WOODWARD 5464-210 – Actuator Driver Module | WOODWARD Industrial Control Platform
Engineering Background
WOODWARD is a globally recognized leader in energy control solutions, with over a century of engineering heritage in turbine, engine, and industrial process control. The 5464-210 Actuator Driver is engineered as a precision output interface module within WOODWARD’s industrial control architecture, designed to translate digital control signals into reliable, high-fidelity actuator commands in demanding operational environments.
Product Positioning
The WOODWARD 5464-210 serves as a critical bridge between the control system and physical actuators in turbine governor systems, gas/steam engine management, and industrial process automation. It is the preferred choice for procurement engineers requiring deterministic response, robust signal conditioning, and long-term field reliability in mission-critical installations.
Complete Technical Specifications
- Part Number: 5464-210
- Manufacturer: WOODWARD
- Module Type: Actuator Driver
- Function: Precision analog/digital output driver for electro-hydraulic and electro-mechanical actuators
- Output Type: Current-controlled analog output (mA drive)
- Power Supply: Compatible with WOODWARD standard control system backplane voltages
- Operating Temperature: Industrial grade; suitable for panel and cabinet installation
- Weight: Approx. 600 g
- Form Factor: Plug-in module, WOODWARD standard form factor
- Compliance: Designed to WOODWARD OEM specifications
- Condition: New / Refurbished OEM (specify at inquiry)
Proven Application Environments
- Gas turbine governor and fuel control systems
- Steam turbine speed and load control
- Diesel and gas engine management platforms
- Industrial compressor and pump control panels
- Power generation and co-generation plant automation
- Oil & gas upstream/downstream process control
- Marine propulsion and auxiliary engine control
Engineering Advantages
- Deterministic Output: Delivers stable, repeatable actuator drive signals with minimal latency, critical for governor response accuracy
- High Noise Immunity: Designed for industrial EMI environments typical of turbine halls and engine rooms
- Drop-in Compatibility: Direct replacement for existing WOODWARD 5464-210 installations — no re-engineering required
- Long Service Life: Industrial-grade components rated for continuous duty in harsh environments
- Reduced Commissioning Time: Plug-in module design enables rapid field replacement and minimal downtime
System Architecture & Signal Flow
The 5464-210 Actuator Driver receives command signals from the WOODWARD control processor via the system backplane. It conditions and amplifies these signals to drive connected actuators — electro-hydraulic servo valves, proportional valves, or electro-mechanical actuators — with precision current output. The module incorporates internal feedback and protection circuitry to ensure safe operation under fault conditions, including open-circuit and short-circuit protection on actuator outputs.
Signal flow: Control Processor → Backplane Bus → 5464-210 Driver Module → Actuator Output (mA) → Field Actuator Device
Sourcing & Quality Verification
- All units sourced through verified industrial supply channels with full traceability
- Pre-shipment functional inspection and visual QC performed on every unit
- OEM part number and label integrity verified prior to dispatch
- Packaging: anti-static, moisture-barrier, and shock-protected for international transit
- Documentation available: test reports, photos, and certificate of conformance upon request
Procurement Process
- Inquiry: Submit your RFQ via the product page or email support@konmask.com with quantity and required condition (new/refurbished)
- Quotation: Receive a formal quotation with lead time, unit price, and shipping options within 24 business hours
- Order Confirmation: Purchase order accepted via online checkout, bank transfer, or corporate PO
- Quality Check & Dispatch: Unit inspected, documented, and dispatched with tracking
- After-Sales Support: Technical support available post-delivery for integration and commissioning queries
Technical FAQ
Q: Is the WOODWARD 5464-210 a direct replacement for my existing unit?
A: Yes. The 5464-210 is a plug-in replacement module. Verify your system backplane and connector compatibility before installation.
Q: What actuator types are compatible with this driver?
A: The module is designed for electro-hydraulic servo valves and proportional actuators standard to WOODWARD governor systems. Consult your system documentation for output current range compatibility.
Q: Can you provide a test report or functional verification certificate?
A: Yes. Functional test reports and QC documentation are available upon request for all units shipped from Konmask.com.
Q: What is the lead time for this part?
A: Standard lead time is 3–7 business days for in-stock units. Express shipping available. Contact us for urgent requirements.
Q: Do you offer a warranty?
A: Yes. All units carry a 90-day functional warranty. Extended warranty options available — contact support for details.
