SMC VV5Q11-10-X3105V Pneumatic Manifold – VV5Q11 Series Multi-Station Valve Manifold
When a pneumatic manifold fails mid-production, the consequences are immediate and costly: solenoid valves lose their shared air supply, actuators freeze in position, and entire automated lines grind to a halt. In high-throughput manufacturing environments — automotive assembly, semiconductor fabrication, food packaging — even minutes of unplanned downtime translate directly into scrapped product, missed delivery windows, and emergency maintenance costs. The SMC VV5Q11-10-X3105V is the precision-engineered solution that keeps these systems running without interruption.
Within SMC’s globally trusted VV5Q11 series, the VV5Q11-10-X3105V occupies a critical mid-range position: a 10-station manifold block designed for high-density valve integration with the X3105V special specification variant, optimized for demanding cycle environments. SMC Corporation, headquartered in Tokyo and operating in 83 countries, is the world’s largest pneumatics manufacturer by market share. The VV5Q11 series represents their flagship modular manifold platform, widely adopted across automotive OEMs, electronics manufacturers, and process industries worldwide.
Technical Specifications
- Part Numbers / SKU: 4060-00949 / VV5Q11-10-X3105V / UT-CNN-01 / H1001426001A / 3620-00122 / CDN127-1
- Brand: SMC Corporation
- Series: VV5Q11 — Modular Manifold for SQ Series Solenoid Valves
- Station Count: 10 stations
- Special Specification: X3105V
- Manifold Type: Multi-station pneumatic valve manifold
- Compatible Valve Series: SMC SQ Series (SQ1000 / SQ2000)
- Weight: 2,600 g
- Condition: New / Surplus / Refurbished (specify on inquiry)
Note: All specifications are based on SMC official documentation. Do not rely solely on this listing for engineering design — always verify with the official SMC datasheet for your application.
Key Features & Benefits
- 10-Station Modular Design: Consolidates up to 10 solenoid valves onto a single manifold block, dramatically reducing piping complexity and installation footprint.
- X3105V Special Specification: Engineered for specific environmental or performance requirements beyond the standard VV5Q11 baseline — consult Konmask for full spec details.
- Centralized Air Supply: Single inlet port supplies all stations simultaneously, simplifying pneumatic circuit design and reducing leak points.
- High Cycle Durability: Built to SMC’s rigorous quality standards for millions of switching cycles in continuous industrial operation.
- Plug-and-Play Compatibility: Direct mounting interface for SMC SQ series valves — no adapters required.
- Compact Footprint: High station density per unit length minimizes panel space consumption in control cabinets and machine frames.
- Individual Station Exhaust: Supports independent exhaust per station for precise speed control of each actuator.
Industry & Equipment Applications
- Automotive Manufacturing: Body welding lines, paint shop conveyors, engine assembly fixtures
- Semiconductor & Electronics: Wafer handling robots, PCB assembly machines, chip packaging equipment
- Food & Beverage Packaging: Filling machines, capping stations, labeling systems
- Pharmaceutical: Blister packaging lines, tablet press machines, sterile filling systems
- General Industrial Automation: Pick-and-place systems, conveyor diverters, clamping fixtures
- Machine Tool: CNC machining centers, tool changers, coolant control systems
System Integration & Compatible Parts
The VV5Q11-10-X3105V is designed for seamless integration within SMC’s SQ series pneumatic ecosystem. Compatible and commonly paired components include:
- Solenoid Valves: SMC SQ1000 series, SQ2000 series (5/2-way, 5/3-way)
- End Plates: SMC VV5Q11 series end plates (D-sub connector, flat ribbon cable, or individual lead wire types)
- Blanking Plates: For unused stations on the manifold block
- Pressure Gauges & Regulators: SMC AR/AW series for supply pressure management
- Silencers: SMC AN series for exhaust noise reduction
- Fieldbus Connectors: EX series SI units for DeviceNet, PROFIBUS, EtherNet/IP integration
Contact Konmask.com to confirm compatibility with your existing SMC manifold system or to source complete valve island assemblies.
Our Quality Assurance Process
At Konmask.com, every SMC component undergoes a structured verification process before shipment:
- Part Number Cross-Verification: All cross-reference SKUs (4060-00949, UT-CNN-01, H1001426001A, 3620-00122, CDN127-1) are validated against SMC’s official part numbering system.
- Physical Inspection: Visual inspection for port integrity, manifold body condition, and mounting surface flatness.
- Documentation: Original SMC packaging, labels, and certificates of conformance provided where available.
- Traceability: Batch and lot tracking maintained for all stocked components.
- Secure Packaging: Anti-static and moisture-resistant packaging for international freight.
How to Order
- Submit an Inquiry: Use the contact form or email [email protected] with your required quantity and delivery timeline.
- Receive a Quote: Our team will respond within 1 business day with pricing, lead time, and availability confirmation.
- Order Confirmation: Confirm your purchase order with delivery address and preferred shipping method.
- Shipment & Tracking: We ship globally via DHL, FedEx, UPS, and sea freight. Tracking number provided upon dispatch.
- After-Sales Support: Technical support available post-delivery for installation and integration questions.
Why Choose Konmask.com?
- ✅ Industrial Automation Specialists: Focused exclusively on PLC, DCS, pneumatics, and automation components — not a generalist marketplace.
- ✅ Global Sourcing Network: Access to genuine SMC components from authorized distribution channels worldwide.
- ✅ B2B Inquiry-First Model: We work with procurement teams, MRO buyers, and OEM engineers — not just retail customers.
- ✅ Fast Response: Dedicated account managers respond to all technical inquiries within 24 hours.
- ✅ Competitive Pricing: Volume discounts available for project-based and blanket order requirements.
- ✅ Export Expertise: Experienced in international trade documentation, customs compliance, and multi-country delivery.
Frequently Asked Questions
Q: What is the difference between VV5Q11-10-X3105V and the standard VV5Q11-10?
A: The X3105V suffix denotes a special specification variant from SMC, typically indicating a customized port configuration, material specification, or environmental rating. Contact us with your application details for clarification.
Q: Can I add or remove stations from this manifold?
A: The VV5Q11 series is modular by design. However, the 10-station block (VV5Q11-10) is a fixed-station manifold. For expandable configurations, SMC offers the VV5Q11 series in various station counts. Contact Konmask for alternatives.
Q: What solenoid valves are compatible with this manifold?
A: This manifold is designed for SMC’s SQ series solenoid valves (SQ1000 and SQ2000 series). Always verify valve body size and port pitch compatibility before ordering.
Q: Do you provide the original SMC datasheet with the product?
A: We provide available documentation upon request. For the official SMC product datasheet, we recommend also consulting SMC’s official website or your local SMC distributor.
Q: What is the lead time for this part?
A: Lead time depends on current stock status. Submit an inquiry at Konmask.com and we will confirm availability and estimated delivery within 1 business day.
Q: Do you ship internationally?
A: Yes. Konmask.com ships globally via major international couriers (DHL, FedEx, UPS) and sea freight for bulk orders. We handle all export documentation.
