The Yaskawa JZRCR-YPU01C-1 and JZRCR-YPU01-1 Servopack servo drive units are core power conversion and motion control modules deployed inside Yaskawa’s DX100 and YRC1000 robot controller cabinets. These drives are found in high-cycle industrial environments including:
- Automotive body welding lines — spot welding and arc welding robots requiring precise multi-axis torque control
- Automotive assembly — door panel handling, windshield installation, and sealing robots
- General manufacturing — palletizing, pick-and-place, and material handling cells
- Metal fabrication — press tending and machine loading with Yaskawa MA, MH, and MS series robots
- Electronics assembly — high-speed component placement requiring sub-millisecond servo response
- Food & beverage packaging — hygienic-environment robots with continuous duty cycles
Compatible robot models include Yaskawa MA1400, MA1900, MH5, MH6, MH12, MH24, MS80W, and other 6-axis industrial robots paired with DX100 or YRC1000 controllers.
Technical Specifications
- Part Numbers: JZRCR-YPU01C-1 / JZRCR-YPU01-1 / JANCD-ABB04-E / SRDA-SDB14A01A-E
- Controller Compatibility: Yaskawa DX100, YRC1000
- Module Type: Servopack — AC Servo Drive Unit (power conversion board)
- Series: Servopack / SRDA / JANCD
- Function: Multi-axis servo amplifier providing current loop control, PWM output, and encoder feedback processing for robot joint motors
- Axes Supported: Up to 6 axes (robot axes R1–R6) depending on configuration
- Input Power: Three-phase AC (per DX100/YRC1000 cabinet specification)
- Communication Interface: Internal MECHATROLINK / proprietary Yaskawa backplane bus
- Mounting: Internal rack-mount within DX100 / YRC1000 controller cabinet
- Condition: New / Refurbished / Tested — specify at inquiry
- Weight: Approx. 300 g (module only, excluding cabinet)
Why Engineers Specify This Model
- OEM-matched performance — factory-spec servo response tuned for Yaskawa robot kinematics; no third-party compatibility risk
- Drop-in replacement — identical form factor and connector pinout to original DX100/YRC1000 installation; zero re-wiring required
- Minimizes downtime — a failed servo drive halts the entire robot cell; having a verified spare on-hand reduces MTTR from days to minutes
- Dual controller compatibility — a single SKU covers both DX100 and YRC1000 platforms, simplifying spare parts inventory management
- Proven in high-cycle duty — designed for 24/7 automotive production environments with millions of cycles between service intervals
Complete System Bill of Materials
For a fully operational DX100 / YRC1000 servo drive replacement, engineers typically source the following alongside this unit:
- JANCD-YCP01-E — CPU board (DX100 main controller)
- JANCD-YIF01-E — I/O interface board
- JANCD-ABB04-E — Servo amplifier board (included in this listing)
- SRDA-SDB14A01A-E — Servo drive base board (included in this listing)
- JZRCR-YPU01C-1 — Power unit board (included in this listing)
- Teach pendant cable assembly (DX100 / YRC1000 compatible)
- Encoder cable set for target robot model (MA/MH/MS series)
Compliance & Industry Standards
- CE Marking — compliant with EU Machinery Directive and Low Voltage Directive (OEM declaration)
- RoHS — Restriction of Hazardous Substances compliant (Yaskawa OEM specification)
- ISO 10218 — designed for integration into industrial robots meeting ISO 10218-1 safety requirements
- UL Listed — UL recognition applicable to DX100/YRC1000 controller system (system-level)
- IEC 61800 — adjustable speed electrical power drive systems standard
Quality Assurance & Sourcing
All Yaskawa servo drive units listed on Konmask.com undergo the following before shipment:
- ✔ Visual inspection for physical damage, burnt components, and connector integrity
- ✔ Power-on functional test where applicable
- ✔ Cross-reference verification of part number markings against Yaskawa OEM documentation
- ✔ Anti-static packaging with humidity indicator card
- ✔ Traceable sourcing from authorized distributors or decommissioned OEM equipment
Konmask specializes in industrial automation components for B2B buyers. We maintain stock of critical Yaskawa spare parts to support production continuity for manufacturing facilities worldwide.
How to Source This Part
- In-stock orders: Add to cart and complete checkout — global shipping available via DHL, FedEx, and UPS Express
- Bulk / project orders: Contact us for volume pricing and lead time confirmation
- Urgent breakdown support: Email [email protected] or call +0086 19859288691 for same-day response
- Cross-reference requests: Provide your robot model and controller serial number for compatibility confirmation
Application-Specific FAQ
Q: Is JZRCR-YPU01C-1 the same as JZRCR-YPU01-1?
A: These are closely related revision variants of the same power unit board. JZRCR-YPU01C-1 is a later revision. Both are functionally compatible with DX100 and YRC1000 controllers — confirm your controller serial number range with us if uncertain.
Q: Can this drive be used with a YRC1000micro controller?
A: The JZRCR-YPU01C-1 is designed for full-size DX100 and YRC1000 cabinets. The YRC1000micro uses a different, compact servo drive architecture. Contact us to confirm compatibility for your specific application.
Q: What causes Yaskawa servo drive failure in DX100 systems?
A: Common failure modes include capacitor degradation after 8–12 years of service, IGBT failure from voltage transients, and thermal fatigue in high-ambient-temperature installations. Alarm codes A.810, A.820, and A.8A0 on the teach pendant typically indicate servo drive faults.
Q: Do you provide a warranty?
A: Yes. All units carry a 90-day functional warranty against defects. Extended warranty options are available for project-critical applications — contact us for details.
Q: What is the lead time for out-of-stock units?
A: Typical lead time for sourced units is 3–10 business days depending on global availability. We maintain relationships with multiple authorized Yaskawa distribution channels.
