Turbine & Engine Control Solution — WOODWARD 5501-376 | Analog I/O Module
The WOODWARD 5501-376 is a precision Analog I/O Module engineered for mission-critical speed governing, fuel control, and process regulation applications. Deployed across power generation, oil & gas, and marine propulsion platforms, this module serves as the analog signal backbone of WOODWARD’s proven control architecture — translating real-world process variables into actionable control commands with high-fidelity accuracy.
At Konmask.com, we supply the 5501-376 from verified OEM-traceable inventory, supporting MRO procurement, emergency replacements, and new system builds for engineering teams worldwide.
Where This Product Is Used
The WOODWARD 5501-376 Analog I/O Module is specified by control engineers across the following environments:
- Gas Turbine Governors — Speed and load control on industrial gas turbines (GE, Siemens, Solar Turbines OEM integrations)
- Steam Turbine Control Systems — Valve positioning, extraction pressure, and extraction flow regulation
- Reciprocating Engine Management — Fuel rack position feedback and air/fuel ratio control on large-bore engines
- Compressor Anti-Surge Control — Analog signal processing for surge detection and recycle valve actuation
- Marine Propulsion Systems — Engine speed governing and pitch control on diesel-electric vessels
- Power Plant DCS Integration — Analog I/O bridging between WOODWARD governors and plant-level DCS (ABB, Honeywell, Emerson)
- Pump & Fan Drive Control — Variable-speed drive feedback loops in water treatment and HVAC applications
Technical Specifications
| Parameter | Specification |
|---|---|
| Part Number | 5501-376 |
| Manufacturer | WOODWARD |
| Module Type | Analog I/O Module |
| Signal Type | Analog Input / Analog Output |
| Typical Input Range | 4–20 mA / 0–10 VDC (application-dependent) |
| Typical Output Range | 4–20 mA / 0–10 VDC (application-dependent) |
| Resolution | 12-bit or higher (confirm with WOODWARD datasheet) |
| Isolation | Galvanic channel isolation (typical for WOODWARD I/O) |
| Operating Temperature | -40°C to +70°C (industrial grade) |
| Power Supply | 24 VDC nominal (confirm with system documentation) |
| Mounting | DIN rail / panel mount (WOODWARD standard backplane) |
| Communication | Backplane bus to WOODWARD controller |
| Weight | 500 g (approx.) |
| Certifications | CE, UL (verify current listing with WOODWARD) |
| Replacement / Cross-Reference | Consult WOODWARD BOM for compatible substitutes |
Note: Confirm all specifications against the official WOODWARD 5501-376 datasheet and your system’s engineering drawings before installation.
Why Engineers Specify This Model
- OEM-Matched Signal Conditioning — Designed to interface natively with WOODWARD governors (MicroNet, 505, 723+) without signal conversion losses
- High Channel Isolation — Galvanic isolation prevents ground loops and protects sensitive control electronics in electrically noisy turbine environments
- Wide Temperature Tolerance — Rated for harsh ambient conditions found in outdoor turbine enclosures and marine engine rooms
- Plug-and-Play Replacement — Direct form-fit-function replacement for existing 5501-376 installations; no firmware changes required
- Proven Field Reliability — Deployed in continuous-duty applications with MTBF exceeding typical industrial I/O standards
- Reduced Commissioning Risk — OEM module eliminates compatibility uncertainty versus third-party analog I/O alternatives
Complete System Bill of Materials
The 5501-376 is typically deployed as part of a broader WOODWARD control system. Common companion components include:
- WOODWARD MicroNet TMR / MicroNet Plus Controller
- WOODWARD 505 Digital Governor
- WOODWARD 723+ Load Sharing & Speed Control
- WOODWARD Digital I/O Modules (5501-series)
- WOODWARD Power Supply Modules
- WOODWARD Communication Modules (Modbus, Profibus, DeviceNet)
- WOODWARD Actuators & Servovalves (matched to governor output)
- Speed sensors, RTDs, thermocouples (field instrumentation)
Contact support@konmask.com for complete BOM sourcing assistance.
Compliance & Industry Standards
- IEC 61511 — Functional Safety for Process Industry Sectors (SIL-rated system integration)
- IEC 61508 — Functional Safety of E/E/PE Safety-Related Systems
- ISO 8528 — Reciprocating internal combustion engine driven alternating current generating sets
- NFPA 85 — Boiler and Combustion Systems Hazards Code (applicable in power plant deployments)
- CE Marking — European conformity for industrial control equipment
- UL Listed — Underwriters Laboratories industrial control equipment (verify current listing)
- RoHS Compliant — Restriction of Hazardous Substances (confirm with WOODWARD for specific revision)
Quality Assurance & Sourcing
- OEM-Traceable Supply Chain — All units sourced from authorized distributors or verified OEM surplus with full traceability documentation
- Pre-Shipment Inspection — Visual inspection, label verification, and packaging integrity check on every unit
- Authenticity Guarantee — Zero tolerance for counterfeit components; units rejected if traceability cannot be confirmed
- Condition Grading — New (sealed OEM), Refurbished (tested to OEM spec), or Surplus (inspected, functional) — stated clearly on invoice
- Warranty — 12-month warranty against manufacturing defects on new units; 90-day warranty on refurbished/surplus
- Export Compliance — All shipments comply with applicable export control regulations (EAR, ECCN classification available on request)
How to Source This Part
- Submit RFQ — Email support@konmask.com with your required quantity, delivery timeline, and destination country
- Receive Quote — We respond within 24 business hours with pricing, lead time, and stock condition details
- Order Confirmation — Confirm PO; we issue proforma invoice with payment terms
- Quality Check & Dispatch — Unit inspected, documented, and shipped via DHL / FedEx / sea freight with full tracking
- Post-Delivery Support — Technical support available for installation verification and system integration questions
Phone / WhatsApp: +0086 19859288691
Email: support@konmask.com
Website: https://Konmask.com
Application-Specific FAQ
Q: Is the WOODWARD 5501-376 compatible with the MicroNet TMR platform?
A: Yes, the 5501-376 is designed for use within WOODWARD’s MicroNet control system family. Verify slot assignment and backplane compatibility with your system’s engineering drawings.
Q: Can this module be used as a direct replacement for a failed unit without reconfiguration?
A: In most cases, yes — the 5501-376 is a form-fit-function replacement. However, always verify firmware revision compatibility and perform a loop check after installation.
Q: What is the lead time for the WOODWARD 5501-376?
A: Lead time depends on current stock status. In-stock units ship within 3–5 business days. For out-of-stock scenarios, typical lead time is 4–8 weeks from OEM. Contact us for real-time availability.
Q: Do you provide a certificate of conformance (CoC) with the module?
A: Yes. A CoC is provided with every shipment. Material Test Reports (MTR) and OEM traceability documentation are available on request.
Q: Can Konmask source other WOODWARD 5501-series modules?
A: Yes. We maintain sourcing relationships for the full WOODWARD 5501-series I/O module range. Submit your complete BOM for a consolidated quote.
Q: Is this module suitable for SIL 2 applications?
A: WOODWARD MicroNet TMR systems are designed for high-availability applications. For SIL certification specifics, consult the WOODWARD functional safety documentation and your system integrator.
