WOODWARD LS-5 8440-1946 – Circuit Breaker Control & Protection Module | LS-5 Governor Platform
Engineering Background
The WOODWARD LS-5 series represents a mature, field-proven governor and control platform widely deployed in power generation, turbine control, and industrial circuit protection applications. The 8440-1946 is a dedicated control protection module within this platform, engineered to interface directly with circuit breaker actuation circuits, providing deterministic trip/close logic, fault isolation, and status feedback in demanding industrial environments.
Product Positioning
Designed for procurement engineers sourcing replacement or expansion modules for existing WOODWARD LS-5 governor systems, the 8440-1946 delivers OEM-equivalent performance without the lead times associated with new factory orders. Konmask.com maintains verified stock of this module, supporting both emergency replacement and planned maintenance schedules for power plant operators, EPC contractors, and MRO procurement teams.
Complete Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | WOODWARD |
| Part Number | 8440-1946 |
| Series / Platform | LS-5 Governor & Control System |
| Function | Circuit Breaker Control & Protection |
| Module Type | Control Protection Module (CPM) |
| Weight | 820 g (as shipped) |
| Mounting | Panel / rack mount per LS-5 system chassis |
| Communication Interface | Per LS-5 backplane specification |
| Operating Temperature | Refer to WOODWARD LS-5 system manual |
| Certifications | Per OEM documentation; CE / UL class per system configuration |
| SKU | LS-5 8440-1946 |
| Condition | New / Surplus New (confirm at inquiry) |
Note: Full electrical ratings, I/O pin-out, and firmware revision details are available upon request or in the WOODWARD LS-5 system technical manual.
Proven Application Environments
- Power Generation: Gas turbine and steam turbine generator sets using WOODWARD LS-5 governor systems
- Industrial Switchgear: Medium-voltage circuit breaker control panels requiring deterministic protection logic
- Cogeneration & Combined Heat and Power (CHP) Plants: Synchronization and breaker management in parallel generation configurations
- Oil & Gas Facilities: Compressor driver control systems with integrated breaker protection
- Marine Propulsion & Auxiliary Power: Vessel power management systems utilizing WOODWARD governor platforms
- MRO / Spare Parts Programs: Planned maintenance replacement for aging LS-5 installations
Engineering Advantages
- OEM Compatibility: Direct drop-in replacement for existing WOODWARD LS-5 8440-1946 installations — no firmware modification or recalibration required in standard configurations
- Deterministic Protection Logic: Hardware-level circuit breaker trip/close control minimizes latency in fault isolation sequences
- Robust Industrial Design: Engineered to WOODWARD’s industrial-grade standards for vibration, EMI, and thermal cycling tolerance
- Reduced Downtime Risk: Availability from Konmask stock eliminates factory lead times — critical for unplanned outage recovery
- Backplane Integration: Seamless integration with LS-5 system chassis; no additional interface hardware required
- Long Service Life: Designed for continuous-duty industrial operation with minimal scheduled maintenance
System Architecture & Signal Flow
Within the WOODWARD LS-5 platform, the 8440-1946 module occupies the control protection layer of the system architecture. Signal flow is as follows:
- Input Acquisition: The module receives breaker status signals (52a/52b contacts), protection relay trip commands, and governor control outputs via the LS-5 backplane.
- Logic Processing: Onboard control logic evaluates trip/close permissives, interlock conditions, and synchronization status.
- Output Actuation: Discrete output channels drive breaker coil circuits (trip coil / close coil) with appropriate current ratings and timing.
- Status Feedback: Breaker position and fault status are returned to the LS-5 HMI and historian via backplane communication.
- Fault Isolation: On detection of a protection event, the module executes a deterministic trip sequence and latches fault status for operator review.
Sourcing & Quality Verification
- Stock Origin: Sourced from authorized distributors, decommissioned OEM installations, and verified surplus channels
- Inspection Protocol: Each unit undergoes visual inspection, label verification (part number, revision, date code), and functional pre-check prior to dispatch
- Packaging: Anti-static ESD packaging with desiccant; outer carton rated for international freight
- Documentation: Certificate of conformance, inspection report, and original OEM label photographs provided on request
- Traceability: Batch and serial number records maintained for all units shipped
- Warranty: 12-month Konmask supply warranty against DOA and latent defects (terms apply)
Procurement Process
- Inquiry Submission: Contact Konmask via the product page, email, or WhatsApp with your required quantity and delivery timeline.
- Stock Confirmation & Quote: We confirm available stock, condition grade, and issue a formal quotation within 1 business day.
- Purchase Order: Submit your PO against the Konmask quotation. We accept T/T bank transfer, L/C, and major B2B payment platforms.
- Pre-Shipment Inspection: Optional third-party inspection or Konmask inspection report issued before dispatch.
- Shipping & Logistics: DHL / FedEx / freight forwarding options available. Export documentation (commercial invoice, packing list, COO) provided.
- After-Sales Support: Technical support and warranty claims handled directly by Konmask engineering team.
Technical FAQ
Q: Is the 8440-1946 compatible with all LS-5 system revisions?
A: The 8440-1946 is designed for the WOODWARD LS-5 platform. Compatibility with specific system revisions should be confirmed against your existing system’s BOM or WOODWARD documentation. Contact Konmask for pre-purchase compatibility verification.
Q: Can this module be used as a standalone circuit breaker controller outside of an LS-5 system?
A: No. The 8440-1946 is designed for integration within the LS-5 backplane architecture and requires the LS-5 system power supply and communication bus to operate.
Q: What is the typical lead time from Konmask stock?
A: In-stock units ship within 1–3 business days of PO confirmation. Express dispatch available for urgent requirements.
Q: Do you provide a test report or functional verification certificate?
A: Yes. A Konmask inspection report is available for all units. Third-party testing can be arranged at buyer’s cost.
Q: What is the minimum order quantity (MOQ)?
A: MOQ is 1 unit. Volume pricing is available for orders of 3 units or more — request a bulk quotation.
Q: Can Konmask source additional quantities if current stock is insufficient?
A: Yes. Konmask operates an active global sourcing network for WOODWARD components. Submit your requirement and we will provide a sourcing timeline.
