YASKAWA SGDV-5R4D11A020000 AC Servo Drive | Replacement, Equivalent & Selection Guide
The YASKAWA SGDV-5R4D11A020000 is a high-performance AC servo amplifier from the Σ-V (Sigma-V) Series, designed for precision motion control in industrial automation. This page provides full technical specifications, compatible replacement models, selection guidance, and sourcing information to help engineers and procurement teams make confident decisions.
Technical Specifications
| Parameter | Value |
|---|---|
| Model Number | SGDV-5R4D11A020000 |
| Brand | YASKAWA Electric |
| Series | Σ-V (Sigma-V) SERVOPACK |
| Rated Output Current | 5.4 A |
| Voltage Class | 200 V AC (Single/Three Phase) |
| Control Mode | Position / Speed / Torque |
| Interface | Analog / Pulse Train |
| Encoder Compatibility | Incremental / Absolute (Serial) |
| Communication | MECHATROLINK-II (optional) |
| Protection Class | IP20 |
| Weight | Approx. 1.87 kg |
| Cooling Method | Natural convection / Fan |
| Operating Temperature | 0 – 55 °C |
| Humidity | 20 – 90% RH (non-condensing) |
Compatible Replacement & Equivalent Models
The following models are commonly evaluated as replacements or equivalents for the SGDV-5R4D11A020000. Always verify electrical and mechanical compatibility before substitution.
| Model | Brand | Notes |
|---|---|---|
| SGDV-5R4D01A000000 | YASKAWA | Standard analog/pulse variant — same current rating, no option codes |
| SGDV-5R4D11A000000 | YASKAWA | Differs in option suffix; verify option card requirements |
| SGDV-7R6D11A020000 | YASKAWA | Next-up current class (7.6 A); use when motor requires higher current |
| SGDV-2R8D11A020000 | YASKAWA | Lower current class (2.8 A); suitable for smaller servo motors |
| SGDV-5R4F11A020000 | YASKAWA | 400 V class equivalent — confirm supply voltage before use |
| MR-J4-60B | Mitsubishi | Cross-brand reference; different wiring and tuning required |
| ASD-B2-0421-B | Delta | Budget alternative; reduced feature set vs. Σ-V |
⚠ Disclaimer: Cross-brand replacements require full re-engineering of wiring, parameters, and safety validation. Konmask.com recommends using genuine YASKAWA parts for critical applications.
Why Choose the Original SGDV-5R4D11A020000
- Proven Σ-V platform — widely deployed in semiconductor, machine tool, and packaging industries worldwide
- High-resolution encoder support — 20-bit absolute encoder for sub-micron positioning accuracy
- Advanced auto-tuning — reduces commissioning time significantly vs. manual tuning
- Vibration suppression — built-in notch filter and resonance suppression algorithms
- Compact footprint — optimized for tight cabinet installations
- Long service life — YASKAWA’s industrial-grade components rated for 24/7 continuous operation
Typical Applications
- CNC machine tools (milling, turning, grinding)
- Semiconductor wafer handling and inspection equipment
- Electronic assembly and SMT pick-and-place machines
- Packaging and labeling lines
- Robotics and multi-axis gantry systems
- Printing and converting machinery
- Medical device manufacturing equipment
System Compatibility
The SGDV-5R4D11A020000 is compatible with the following YASKAWA servo motor series:
- SGMJV — Small, high-speed motors (50 W – 1 kW)
- SGMAV — Medium inertia, general-purpose (50 W – 7 kW)
- SGMGV — Large capacity, high-torque (450 W – 15 kW)
- SGMSV — High-speed spindle motors
Compatible controllers include YASKAWA MP2000/MP3000 series machine controllers and third-party PLCs via pulse-train or analog command interfaces.
Selection Guide
Use the following criteria to confirm the SGDV-5R4D11A020000 is the right drive for your application:
- Motor rated current — must be ≤ 5.4 A continuous; check motor nameplate
- Supply voltage — confirm 200 V AC single or three-phase availability at installation site
- Control interface — verify PLC/controller outputs pulse-train or ±10 V analog command
- Option codes — decode the suffix 11A020000: interface type, option card slot, and safety function options
- Encoder type — match absolute or incremental encoder on the paired servo motor
- Ambient conditions — confirm cabinet temperature stays within 0–55 °C operating range
Not sure which model fits? Contact our technical team at support@konmask.com with your motor model and application details.
Quality Assurance & Sourcing
- All units sourced through verified industrial distribution channels
- Pre-shipment inspection: visual, label verification, and basic power-on test where applicable
- Genuine YASKAWA OEM parts — no counterfeit or refurbished units without explicit disclosure
- Traceability documentation available upon request (batch records, test reports)
- Warranty: 12 months from date of shipment against manufacturing defects
How to Order
- Confirm the exact model number: SGDV-5R4D11A020000
- Specify required quantity and delivery timeline
- Submit your inquiry via the product page or email support@konmask.com
- Receive quotation within 1 business day (stock items ship within 3–5 business days)
- Payment via T/T, PayPal, or trade assurance — contact us for terms
📞 WhatsApp / Phone: +0086 19859288691
Replacement & Compatibility FAQ
Q: Can I replace SGDV-5R4D11A020000 with SGDV-5R4D01A000000?
A: Yes, in most cases. The core drive hardware is identical; the suffix difference relates to option codes. Verify that no option card (e.g., safety, fieldbus) is required in your application before substituting.
Q: Is the SGDV-5R4D11A020000 compatible with MECHATROLINK-II?
A: The base model supports analog/pulse interface. MECHATROLINK-II requires the appropriate option module — check the option code in the model suffix or contact us to confirm.
Q: What servo motor should I pair with this drive?
A: Any YASKAWA Σ-V series motor with rated current ≤ 5.4 A and compatible encoder type. Common pairings include SGMAV-04A and SGMJV-04A motors.
Q: Can this drive be used with a non-YASKAWA motor?
A: Technically possible with analog/pulse interface, but not recommended. Motor parameter tuning, encoder compatibility, and safety compliance must be independently validated.
Q: Do you offer repair or exchange service?
A: Yes — contact us with your unit’s fault history and we can advise on repair vs. replacement economics.
