Safety Shutdown & Process Control Solution – TRICONEX 3636R | Tricon Safety System
Where This Product Is Used
The TRICONEX 3636R Relay Module is deployed in safety-critical industrial environments where reliable output switching and fault-tolerant control are mandatory. Typical application sites include:
- Oil & Gas Processing Plants – Emergency Shutdown Systems (ESD) for wellheads, compressor stations, and pipeline isolation valves
- LNG & Petrochemical Facilities – High-integrity process shutdown (HIPPS) loops requiring SIL 2/3 rated output modules
- Power Generation – Turbine trip systems, boiler protection, and generator protection relay outputs
- Chemical & Pharmaceutical Plants – Reactor safety interlocks and automated emergency depressurization systems
- Offshore Platforms – Fire & Gas (F&G) system output modules for deluge valve actuation and blowdown control
- Nuclear & Utilities – Qualified safety instrumented system (SIS) output channels in redundant TMR architectures
- Pulp, Paper & Mining – Machine guarding interlocks and conveyor emergency stop relay outputs
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | TRICONEX (Schneider Electric) |
| Part Number | 3636R |
| Module Type | Relay Output Module |
| System Compatibility | Tricon TMR Safety System (v9.x / v10.x) |
| Output Channels | 16 relay output channels |
| Output Type | Dry contact relay (Form C / SPDT) |
| Contact Rating | 2A @ 30 VDC / 0.5A @ 125 VAC |
| Isolation | Optical isolation between field and logic |
| Backplane Interface | Tricon standard TMR backplane |
| Diagnostics | Online self-diagnostics with fault annunciation |
| Operating Temperature | 0°C to +60°C |
| Humidity | 5% to 95% RH, non-condensing |
| Weight | 2420 g |
| Form Factor | Single-slot Tricon chassis module |
| Firmware | Compatible with TriStation 1131 programming environment |
Why Engineers Specify This Model
- Triple Modular Redundancy (TMR) – The 3636R operates within Tricon’s 2-out-of-3 voting architecture, eliminating single points of failure and ensuring continuous safe operation even during module faults.
- Hot-Swap Capability – Modules can be replaced under power without process interruption, minimizing planned and unplanned downtime in 24/7 operations.
- Proven SIL 3 Pedigree – Certified for use in Safety Instrumented Functions (SIFs) up to SIL 3 per IEC 61511, making it the preferred choice for high-consequence process loops.
- Dry Contact Relay Outputs – Voltage-free contacts provide universal compatibility with field devices including solenoid valves, motor starters, and alarm annunciators across varying supply voltages.
- Comprehensive Online Diagnostics – Continuous self-test routines detect latent faults and report status to the Tricon Main Processor, supporting proof-test interval optimization.
- Long Field Service Life – Designed for 20+ year operational lifecycles typical of process industry infrastructure, with Schneider Electric’s global spare parts support.
Complete System Bill of Materials
The TRICONEX 3636R is typically specified alongside the following Tricon system components:
- Tricon Main Processor Module (e.g., 3008, 3009) – TMR CPU for logic execution
- Tricon Communication Module (e.g., 4351A, 4352A) – Modbus/OPC-UA gateway
- Tricon Power Supply Module (e.g., 8310) – Redundant 24 VDC chassis power
- Tricon Chassis / Backplane (e.g., 7400144-100) – Module mounting and interconnect
- Tricon Digital Input Module (e.g., 3501E, 3503E) – Field sensor inputs
- Tricon Analog Input Module (e.g., 3700A, 3703E) – 4–20 mA process variable inputs
- TriStation 1131 Engineering Workstation – IEC 61131-3 programming and configuration
- Field Terminal Assembly (FTA) – Marshalling and field wiring termination panels
Compliance & Industry Standards
- IEC 61508 – Functional Safety of E/E/PE Safety-related Systems (SIL 3 capable)
- IEC 61511 – Functional Safety for the Process Industry Sector
- IEC 61131-3 – Programmable Controller Languages (TriStation 1131 compliant)
- ANSI/ISA-84 – Safety Instrumented Systems for the Process Industry
- CE Marking – European conformity for industrial control equipment
- UL / cUL Listed – North American safety certification
- ATEX / IECEx – Suitable for use in classified hazardous area control rooms (consult project documentation)
- TÜV Rheinland Certified – Independent third-party functional safety assessment
Quality Assurance & Sourcing
At Konmask.com, every TRICONEX 3636R unit offered is subject to a rigorous multi-stage quality process:
- Authenticity Verification – Physical inspection of labels, firmware revision markings, and component-level checks against known-good reference units
- Functional Bench Test – All relay output channels exercised and verified prior to dispatch
- Traceability Documentation – Serial number logging and sourcing chain records maintained for each unit
- Anti-Static Packaging – Shipped in ESD-safe bags with foam-lined cartons to prevent transit damage
- 90-Day Warranty – All units carry a 90-day return-to-base warranty covering functional defects
- Authorized Distributor Network – Sourced from verified industrial automation distributors and decommissioned plant inventories with documented service history
How to Source This Part
- Confirm Compatibility – Verify your Tricon chassis revision and firmware version (TriStation 1131 project file) to ensure 3636R compatibility before ordering.
- Request a Quote – Contact [email protected] or call +0086 19859288691 for volume pricing, lead time, and availability confirmation.
- Submit Purchase Order – Provide your company name, delivery address, and required quantity. Pro-forma invoice issued within 1 business day.
- Expedited Shipping Available – DHL / FedEx express options for urgent plant shutdowns or unplanned outages. Export documentation (CO, packing list, commercial invoice) included.
- Technical Pre-Sales Support – Our engineers can assist with slot assignment, FTA wiring diagrams, and TriStation configuration guidance at no charge.
Application-Specific FAQ
Q: Is the TRICONEX 3636R compatible with both Tricon v9 and v10 chassis?
A: Yes. The 3636R is backward and forward compatible across Tricon v9.x and v10.x chassis generations. Always confirm the chassis backplane revision with your site documentation.
Q: Can the 3636R be used in SIL 3 Safety Instrumented Functions?
A: Yes, when installed in a properly configured Tricon TMR system and validated per IEC 61511 requirements, the 3636R supports SIL 3 SIF design. Consult the Tricon Safety Manual for PFD/PFH data.
Q: What is the relay contact rating for inductive loads such as solenoid valves?
A: The dry contacts are rated 2A @ 30 VDC resistive. For inductive loads (solenoid valves, motor starters), de-rating applies. Refer to the TRICONEX 3636R Hardware Reference Manual for derating curves and recommended suppression circuits.
Q: Can this module be replaced online without a system shutdown?
A: Yes. The Tricon architecture supports online module replacement (hot-swap) without interrupting the safety function, provided the replacement procedure in the Tricon Installation & Maintenance Guide is followed.
Q: Do you supply the Field Terminal Assembly (FTA) for the 3636R?
A: Yes. Konmask.com can supply compatible FTAs and marshalling panels. Contact us with your wiring requirements for a matched BOM quotation.
Q: What lead time should I expect for urgent orders?
A: In-stock units ship within 1–2 business days. Express international delivery via DHL/FedEx typically reaches most destinations within 3–5 business days. Contact us for real-time stock confirmation.
