Precision Motion Control Solution — Yaskawa SGMJV-01ADA6C + VLAST60-06-0700 | Sigma-V Series
Where This Product Is Used
The Yaskawa SGMJV-01ADA6C servo motor combined with the VLAST60-06-0700 servo drive is engineered for high-precision, high-cycle industrial applications. Typical deployment environments include:
- CNC Machining Centers — Axis feed drives requiring sub-micron positioning repeatability
- Industrial Robotics — Joint actuators in articulated and SCARA robot arms
- Semiconductor & Electronics Assembly — Pick-and-place, die bonding, and wafer handling stages
- Packaging Machinery — High-speed indexing, filling, and sealing lines
- Printing & Converting Equipment — Register control and web tension management
- Medical Device Manufacturing — Precision dispensing and surgical tool assembly
- Textile Machinery — Yarn tension control and loom positioning
Technical Specifications
| Parameter | Value |
|---|---|
| Manufacturer | Yaskawa Electric Corporation |
| Motor Model | SGMJV-01ADA6C |
| Drive / Amplifier Model | VLAST60-06-0700 |
| Part Numbers | HV30001 / 810-495659-308 |
| Series | Sigma-V (Σ-V) |
| Rated Output Power | 100 W |
| Rated Torque | 0.318 N·m |
| Rated Speed | 3,000 rpm |
| Maximum Speed | 6,000 rpm |
| Encoder Type | Incremental / Serial Absolute (model-dependent) |
| Voltage Input | Single-phase / Three-phase 200–240 VAC |
| Protection Rating | IP67 (motor shaft end IP65) |
| Mounting | Flange mount (IEC standard) |
| Weight (Motor) | Approx. 0.3 kg |
| Shipping Weight | 2,600 g (packaged) |
| HS Code | 8501.52.0000 |
Why Engineers Specify This Model
- Compact 100 W footprint — Smallest frame in the Sigma-V family; ideal for space-constrained axes
- High-resolution encoder — 20-bit absolute encoder option delivers 1,048,576 pulses/rev for nanometer-class positioning
- Autotuning & vibration suppression — Sigma-V drive’s adaptive tuning eliminates manual gain adjustment on flexible loads
- MECHATROLINK-II / Analog-Pulse compatible — Integrates natively with Yaskawa MP controllers and third-party PLCs
- Proven global installed base — Millions of Sigma-V units deployed across Asia, Europe, and North America
- Long service life — Rated bearing life >20,000 hours under standard duty cycles
Complete System Bill of Materials
| Item | Part Number | Description |
|---|---|---|
| Servo Motor | SGMJV-01ADA6C | 100 W, 3,000 rpm, flange mount AC servo motor |
| Servo Drive | VLAST60-06-0700 | Matching amplifier / drive unit |
| Assembly Reference | HV30001 | OEM assembly / kit reference number |
| Cross-Reference P/N | 810-495659-308 | Alternate procurement / ERP part number |
| Encoder Cable | JZSP-CVP02-xx-E | Sigma-V encoder cable (specify length) |
| Power Cable | JZSP-B9P2-xx-E | Motor power cable (specify length) |
Contact Konmask for cable length options and complete wiring accessories.
Compliance & Industry Standards
- CE Marked — EMC Directive 2014/30/EU & Low Voltage Directive 2014/35/EU
- UL/cUL Listed — UL 508C (Power Conversion Equipment)
- RoHS 2 Compliant — Directive 2011/65/EU
- ISO 9001:2015 — Yaskawa manufacturing quality system
- SEMI S2 / S8 — Semiconductor equipment safety guidelines (applicable configurations)
Quality Assurance & Sourcing
Konmask sources Yaskawa servo components exclusively through verified industrial distribution channels. Every unit undergoes:
- Visual and dimensional inspection against OEM datasheets
- Label and serial number authentication
- Functional continuity check prior to dispatch
- Anti-static packaging with humidity indicator card
Traceability documentation available upon request for regulated industries (semiconductor, medical, aerospace).
How to Source This Part
- Add to Cart — Confirm quantity and proceed to checkout
- Request a Quote — Email [email protected] for volume pricing (>5 units) or blanket orders
- Lead Time — In-stock units ship within 1–3 business days; ex-factory orders 4–8 weeks
- Export & Customs — HS Code 8501.52.0000 declared; we support DDP, DAP, and EXW Incoterms
- Payment — T/T, PayPal, and major credit cards accepted
Application-Specific FAQ
Q: Is the SGMJV-01ADA6C compatible with non-Yaskawa controllers?
A: Yes. In pulse-train (P/P) mode the drive accepts standard step/direction or CW/CCW signals from any PLC or motion controller. Analog ±10 V torque/speed mode is also supported.
Q: What is the difference between SGMJV and SGMJV-01ADA6C?
A: SGMJV is the base series designation. The suffix -01ADA6C encodes: 100 W output (01), 200 VAC input (A), standard shaft (D), incremental encoder (A), straight shaft without key (6), and IP67 sealing (C).
Q: Can this motor be used in a vertical axis application?
A: Yes, with an appropriate holding brake option. The base SGMJV-01ADA6C does not include a brake; specify the -B suffix variant or add an external brake module for vertical loads.
Q: What regenerative resistor is required for the VLAST60-06-0700 drive?
A: At 100 W with typical duty cycles the internal regenerative circuit is sufficient. High-inertia or rapid deceleration applications may require an external resistor — contact Konmask with your duty cycle data for sizing.
Q: Do you provide the Yaskawa SigmaWin+ setup software?
A: SigmaWin+ is freely downloadable from Yaskawa’s website. Konmask can supply the USB-to-serial configuration cable (JZSP-CVS06-02-E) separately.
