Substances requirements.
- ISO 9001 — Manufactured under Siemens’ certified quality management system.
Quality Assurance & Sourcing
All Siemens components supplied by Konmask.com are sourced through verified industrial distribution channels. Our quality process includes:
- Visual inspection and packaging integrity check upon receipt
- Cross-reference verification of part number, revision, and date code
- Anti-static handling and climate-controlled storage
- Traceability documentation available upon request
- 30-day return policy for unused, unopened items in original packaging
We do not supply counterfeit or unauthorized clone products. All items ship with original manufacturer packaging where available.
How to Source This Part
- Add to Cart — Place your order directly on this page for in-stock units.
- Request a Quote — Email support@konmask.com for volume orders, lead-time confirmation, or alternative condition grades.
- Urgent Requirements — Call or WhatsApp +0086 19859288691 for same-day response on critical machine-down situations.
- Export & Customs — We support international shipments with full commercial invoice, packing list, and HS code documentation for customs clearance.
Application-Specific FAQ
Q: Is the A5E39206479 compatible with SINUMERIK 840D sl?
A: Yes, the A5E39206479 Teach Screen is designed for use within the SINUMERIK product family. Confirm compatibility with your specific NCU firmware version before installation.
Q: Can this teach screen be used as a handheld pendant?
A: The A5E39206479 is configured as a teach screen panel. For handheld pendant applications, verify the cable assembly and enabling switch requirements with your machine builder documentation.
Q: What is the lead time for this part?
A: In-stock units ship within 1–3 business days. For out-of-stock or special-condition requests, contact us for a confirmed lead time.
Q: Do you provide a warranty?
A: Yes. New units carry the original Siemens manufacturer warranty. Surplus and refurbished units include a Konmask 90-day functional warranty. Contact us for details.
Q: Can you supply the full SINUMERIK operator panel assembly?
A: Yes. We can source complete operator panel assemblies including MCP, HMI, and cabling. Submit your BOM to support@konmask.com for a consolidated quote.
