Variable Speed Drive Solution — YASKAWA CIMR-G7A43P7 | G7 Series
Where This Product Is Used
The YASKAWA CIMR-G7A43P7 is a 3.7 kW (5 HP), 480 V three-phase AC inverter drive from the G7 Series — one of YASKAWA’s most field-proven general-purpose drive platforms. It is specified across a wide range of industrial applications where precise motor speed control, energy efficiency, and robust protection are non-negotiable.
- Pump & Fan Control — HVAC systems, cooling towers, water treatment plants, and building management systems rely on the G7 for smooth flow regulation and significant energy savings via variable torque operation.
- Conveyor & Material Handling — Logistics centers, packaging lines, and assembly conveyors use the G7’s V/f and vector control modes to maintain precise belt speed under variable load.
- Machine Tool & CNC Spindle Drives — The G7’s high carrier frequency and low-noise PWM output make it suitable for spindle motor control in milling, turning, and grinding machines.
- Compressor & Blower Drives — Industrial compressors and process blowers benefit from the G7’s built-in PID controller and auto-tuning for stable pressure regulation.
- Crane & Hoist Applications — With dynamic braking support and torque boost functions, the G7 handles regenerative loads in overhead crane and hoist systems.
- Food & Beverage Processing — Wash-down-adjacent environments use the G7 with appropriate enclosures for mixer, agitator, and conveyor drives.
- Water & Wastewater Treatment — Municipal pump stations and aeration blowers leverage the G7’s multi-pump control and sleep/wake functions.
Technical Specifications
| Model Number | CIMR-G7A43P7 |
| Series | YASKAWA G7 |
| Output Power | 3.7 kW / 5 HP |
| Input Voltage | 380–480 V AC, 3-Phase |
| Output Voltage | 0–480 V AC, 3-Phase |
| Input Frequency | 50 / 60 Hz |
| Output Frequency Range | 0.1–400 Hz |
| Rated Output Current | 8.5 A (HD) / 9.2 A (ND) |
| Control Method | V/f, Open-Loop Vector, Closed-Loop Vector (Flux Vector) |
| Carrier Frequency | 2.0–15.0 kHz (adjustable) |
| Overload Capacity | 150% for 60 s (HD mode) |
| Protection Class | IP20 (NEMA 1 optional) |
| Braking | Dynamic braking transistor built-in |
| Communication | MEMOBUS/Modbus RTU (RS-485); optional DeviceNet, PROFIBUS, EtherNet/IP |
| Ambient Temperature | -10°C to +50°C (derating above 40°C) |
| Humidity | 95% RH max (non-condensing) |
| Altitude | Up to 1,000 m (derating above) |
| Approvals | UL, cUL, CE, RoHS |
| Weight | Approx. 3.5 kg |
Why Engineers Specify This Model
- Proven G7 Platform — The G7 series has accumulated millions of operating hours globally across heavy industry, making it a low-risk specification for critical processes.
- Flux Vector Control — Closed-loop vector mode delivers high starting torque (200% at 0 Hz with encoder feedback), essential for hoists, extruders, and servo-like positioning tasks.
- Built-in PID & Multi-Function I/O — Eliminates the need for external PLC logic in simple closed-loop applications such as pressure or flow control.
- Auto-Tuning — Rotational and stationary auto-tune routines reduce commissioning time and optimize motor performance without manual parameter calculation.
- Comprehensive Fault Diagnostics — Fault history log, output waveform monitoring, and DriveWizard PC software support rapid troubleshooting and predictive maintenance.
- Scalable Communication — Native Modbus RTU with optional fieldbus cards (DeviceNet, PROFIBUS-DP, EtherNet/IP) integrates seamlessly into existing SCADA and DCS architectures.
- Energy-Saving Functions — Energy-saving mode, sleep/wake, and DC injection braking reduce operating costs in pump and fan applications.
Complete System Bill of Materials
For a fully operational drive system using the CIMR-G7A43P7, engineers typically specify the following complementary components:
- Input Line Reactor — Reduces harmonic distortion and protects against voltage spikes from the supply network.
