VACON PC00225I — Internal Power Supply Board | VACON NX / NXP Series Platform
Engineering Background
VACON (now part of Danfoss Drives) is a globally recognized manufacturer of AC variable frequency drives deployed across heavy industry, marine, water treatment, and process automation. The NX/NXP platform is engineered for demanding continuous-duty applications where drive uptime is mission-critical. The PC00225I is the dedicated internal power supply board that regulates and distributes low-voltage DC rails to the drive’s control electronics, gate driver circuits, and I/O subsystems.
Product Positioning
The PC00225I is a direct OEM-equivalent replacement board for VACON NX/NXP series drives. It is the correct procurement choice for maintenance engineers performing board-level repairs, system integrators refurbishing drive cabinets, and OEM spare-parts programs requiring verified, traceable components. Konmask.com sources this board through established industrial distribution channels with full traceability documentation available on request.
Complete Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | PC00225I |
| Manufacturer | VACON (Danfoss Drives) |
| Component Type | Internal Power Supply Board (SMPS) |
| Compatible Platform | VACON NX / NXP Series AC Drives |
| Function | Regulated DC power distribution to control board, gate drivers, and I/O |
| Board Form Factor | PCB assembly with edge connectors |
| Condition | New / Refurbished (specify at inquiry) |
| Warranty | 12 months (Konmask standard) |
| Shipping Weight | ~100 g |
| Export Classification | Contact us for HS code confirmation |
Proven Application Environments
- Water & Wastewater: Pump and blower drives in municipal treatment plants running VACON NX frames
- Marine & Offshore: Thruster and auxiliary drives requiring high-reliability power supply boards with vibration tolerance
- Oil & Gas / Process: Compressor and fan drives in hazardous-area cabinets where board-level repair is preferred over full drive replacement
- HVAC & Building Automation: Large AHU and chiller drives in commercial facilities with long service-life requirements
- Pulp, Paper & Mining: Continuous-duty conveyor and mill drives where unplanned downtime carries high production cost
Engineering Advantages
- OEM-Equivalent Design: Identical PCB layout, component ratings, and connector pinout to the factory-installed board — no firmware or parameter changes required after swap
- Isolated DC Rails: Galvanically isolated output rails prevent ground-loop faults from propagating between control and power sections
- Thermal Stability: Industrial-grade capacitors and magnetics rated for extended temperature range, consistent with VACON NX environmental specifications
- Drop-In Replacement: Plug-and-play installation reduces MTTR; no custom calibration required
- Traceability: Batch and date codes available; supports ISO 9001 maintenance records
System Architecture & Signal Flow
Within the VACON NX/NXP drive architecture, the PC00225I board receives its primary input from the DC bus or auxiliary winding of the main transformer and generates the regulated low-voltage rails (typically ±15 V, +5 V, +24 V) required by:
- The main control board (NXOPTA / NXOPTB option boards included)
- Gate driver boards for IGBT switching
- Fieldbus and I/O option cards
- Keypad and HMI interface
Failure of the PC00225I typically manifests as a complete drive lockout, loss of keypad communication, or persistent fault codes related to internal supply undervoltage. Board-level replacement is the standard corrective action recommended in VACON NX service documentation.
Sourcing & Quality Verification
- Supply Chain: Sourced from authorized industrial distributors and verified OEM surplus channels
- Inspection: Each board undergoes visual inspection and functional verification prior to dispatch
- Documentation: Certificate of conformity, packing list, and traceability records provided on request
- Anti-Counterfeit: Boards are cross-referenced against VACON part number databases; counterfeit or non-OEM boards are rejected
- Packaging: ESD-safe anti-static bag + foam-lined carton for safe international transit
Procurement Process
- Inquiry: Submit your drive nameplate data (model, frame size, serial number) via email or WhatsApp to confirm compatibility
- Quotation: Receive a formal quotation with lead time, unit price, and shipping options within 1 business day
- Order Confirmation: Pro-forma invoice issued; payment via T/T, PayPal, or platform checkout
- Dispatch: Ships within 3–5 business days from Xiamen, China; DHL / FedEx / EMS available
- After-Sales: 12-month warranty; DOA replacement policy; technical support via email
