Temperature Measurement Solution — YOKOGAWA AAR145-S03 S1 | CENTUM VP / CS 3000 Series
Where This Product Is Used
The YOKOGAWA AAR145-S03 S1 is a dedicated RTD (Resistance Temperature Detector) and Potentiometer Input Module designed for high-precision temperature and position measurement in demanding industrial environments. Typical deployment sites include:
- Oil & Gas Refineries — reactor temperature monitoring, heat exchanger control loops
- Chemical & Petrochemical Plants — multi-point RTD scanning for distillation columns and reactors
- Power Generation — turbine bearing temperature surveillance, boiler feed-water control
- Pharmaceutical Manufacturing — GMP-compliant temperature logging in clean-room processes
- Pulp & Paper / Food & Beverage — continuous process temperature regulation requiring IEC-traceable accuracy
- Water & Wastewater Treatment — potentiometer-based valve position feedback integrated into CENTUM VP DCS
Technical Specifications
| Part Number | AAR145-S03 S1 |
| Manufacturer | YOKOGAWA Electric Corporation |
| Module Type | RTD / Potentiometer Analog Input |
| Compatible Platform | CENTUM VP, CENTUM CS 3000 |
| Input Channels | Multi-channel (per S03 suffix configuration) |
| RTD Types Supported | Pt100, Pt1000, JPt100, Ni100 (IEC 60751 / JIS C 1604) |
| Potentiometer Input | 0–10 kΩ (typical) |
| Accuracy | ±0.1°C (RTD mode, typical) |
| Isolation | Channel-to-channel and channel-to-bus isolation |
| Communication | YOKOGAWA proprietary V-net / ESB bus |
| Power Supply | Supplied via I/O bus backplane |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -20°C to +70°C |
| Humidity | 5% to 95% RH (non-condensing) |
| Weight | Approx. 300 g |
| Suffix S1 | CE Mark / ATEX-ready suffix designation |
Why Engineers Specify This Model
- Native CENTUM VP Integration — plug-and-play compatibility with YOKOGAWA’s flagship DCS eliminates custom driver development and reduces commissioning time.
- Dual-Mode Input Flexibility — a single module handles both RTD and potentiometer signals, reducing panel footprint and spare-parts inventory.
- High Measurement Accuracy — ±0.1°C resolution meets the stringent requirements of pharmaceutical and specialty chemical processes.
- Robust Isolation Architecture — channel-to-channel isolation prevents ground-loop interference in multi-sensor installations across large plant areas.
- Long Product Lifecycle Support — YOKOGAWA’s extended support policy for CENTUM platform modules ensures availability of firmware updates and technical documentation.
- Hot-Swap Capable — supports online replacement within the CENTUM VP architecture, minimizing unplanned downtime during maintenance windows.
Complete System Bill of Materials
For a fully operational RTD input subsystem within CENTUM VP, engineers typically specify the following alongside the AAR145-S03 S1:
- YOKOGAWA AFV10D / AFV30D — Field Control Unit (FCU) or Node Unit
- YOKOGAWA AIP588 — I/O Bus Interface Module
- YOKOGAWA ANT100 / ANT200 — Node Terminal Board
- YOKOGAWA KS1 / KS2 — I/O Module Mounting Base
- Shielded 3-wire or 4-wire RTD field cables (IEC 60751 compliant)
- YOKOGAWA CENTUM VP Engineering Workstation (EWS) license for I/O configuration
Compliance & Industry Standards
- CE Marking — EMC Directive 2014/30/EU; Low Voltage Directive 2014/35/EU
- IEC 61131-2 — Programmable Controllers: Equipment Requirements and Tests
- IEC 60751 — Industrial Platinum Resistance Thermometers
- JIS C 1604 — Japanese Industrial Standard for Resistance Thermometers
- RoHS Compliant — Directive 2011/65/EU (Restriction of Hazardous Substances)
- ATEX / IECEx — Suffix S1 designation supports hazardous area installation documentation (verify zone classification with project engineer)
Quality Assurance & Sourcing
Konmask.com sources YOKOGAWA AAR145-S03 S1 modules through established industrial automation supply channels. Each unit offered is:
- Inspected for physical integrity and label authenticity prior to listing
- Stored in ESD-safe, climate-controlled warehousing
- Shipped with original manufacturer packaging where available
- Accompanied by a traceable lot/serial record for your maintenance documentation
We do not list modules with missing firmware, damaged connectors, or unverifiable provenance. If you require a Factory Acceptance Test (FAT) report or third-party inspection certificate, contact us before ordering.
How to Source This Part
- Confirm compatibility — verify your CENTUM VP / CS 3000 system revision and I/O bus type against the AAR145 series datasheet.
- Check quantity & lead time — contact support@konmask.com or call +0086 19859288691 for real-time stock confirmation.
- Request a quotation — provide your project PO number, delivery address, and any inspection requirements.
- Place your order — secure checkout via this product page or via direct invoice for B2B accounts.
- Receive & verify — inspect the module against the packing list; contact us within 5 business days if any discrepancy is found.
Application-Specific FAQ
Q: Can the AAR145-S03 S1 be used with CENTUM CS 3000 as well as CENTUM VP?
A: Yes. The AAR145 series is compatible with both CENTUM CS 3000 and CENTUM VP platforms. Confirm the specific I/O bus revision with your YOKOGAWA system integrator.
Q: What is the difference between the S03 and other suffix variants (e.g., S04, S06)?
A: The suffix denotes the number of input channels and/or input type configuration. S03 typically indicates a specific channel count optimized for RTD/POT inputs. Refer to YOKOGAWA GS document for the full suffix matrix.
Q: Is this module suitable for 2-wire RTD connections?
A: The AAR145 supports 3-wire and 4-wire RTD configurations for optimal accuracy. 2-wire connections are possible but will introduce lead resistance error; consult your process engineer for acceptability.
Q: Can I replace this module online without shutting down the controller?
A: CENTUM VP supports online module replacement (hot-swap) for I/O modules. Confirm this capability is enabled in your system configuration before performing live replacement.
Q: Do you provide a warranty on this module?
A: We offer a 90-day functional warranty on all modules sold through Konmask.com. Extended warranty and on-site support arrangements are available — contact us for details.
