Yaskawa YRC1000 – High-Speed 6-Axis Robot Controller | Motoman Platform
Engineering Background: The YRC1000 is Yaskawa’s next-generation robot controller engineered for the Motoman series of 6-axis industrial robots. Launched as the successor to the DX200, it delivers a 25% reduction in cabinet volume while significantly improving cycle time performance through its high-speed CPU architecture and advanced motion interpolation algorithms. Designed for demanding 24/7 production environments, the YRC1000 is the control backbone for welding, handling, assembly, and painting automation cells worldwide.
Product Positioning: Targeted at automation engineers and system integrators requiring a compact, network-ready controller with deterministic real-time performance. The YRC1000 supports Yaskawa’s full Motoman robot lineup and is the preferred choice for new cell builds and legacy DX200 upgrades across automotive, electronics, food & beverage, and general manufacturing sectors.
Complete Technical Specifications
- Model: YRC1000
- Manufacturer: Yaskawa Electric Corporation
- Series / Platform: Motoman YRC Series
- Applicable Robots: Yaskawa Motoman 6-axis robots (GP, MH, AR, PL series)
- Number of Controlled Axes: Up to 8 axes (6 robot + 2 external)
- CPU: High-speed multi-core processor
- Memory: 60,000 steps / 10,000 instructions program capacity
- Teach Pendant: Smart Pendant (optional) or YPP-1 pendant
- I/O Points: 2048 inputs / 2048 outputs (max, with expansion)
- Standard I/O: 40 DI / 40 DO
- Fieldbus / Network: EtherNet/IP, PROFINET, DeviceNet, CC-Link (option cards)
- Communication Ports: USB × 2, LAN (100BASE-TX)
- Safety Standard: IEC 62061 SIL2 / ISO 13849-1 PLd
- Power Supply: 3-phase AC 200–480 V, 50/60 Hz
- Power Consumption: Varies by robot model (refer to robot spec sheet)
- Ambient Temperature: 0–45 °C (operating); −10–60 °C (storage)
- Humidity: 10–90% RH (non-condensing)
- Protection Rating: IP54 (controller cabinet)
- Cabinet Dimensions (W×H×D): 598 × 490 × 427 mm
- Weight: Approx. 56 kg
- Cooling Method: Forced air cooling
- Vibration Resistance: 4.9 m/s² (10–150 Hz)
- Certifications: CE, UL, CSA, KCs
- Country of Origin: Japan
Proven Application Environments
- Arc Welding: Paired with AR series robots for high-duty-cycle MIG/TIG welding cells
- Spot Welding: Automotive body-in-white lines with servo gun control
- Material Handling: High-speed pick-and-place with GP series robots
- Assembly: Electronics and precision component assembly with vision integration
- Painting & Coating: Explosion-proof configurations for paint booths
- Palletizing: End-of-line palletizing with PL series heavy-payload robots
- Machine Tending: CNC machine loading/unloading with external axis coordination
Engineering Advantages
- 25% Smaller Cabinet: Compared to DX200 — reduces floor space and simplifies cell layout
- High-Speed Motion: Improved path accuracy and shorter cycle times via advanced interpolation
- Dual Check Safety (DCS): Software-based safety zones eliminate external safety PLCs in many applications
- Smart Pendant Ready: Intuitive touchscreen pendant with job management and diagnostic tools
- Multi-Robot Coordination: Synchronized control of up to 8 robots from a single controller (with MotoSim)
- Open Network Architecture: Native EtherNet/IP and PROFINET support for seamless PLC/SCADA integration
- Energy Monitoring: Built-in power consumption tracking for sustainability reporting
- Backward Compatibility: Supports migration from DX200 programs with minimal rework
System Architecture & Signal Flow
The YRC1000 employs a distributed servo control architecture. The main CPU board handles trajectory planning and HMI communication, while dedicated servo amplifier boards manage real-time torque/velocity loops for each axis at 1 ms cycle time. I/O signals are processed through the integrated I/O board, with optional fieldbus interface cards installed in the expansion slots. The teach pendant communicates via a dedicated serial link, and external devices connect through the LAN port using Yaskawa’s MotoPlus SDK or standard fieldbus protocols. Safety signals (E-stop, safety gate, speed limit) are hardwired to the dual-channel safety circuit board, which is independently monitored by the DCS function.
Sourcing & Quality Verification
- All units sourced through authorized Yaskawa distribution channels or verified industrial surplus with full traceability
- Each unit undergoes incoming inspection: visual check, firmware version verification, and power-on functional test
- Serial number and manufacturing date verified against Yaskawa’s product database where applicable
- Units shipped with original documentation, parameter backup media, and calibration records when available
- Counterfeit-prevention: we do not source from unverified gray-market channels — all units carry documented chain of custody
Procurement Process
- Inquiry: Submit your robot model, application, and required delivery timeline to support@konmask.com
- Quotation: Receive a detailed quote within 1 business day including lead time and warranty terms
- Order Confirmation: Purchase order accepted via email or through our online checkout
- Quality Inspection: Unit inspected and documented before dispatch
- Shipping: Secure export packaging; DHL / FedEx / sea freight options available; export documentation provided
- After-Sales: 12-month warranty on new units; technical support via email and WhatsApp
Technical FAQ
Q: Is the YRC1000 compatible with older Motoman robots (e.g., UP series)?
A: No. The YRC1000 is designed for current-generation Motoman robots. Legacy UP/SK series robots require the NX100 or DX100 controller. Please confirm your robot model before ordering.
Q: Can the YRC1000 control external axes (positioners, tracks)?
A: Yes. The YRC1000 supports up to 2 additional external axes (total 8 axes) for coordinated motion with positioners or linear tracks.
Q: What fieldbus options are available?
A: Standard LAN (EtherNet/IP) is built-in. PROFINET, DeviceNet, and CC-Link require optional interface cards installed in the expansion slots.
Q: Is the Smart Pendant included?
A: The Smart Pendant (YPP-1 or touchscreen version) is an optional accessory. Please specify at time of order if required.
Q: What is the warranty period?
A: New units carry a 12-month warranty covering manufacturing defects. Refurbished units carry a 6-month warranty. Extended warranty available on request.
Q: Can you provide parameter backup and restore support?
A: Yes. We can assist with parameter file backup, transfer, and restoration for robot cell migration projects.
