Safety-Critical Control Solution — TRICONEX 3625A | Tricon TMR Main Processor
Where This Product Is Used
The TRICONEX 3625A Main Processor is deployed in the most demanding safety-instrumented and process-control environments across global industries. Typical installation sites include:
- Oil & Gas: Offshore platform emergency shutdown (ESD) systems, pipeline SCADA controllers, compressor anti-surge control
- Petrochemical & Refining: Reactor safety interlock systems, fired-heater burner management systems (BMS), distillation column protection
- Power Generation: Turbine overspeed protection, boiler safety systems, nuclear auxiliary control
- Chemical Manufacturing: Batch reactor interlocks, toxic-gas detection logic solvers, pressure-relief automation
- LNG & Terminal Operations: Loading arm ESD, cryogenic pump protection, vapor-recovery unit control
- Water & Wastewater: High-integrity pressure protection systems (HIPPS), pump station safety logic
Wherever SIL 2 / SIL 3 functional safety certification is mandated by regulation or engineering standard, the 3625A is a proven, field-validated choice.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | 3625A |
| Manufacturer | TRICONEX (Schneider Electric) |
| Series | Tricon TMR (Triple Modular Redundant) |
| Module Type | Main Processor Module (MP) |
| Architecture | Triple Modular Redundant (TMR) — three independent processing legs with 2-out-of-3 voting |
| Processor | Dual-redundant CPUs per leg (6 CPUs total across TMR) |
| Memory | Application RAM + Flash-backed program storage |
| Communication Ports | TriStation 1131 programming port; Tricon Communication Module (TCM) interface |
| Backplane Interface | Tricon chassis high-speed backplane bus |
| Operating Voltage | Supplied via chassis power supply (24 VDC internal bus) |
| Weight | 2,060 g (as listed) |
| Operating Temperature | 0 °C to +60 °C |
| Humidity | 5 % to 95 % RH, non-condensing |
| Safety Integrity Level | SIL 2 / SIL 3 capable (IEC 61511 / IEC 61508) |
| Certifications | TÜV, FM, CSA, ATEX (zone-dependent enclosure) |
| Firmware Compatibility | Tricon v9.x / v10.x (verify with project BOM) |
Why Engineers Specify This Model
- True TMR Architecture: Three independent processing legs continuously cross-check results via 2oo3 voting — a single-leg fault does not interrupt process control or trigger a spurious trip.
- Online Repair Without Shutdown: A faulty MP module can be replaced while the other two legs maintain full SIS operation, eliminating costly plant shutdowns.
- Deterministic Scan Cycle: Guaranteed worst-case response time supports tight process safety time (PST) budgets required by HAZOP/LOPA studies.
- Proven Field History: Installed base exceeds 10,000 systems globally across 30+ years of continuous development — critical for insurance underwriters and regulatory auditors.
- Integrated Diagnostics: Continuous self-test coverage >99 % detects latent faults before they can contribute to a dangerous failure.
- TriStation 1131 Compatibility: IEC 61131-3 programming environment with certified function blocks accelerates SIL-compliant application development.
Complete System Bill of Materials
The 3625A operates within the Tricon chassis ecosystem. A typical SIS node requires:
- Main Processor: 3625A (×1 per chassis, TMR internally)
- Chassis: Tricon 8-slot or 16-slot main chassis
- Power Supply: 8310 / 8311 redundant power supply modules (×2 recommended)
- Communication Module: TCM 4351A / 4352A for Modbus, OPC, or DCS gateway
- Digital Input Modules: 3501E / 3503E (TMR DI, 24 VDC or 120 VAC)
- Digital Output Modules: 3601E / 3603E (TMR DO, relay or solid-state)
- Analog Input Modules: 3703E / 3706A (TMR AI, 4–20 mA HART)
- Analog Output Modules: 3805E (TMR AO, 4–20 mA)
- TriStation 1131 Software: Engineering workstation license for programming and diagnostics
Contact Konmask for complete system quotations and compatibility verification.
Compliance & Industry Standards
- IEC 61508: Functional Safety of E/E/PE Safety-Related Systems (SIL 2 / SIL 3)
- IEC 61511: Functional Safety — Safety Instrumented Systems for the Process Industry
- NFPA 72 / 85: Applicable BMS and fire-protection logic applications
- API RP 14C / 14F: Offshore platform safety system design
- TÜV Rheinland Certified: Independent third-party safety assessment
- FM Approved & CSA Certified: North American hazardous-location compliance
- ATEX / IECEx: European and international explosive-atmosphere suitability (zone-rated enclosure required)
- RoHS Compliant: Restriction of Hazardous Substances
Quality Assurance & Sourcing
Konmask sources TRICONEX 3625A modules through verified industrial surplus and authorized distribution channels. Every unit offered is subject to:
- Visual and mechanical inspection (connector pins, PCB, label integrity)
- Firmware version documentation and traceability records
- Anti-static packaging with humidity indicator cards
- Optional functional test report available on request
- 90-day warranty against defects in materials and workmanship
We do not sell counterfeit, re-marked, or unverified parts. All units ship with full documentation of provenance.
How to Source This Part
- Add to Cart — proceed directly for standard lead times.
- Request a Quote — for volume orders (>2 units), system BOM quotations, or expedited delivery, email support@konmask.com.
- Provide Your Project Details — chassis model, firmware version, and required delivery date help us confirm compatibility and stock.
- Shipping — worldwide DHL / FedEx express available; export documentation (EAR99 / ECCN classification) provided on request.
Application-Specific FAQ
Q: Is the 3625A backward-compatible with older Tricon v9 systems?
A: The 3625A is designed for Tricon v10.x platforms. Compatibility with v9.x chassis requires firmware verification — contact us with your chassis serial number before ordering.
Q: Can this module be hot-swapped during live plant operation?
A: Yes. The TMR architecture allows online replacement of a faulted MP module while the remaining two legs maintain 2oo3 voting and full SIS functionality.
Q: Do you provide a Safety Manual or SIL certificate?
A: TÜV safety manuals and SIL certificates are available from Schneider Electric / TRICONEX. Konmask can provide copies of documentation received with the unit upon request.
Q: What is the typical lead time?
A: In-stock units ship within 1–3 business days. For out-of-stock items, typical sourcing lead time is 2–4 weeks. Contact us for current availability.
Q: Can Konmask supply a complete Tricon system (chassis + I/O + power)?
A: Yes. We specialize in complete system BOM fulfillment. Provide your I/O list and we will quote the full system.
