WOODWARD 8200-188 — Precision Rotary Actuator | WOODWARD EG Series Platform
Engineering Background
WOODWARD is a globally recognized leader in energy control solutions, with over a century of engineering heritage in turbine, engine, and industrial power management. The 8200-188 Rotary Actuator is engineered for applications demanding precise, repeatable angular positioning under demanding thermal and mechanical conditions. It is a core component in fuel metering, valve actuation, and governor-linked control loops across gas turbines, diesel engines, and industrial prime movers.
Product Positioning
The WOODWARD 8200-188 is designed for OEM integrators, MRO procurement teams, and plant engineers who require a drop-in-compatible, spec-verified rotary actuator with documented traceability. It delivers consistent torque output and angular resolution in closed-loop control architectures where positional accuracy directly impacts fuel efficiency, emissions compliance, and system uptime.
Complete Technical Specifications
| Part Number | 8200-188 |
| Manufacturer | WOODWARD |
| Product Family | EG Series Rotary Actuator |
| Actuator Type | Electro-hydraulic / Electromechanical Rotary |
| Output Motion | Rotary (angular displacement) |
| Control Signal | Analog current input (4–20 mA typical) |
| Supply Voltage | 24 VDC nominal (consult datasheet for range) |
| Operating Temperature | –40°C to +85°C (ambient) |
| Enclosure Rating | IP65 (dust-tight, water jet resistant) |
| Mounting Interface | Flange-mount per WOODWARD standard |
| Weight | ~500 g |
| Compliance | CE, RoHS (verify current revision with datasheet) |
Note: Full electrical and mechanical specifications are available in the official WOODWARD 8200-188 datasheet. Contact Konmask technical support for document access.
Proven Application Environments
- Gas Turbine Fuel Control: Precise metering valve positioning in single-shaft and split-shaft turbine configurations.
- Diesel Engine Governor Systems: Rack actuator replacement and fuel injection timing control in industrial gensets and marine propulsion.
- Industrial Compressor Control: Anti-surge valve actuation and capacity control in centrifugal and reciprocating compressors.
- Power Generation: Load-sharing and droop-speed control in parallel generator sets.
- Oil & Gas Processing: Wellhead and pipeline valve actuation in upstream and midstream facilities.
- Marine & Offshore: Engine room automation and propulsion control on vessels requiring DNV/ABS-compatible components.
Engineering Advantages
- High Positional Repeatability: Closed-loop feedback ensures angular position accuracy critical for fuel trim and emissions tuning.
- Robust Thermal Performance: Rated for wide ambient temperature range, suitable for engine room and outdoor enclosure installations.
- Direct OEM Compatibility: Drop-in replacement for existing WOODWARD 8200-series installations — no mechanical adaptation required.
- Low Hysteresis: Minimizes control dead-band, improving governor response and reducing fuel consumption variance.
- Sealed Construction: IP65-rated housing resists contamination from oil mist, dust, and water ingress in harsh plant environments.
- Long Service Life: WOODWARD’s proven actuator platform with documented MTBF data available for reliability engineering assessments.
System Architecture & Signal Flow
The 8200-188 integrates into a standard closed-loop governor or fuel control architecture as follows:
- Speed/Load Sensor → transmits process variable to the WOODWARD controller (e.g., 505, 2301, MicroNet).
- Controller Output → generates 4–20 mA demand signal to the 8200-188 actuator.
- Actuator → converts electrical demand to precise rotary shaft displacement, driving the fuel valve or rack.
- Position Feedback → internal LVDT or potentiometer returns actual position to the controller for closed-loop correction.
- Fuel Valve / Rack → modulates fuel flow in direct proportion to actuator shaft angle.
This architecture supports both isochronous (constant speed) and droop (load-proportional) control modes depending on controller configuration.
Sourcing & Quality Verification
- Genuine Parts: Konmask.com sources WOODWARD components through authorized distribution channels and verified surplus networks with full traceability documentation.
- Inspection Protocol: Each unit undergoes visual inspection, label verification, and packaging integrity check prior to dispatch.
- Documentation Available: Certificate of conformance, test reports, and original WOODWARD packaging available upon request for critical applications.
- Counterfeit Mitigation: All WOODWARD parts are cross-referenced against OEM part number databases. Suspect units are quarantined and not listed.
Procurement Process
- Confirm Part Number: Verify 8200-188 against your BOM or existing unit nameplate before ordering.
- Request Quote: Contact support@konmask.com for volume pricing, lead time, and availability confirmation.
- Submit PO: Purchase orders accepted via email. Net payment terms available for qualified B2B accounts.
- Shipping: DHL / FedEx international express with full tracking. Export documentation (commercial invoice, packing list, COO) provided for customs clearance.
- After-Sales Support: Technical assistance available post-delivery for installation verification and commissioning queries.
Technical FAQ
Q: Is the 8200-188 compatible with WOODWARD 2301A and 505 controllers?
A: Yes. The 8200-188 is designed to interface with standard WOODWARD governor controllers using 4–20 mA actuator output channels. Verify wiring polarity and current range against your specific controller manual.
Q: What is the difference between the 8200-188 and other 8200-series variants?
A: The 8200 series covers a range of torque ratings and shaft configurations. The -188 suffix designates a specific torque/stroke combination. Contact Konmask for cross-reference assistance if you are evaluating alternative variants.
Q: Can this actuator be used in ATEX/hazardous area zones?
A: The standard 8200-188 is not ATEX-certified. For hazardous area applications, consult WOODWARD’s EX-rated actuator product line or contact Konmask for guidance.
Q: What is the typical lead time?
A: In-stock units ship within 1–3 business days. Ex-stock or sourced units typically require 5–15 business days. Contact us for real-time availability.
Q: Do you provide installation support?
A: Yes. Konmask technical support can provide wiring diagrams, commissioning checklists, and remote guidance for qualified engineers. Contact support@konmask.com.
