YASKAWA JZDP-D005-000 Conversion Cable | Replacement, Equivalent & Selection Guide
The YASKAWA JZDP-D005-000 is a dedicated conversion cable designed for use with YASKAWA Sigma-series servo drives and servo amplifiers. It serves as the encoder feedback interface cable, enabling reliable signal transmission between the servo motor encoder and the drive unit. This guide covers technical specifications, compatible replacements, application scenarios, and sourcing information to help engineers and procurement teams make informed decisions.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | JZDP-D005-000 |
| Manufacturer | YASKAWA Electric Corporation |
| Series | Sigma (Σ) Series |
| Cable Type | Encoder Conversion Cable |
| Application | Servo Drive ↔ Encoder Interface |
| Connector Type | Multi-pin D-sub / proprietary YASKAWA connector |
| Cable Length | Refer to YASKAWA datasheet for exact length |
| Weight | Approx. 1,250 g |
| Operating Temperature | 0°C to +60°C (standard servo environment) |
| Country of Origin | Japan |
| RoHS Compliance | Compliant |
Compatible Replacement & Equivalent Models
When the original JZDP-D005-000 is unavailable or requires substitution, the following models may serve as functional equivalents depending on your servo system configuration. Always verify connector pinout and cable length before substitution.
- JZDP-D005-E – Extended-temperature variant; same connector interface
- JZDP-A005-000 – Earlier Sigma-II series equivalent; verify drive compatibility
- JZDP-C005-000 – Sigma-III compatible conversion cable
- Third-party encoder cables – Must match YASKAWA encoder signal protocol (incremental/absolute) and connector pinout exactly
Note: Konmask.com recommends using genuine YASKAWA cables for safety-critical and high-precision applications. Contact our team for cross-reference verification.
Why Choose the Original JZDP-D005-000
- Signal Integrity: Factory-shielded cable minimizes EMI interference in servo feedback loops
- Plug-and-Play: Designed specifically for YASKAWA Sigma-series — no pinout adaptation required
- Reliability: Meets YASKAWA’s stringent QC standards for industrial servo environments
- Warranty Compliance: Using OEM cables preserves servo drive warranty coverage
- Long Service Life: Industrial-grade insulation rated for continuous flex and vibration
Typical Applications
- CNC machine tool servo axis feedback wiring
- Industrial robot joint encoder connections
- Semiconductor manufacturing equipment (pick-and-place, wafer handling)
- Packaging and labeling machinery
- Injection molding machine servo retrofit projects
- Conveyor and material handling automation systems
System Compatibility
The JZDP-D005-000 is compatible with the following YASKAWA servo drive families:
- YASKAWA Sigma-II (SGDH series) servo amplifiers
- YASKAWA Sigma-III (SGDS series) servo amplifiers
- YASKAWA Sigma-V (SGDV series) — verify specific variant
- YASKAWA SGMAH / SGMPH / SGMGH motor series encoders
Always cross-reference the servo amplifier model number and encoder type (incremental vs. absolute) before ordering.
Selection Guide
Use the following criteria to confirm JZDP-D005-000 is the correct cable for your application:
- Identify your servo amplifier model – Check the nameplate (e.g., SGDH-□□AE)
- Identify your motor encoder type – Incremental (13-bit) or Absolute (17-bit)
- Verify required cable length – Standard vs. custom length options
- Check connector gender and pinout – Match to drive CN2 port specification
- Confirm operating environment – Standard vs. high-flex or high-temperature variants
Not sure which cable you need? Contact our technical team with your servo drive model number for a free selection consultation.
Quality Assurance & Sourcing
- Source: Konmask.com sources YASKAWA components from authorized distributors and verified surplus channels
- Inspection: All cables undergo visual and continuity inspection prior to shipment
- Authenticity: Genuine YASKAWA part numbers with original packaging where available
- Traceability: Batch records maintained for B2B procurement compliance
- Warranty: 90-day replacement warranty on all stocked items
How to Order
- Add YASKAWA JZDP-D005-000 to cart and proceed to checkout
- For bulk orders (>5 units), contact support@konmask.com for volume pricing
- Lead time: In-stock items ship within 1–3 business days; special orders 7–15 business days
- Payment: T/T, PayPal, credit card accepted
- Shipping: DHL / FedEx / UPS international express available
Replacement & Compatibility FAQ
Q: Can I use a third-party encoder cable instead of JZDP-D005-000?
A: Technically possible if the pinout, shielding, and signal protocol match exactly. However, YASKAWA does not guarantee performance with non-OEM cables, and servo faults may occur. We recommend OEM cables for production environments.
Q: Is JZDP-D005-000 compatible with Sigma-7 (SGDV7) drives?
A: Sigma-7 uses a different encoder interface. Please contact us to confirm compatibility or identify the correct Sigma-7 cable.
Q: What is the difference between JZDP-D005-000 and JZDP-A005-000?
A: The “D” and “A” designations typically indicate different Sigma series generations and connector configurations. Cross-reference your drive’s CN2 port before substituting.
Q: Do you offer custom cable lengths?
A: Yes. Contact support@konmask.com with your required length and we will advise on availability.
Q: How do I verify the cable is genuine YASKAWA?
A: Genuine cables feature YASKAWA branding on the connector housing and cable jacket. We provide photos upon request before shipment.
