Turbine & Generator Control Solution — WOODWARD 8444-1002 | Measuring Transducer
The WOODWARD 8444-1002 Measuring Transducer is a precision signal-conditioning module engineered for industrial prime-mover control systems. Designed to interface with WOODWARD’s governor and control platforms, it converts raw sensor inputs—speed, load, pressure, or temperature—into clean, calibrated analog signals that drive closed-loop control decisions in real time. For engineers specifying replacement or upgrade components in turbine, generator, and compressor applications, the 8444-1002 is a proven, OEM-grade solution available through Konmask.com.
Where This Product Is Used
- Steam Turbine Governor Systems — Provides accurate speed and load feedback to WOODWARD 505, 505E, and MicroNet governor controllers, enabling stable isochronous or droop speed control across load transients.
- Gas Turbine Control Panels — Conditions fuel-flow and exhaust-temperature sensor signals for integration into turbine management systems in power generation and oil & gas facilities.
- Diesel & Gas Generator Sets — Used in genset paralleling applications where precise load-sharing signals are required between multiple generating units on an islanded or grid-tied bus.
- Industrial Compressor Drives — Interfaces with pressure and flow transmitters to deliver conditioned process-variable signals to WOODWARD speed controllers in pipeline compression stations.
- Marine Propulsion Control — Deployed in ship propulsion governor panels where vibration-resistant, reliable signal conditioning is mandatory for classification society compliance.
- Hydroelectric Turbine Governors — Converts wicket-gate position and shaft-speed sensor outputs into standardized signals for WOODWARD digital governor platforms.
Technical Specifications
- Part Number: 8444-1002
- Manufacturer: WOODWARD
- Module Type: Measuring / Signal Conditioning Transducer
- Form Factor: DIN-rail or panel-mount module (per WOODWARD system chassis)
- Input Signal Types: Magnetic pickup (MPU), 4–20 mA, 0–10 V DC (application-dependent)
- Output Signal: Conditioned analog DC signal compatible with WOODWARD governor analog inputs
- Operating Voltage: 24 V DC nominal (refer to WOODWARD system power supply specification)
- Operating Temperature: –40 °C to +70 °C
- Weight: Approx. 2,000 g (packaged)
- Compliance: CE Marked; designed to WOODWARD OEM quality standards
- SKU / Part No.: 8444-1002
Note: Full datasheet and wiring diagrams are available upon request. Contact support@konmask.com.
Why Engineers Specify This Model
- OEM Compatibility — Direct drop-in replacement for WOODWARD governor and control systems; no firmware changes or signal re-scaling required.
- High Signal Fidelity — Precision conditioning eliminates noise and drift that can cause governor hunting or false trips in sensitive prime-mover applications.
- Proven Field Reliability — WOODWARD’s 8444-series transducers have decades of deployment history in power generation, oil & gas, and marine industries.
- Reduced Commissioning Time — Plug-compatible with existing WOODWARD wiring harnesses; engineers report same-day swap-out and re-commissioning.
- Wide Environmental Tolerance — Rated for harsh industrial environments including high-vibration, wide-temperature, and EMI-rich control rooms.
- Traceable Sourcing — Konmask.com supplies this part with full traceability documentation, supporting your site’s maintenance and audit records.
Complete System Bill of Materials
The 8444-1002 is typically specified alongside the following WOODWARD components. Contact Konmask.com to source the complete BOM:
- WOODWARD 505 / 505E Digital Governor Controller
- WOODWARD Magnetic Pickup (MPU) Speed Sensor — 8923-032 or equivalent
- WOODWARD Load Sharing & Speed Control Module — 9907-series
- WOODWARD Power Supply Module — 5464-series (24 V DC)
- WOODWARD Actuator Driver / Servo Amplifier — 9905-series
- Shielded instrumentation cable (Belden 8760 or equivalent) for MPU wiring
- DIN rail terminal blocks and grounding bars for panel integration
Compliance & Industry Standards
- CE Marking — Meets EU Machinery Directive and EMC Directive requirements.
- IEC 61511 / IEC 61508 — Suitable for use in safety-instrumented systems (SIS) where functional safety assessment is required; consult WOODWARD SIL documentation.
- API 670 — Compatible with machinery protection system architectures per API 670 for turbomachinery.
- DNV / Lloyd’s Register — WOODWARD governor components are accepted by major marine classification societies for shipboard propulsion applications.
- ISO 9001 — Manufactured under WOODWARD’s ISO 9001-certified quality management system.
Quality Assurance & Sourcing
Konmask.com sources the WOODWARD 8444-1002 through verified industrial supply channels with a focus on authenticity and traceability:
- Authenticity Verification — Each unit is inspected against WOODWARD OEM markings, label integrity, and packaging standards before dispatch.
- Traceability Documentation — Certificate of conformance (CoC) and, where available, original manufacturer test records are provided.
- Condition — New (surplus stock) or factory-refurbished units clearly identified at time of quotation.
- Warranty — 12-month operational warranty against manufacturing defects; extended warranty available on request.
- Packaging — Anti-static, moisture-barrier packaging with foam cushioning for safe international transit.
How to Source This Part
- Submit an RFQ — Email support@konmask.com with your part number (8444-1002), required quantity, and delivery timeline. We respond within 1 business day.
- Receive a Quotation — We provide pricing in USD/HKD, lead time, and available stock condition (new surplus / refurbished).
- Place Your Order — Confirm via purchase order or online checkout. We accept T/T bank transfer, PayPal, and major credit cards.
- Shipping & Tracking — Orders ship via DHL Express, FedEx, or UPS with full tracking. Export documentation (commercial invoice, packing list, COO) included.
- Technical Support — Our engineering team is available to assist with installation questions, wiring diagrams, and compatibility verification.
Application-Specific FAQ
Q: Is the WOODWARD 8444-1002 a direct replacement for older 8444-series transducers?
A: In most cases, yes. The 8444-1002 is pin- and signal-compatible with other 8444-series variants used in WOODWARD governor panels. We recommend confirming your existing wiring diagram before installation. Contact us for a compatibility check.
Q: Can this transducer be used with non-WOODWARD control systems?
A: The 8444-1002 outputs a standard analog DC signal and can interface with third-party PLCs or DCS systems provided the input impedance and signal range are matched. Signal scaling may be required.
Q: What is the lead time for the 8444-1002?
A: Stock availability varies. In-stock units ship within 3–5 business days. For out-of-stock items, typical lead time is 4–8 weeks. Submit an RFQ for current availability.
Q: Do you provide installation support?
A: Yes. Konmask.com provides wiring diagrams, WOODWARD technical manuals, and remote engineering support for customers integrating the 8444-1002 into their control systems.
Q: Is this part suitable for use in hazardous area (ATEX/IECEx) installations?
A: The standard 8444-1002 is not ATEX-certified for Zone 1/2 hazardous areas. For Ex-rated applications, consult WOODWARD’s hazardous-area product line or use appropriate safety barriers.
Q: Can I order a single unit, or is there a minimum order quantity?
A: Konmask.com supplies single units as well as bulk orders. No minimum order quantity applies.
