Process Control & DCS Analog Input Solution — YOKOGAWA AAI835-H00 S1 | CENTUM Series
Where This Product Is Used
The YOKOGAWA AAI835-H00 S1 is a high-density analog input module deployed across demanding process industries where reliable field signal acquisition is mission-critical. Typical installation environments include:
- Oil & Gas Refineries — Continuous monitoring of pressure transmitters, flow meters, and temperature sensors across distillation columns and pipeline segments.
- Chemical & Petrochemical Plants — Multi-loop process control for reactor temperature, vessel pressure, and feed-flow regulation in CENTUM VP / CS 3000 DCS architectures.
- Power Generation Facilities — Boiler drum level, turbine inlet pressure, and flue-gas oxygen measurement integrated into plant-wide DCS networks.
- Pulp & Paper Mills — Digester pressure and consistency control loops requiring stable, noise-immune analog acquisition.
- Water & Wastewater Treatment — Flow, pH, and dissolved-oxygen sensor inputs feeding SCADA/DCS supervisory layers.
- Pharmaceutical Manufacturing — GMP-compliant process monitoring where signal integrity and audit-trail traceability are regulatory requirements.
Technical Specifications
| Part Number | AAI835-H00 S1 |
| Manufacturer | YOKOGAWA Electric Corporation |
| Compatible Platform | CENTUM VP / CENTUM CS 3000 DCS |
| Module Type | Analog Input (AI) |
| Channel Count | 16 channels (single module) |
| Input Signal Range | 4–20 mA DC (standard process current loop) |
| HART Communication | Supported (HART pass-through for smart field devices) |
| Isolation | Channel-to-channel and channel-to-bus isolation |
| Resolution | 16-bit A/D conversion |
| Accuracy | ±0.1% of full scale |
| Power Consumption | Per YOKOGAWA CENTUM VP hardware specification |
| Operating Temperature | 0°C to 60°C |
| Weight | 320 g |
| Form Factor | Standard CENTUM I/O module card |
| Suffix Codes | H00 = Standard; S1 = Safety Instrumented System variant |
Why Engineers Specify This Model
- High Channel Density — 16 AI channels per card minimizes cabinet footprint and reduces wiring cost in large-scale DCS marshalling rooms.
- HART Pass-Through — Enables remote device diagnostics and parameterization of smart transmitters without breaking the 4–20 mA loop, reducing maintenance downtime.
- S1 Safety Suffix — Designed for use in Safety Instrumented Systems (SIS), meeting IEC 61511 / IEC 61508 functional safety requirements where applicable.
- Proven CENTUM Ecosystem Compatibility — Drop-in replacement for existing CENTUM VP and CS 3000 installations; no firmware re-engineering required.
- Robust Isolation Architecture — Protects the DCS backplane from field-side ground loops, transients, and common-mode noise common in industrial environments.
- Long Product Lifecycle Support — YOKOGAWA maintains extended support for CENTUM platform modules, protecting capital investment in legacy DCS infrastructure.
Complete System Bill of Materials
For a fully operational CENTUM VP analog input subsystem, engineers typically specify the following alongside the AAI835-H00 S1:
- CENTUM VP Field Control Station (FCS) — e.g., AFV10D / AFV30D
- I/O Module Nest / Node Unit — ANB10D or equivalent
- Terminal Board — ATB series (screw or connector type)
- Field Wiring Cable — Shielded twisted-pair, 0.5 mm² minimum
- HART Multiplexer (optional) — For bulk HART device management
- Power Supply Module — APS series redundant PSU
- Engineering Workstation — CENTUM VP HIS with R6.xx software license
Compliance & Industry Standards
- IEC 61511 — Functional Safety: Safety Instrumented Systems for the Process Industry Sector (S1 variant)
- IEC 61508 — Functional Safety of E/E/PE Safety-Related Systems
- CE Marking — Compliant with EU EMC and Low Voltage Directives
- ATEX / IECEx — Consult YOKOGAWA datasheet for hazardous area classification applicability
- RoHS — Restriction of Hazardous Substances compliant
- NAMUR NE 43 — Standardized signal levels for fault state indication in 4–20 mA transmitters
Quality Assurance & Sourcing
Konmask.com sources YOKOGAWA modules through verified industrial automation supply channels. Every unit offered is:
- Inspected for physical integrity and label authenticity prior to listing
- Stored in ESD-safe, climate-controlled warehousing
- Shipped with original manufacturer packaging where available
- Traceable to batch/lot documentation upon request for regulated industries
- Covered by Konmask’s standard return and quality guarantee policy
We do not list counterfeit, refurbished-without-disclosure, or end-of-life modules without explicit labeling. Authenticity concerns? Contact our technical team before purchase.
How to Source This Part
- Confirm Compatibility — Verify your FCS node type and I/O nest revision against YOKOGAWA’s CENTUM VP hardware compatibility matrix (GS 33J60B10-01EN).
- Check Stock & Lead Time — Contact support@konmask.com for real-time inventory status and estimated delivery to your site.
- Request a Quote — For project quantities (3+ units), request a formal quotation with volume pricing and consolidated shipping options.
- Place Order — Add to cart and proceed to checkout, or submit a purchase order via email for B2B net-terms arrangements.
- Expedited Sourcing — Urgent plant shutdown or turnaround requirement? Call +0086 19859288691 for priority handling.
Application-Specific FAQ
Q: Is the AAI835-H00 S1 compatible with CENTUM CS 3000 as well as CENTUM VP?
A: Yes. The AAI835 series is designed for the CENTUM platform and is compatible with both CS 3000 and CENTUM VP node architectures. Always verify the specific node unit revision with YOKOGAWA’s hardware compatibility documentation.
Q: What does the “S1” suffix indicate?
A: The S1 suffix designates a Safety Instrumented System (SIS) variant, engineered to meet IEC 61511 functional safety requirements. It is specified for safety loops where SIL (Safety Integrity Level) certification is required.
Q: Can I use this module with third-party HART configurators?
A: HART pass-through is supported. Standard HART communicators (e.g., Emerson 475/375) and HART-over-IP solutions are compatible when used with the appropriate CENTUM HART multiplexer configuration.
Q: What is the typical lead time for this module?
A: Lead time varies by stock availability. Contact support@konmask.com with your project timeline for a confirmed delivery estimate. Expedited options are available for shutdown/turnaround scenarios.
Q: Do you provide documentation such as datasheets or wiring diagrams?
A: Yes. YOKOGAWA general specifications (GS) and installation manuals are available upon request. Contact our technical team with your part number and application details.
Q: Can Konmask supply multiple modules for a large DCS expansion project?
A: Yes. We support project-quantity procurement with consolidated shipping, formal quotations, and B2B purchase order processing. Reach out via email for project-scale sourcing.