- EMC Filter — Required for CE compliance in residential or light-industrial environments (Class C2/C3).
- Dynamic Braking Resistor — External resistor unit for applications with frequent deceleration or regenerative loads (cranes, hoists).
- Output AC Reactor / dV/dt Filter — Protects motor insulation on long cable runs (>50 m) and reduces bearing current.
- Encoder Feedback Card (PG-B3 / PG-X3) — Required for closed-loop flux vector control mode.
- Fieldbus Option Card — SI-N3 (DeviceNet), SI-P3 (PROFIBUS-DP), SI-EN3 (EtherNet/IP) for network integration.
- Remote Operator / Keypad — JVOP-182 digital operator for remote panel mounting.
- NEMA 1 Conduit Kit — For UL-compliant enclosed panel installations.
Contact support@konmask.com to source any of the above accessories alongside your drive order.
Compliance & Industry Standards
- UL 508C — Power Conversion Equipment (North America)
- cUL — Canadian equivalent listing
- CE Marking — Low Voltage Directive (LVD) 2014/35/EU & EMC Directive 2014/30/EU
- RoHS Compliant — Restriction of Hazardous Substances
- IEC 61800-3 — Adjustable Speed Electrical Power Drive Systems (EMC)
- IEC 61800-5-1 — Safety requirements for adjustable speed drive systems
- SEMI F47 — Voltage sag immunity (semiconductor fab environments)
Quality Assurance & Sourcing
Konmask.com sources YASKAWA drives exclusively through verified industrial distribution channels and authorized surplus networks. Every unit offered is subject to the following quality process:
- Visual Inspection — Enclosure integrity, terminal condition, label legibility, and firmware version verification.
- Functional Power-On Test — Drive is energized and parameter read-back is confirmed prior to shipment where applicable.
- Authenticity Verification — Serial number cross-referenced against YASKAWA production records where available.
- Secure Packaging — Anti-static bag, foam-lined carton, and moisture-barrier packaging for international transit.
- Documentation — Original or copy of YASKAWA technical manual provided on request.
How to Source This Part
- Add to Cart — Click the purchase button above for immediate checkout.
- Request a Quote — Email support@konmask.com with your required quantity, delivery timeline, and destination country for a tailored commercial offer.
- Bulk / Project Orders — For OEM integrators and EPC contractors requiring 5+ units, contact us for volume pricing and lead-time commitment.
- Urgent Requirement — Call or WhatsApp +0086 19859288691 for same-day response on critical plant-down situations.
- Export & Cross-Border — We handle export documentation (commercial invoice, packing list, COO) for shipments to Southeast Asia, Middle East, Europe, and the Americas.
Application-Specific FAQ
Q: Can the CIMR-G7A43P7 run a 4 kW motor?
A: The G7A43P7 is rated for 3.7 kW in heavy-duty (HD) mode. Running a 4 kW motor is possible in normal-duty (ND) mode with the 9.2 A output rating, but verify the motor’s full-load current does not exceed this threshold. Consult YASKAWA’s drive sizing guidelines or contact us for confirmation.
Q: Is an encoder required for this drive?
A: No. The G7 operates in open-loop V/f or open-loop vector mode without an encoder. A PG feedback card is only required for closed-loop flux vector (zero-speed torque) applications.
Q: What fieldbus protocols are natively supported?
A: The drive natively supports MEMOBUS/Modbus RTU via the RS-485 port. DeviceNet, PROFIBUS-DP, and EtherNet/IP require optional SI-series option cards.
Q: Can this drive be used for single-phase input?
A: The CIMR-G7A43P7 is designed for three-phase 380–480 V input. Single-phase operation is not supported and will void the warranty.
Q: What is the typical lead time for this model?
A: In-stock units ship within 1–3 business days. For out-of-stock situations, lead time is typically 2–6 weeks depending on sourcing channel. Contact us for real-time availability.
Q: Do you provide a warranty?
A: Yes. Konmask.com provides a 90-day functional warranty on all drives sold. Extended warranty options are available on request.
