YOKOGAWA MX100-E-1F – High-Accuracy Modular Data Acquisition Unit | DARWIN Series
Engineering Background
The YOKOGAWA MX100-E-1F is a core component of the DARWIN MX100 modular data acquisition platform, engineered for precision multi-channel measurement in demanding industrial and laboratory environments. YOKOGAWA’s DARWIN series has been the benchmark for high-channel-count DAQ systems across process industries, R&D facilities, and quality assurance labs worldwide.
Product Positioning
The MX100-E-1F serves as the Ethernet-connected main unit of the MX100 system, enabling distributed, scalable data acquisition with real-time PC connectivity. It is purpose-built for procurement engineers who require traceable, high-integrity measurement data with minimal integration overhead. Whether deployed in thermal testing, structural monitoring, or process validation, the MX100-E-1F delivers the accuracy and reliability that YOKOGAWA is globally recognized for.
Complete Technical Specifications
- Model: MX100-E-1F
- Series / Platform: DARWIN MX100
- Manufacturer: YOKOGAWA Electric Corporation (Japan)
- Unit Type: Main Unit (Ethernet Interface)
- Communication Interface: 100BASE-TX Ethernet (RJ-45)
- Module Slots: Up to 6 input/output modules per main unit
- Max Channels: Up to 60 channels per main unit (10 ch/module × 6 slots)
- Measurement Types: Voltage, thermocouple, RTD, resistance, current (module-dependent)
- Sampling Rate: Up to 10 ms/channel (module-dependent)
- A/D Resolution: 16-bit
- Internal Memory: Built-in flash memory for data storage
- Display: None (PC-controlled via DAQSTANDARD software)
- Power Supply: 100–240 VAC, 50/60 Hz
- Power Consumption: Max 30 VA
- Operating Temperature: 0 to 50°C
- Storage Temperature: -20 to 60°C
- Humidity: 20 to 80% RH (non-condensing)
- Dimensions (W × H × D): 215 × 132 × 110 mm (approx.)
- Weight: Approx. 1.6 kg (main unit only, without modules)
- Protection Class: IP20
- Compliance: CE, UL, CSA
- Software: Compatible with YOKOGAWA DAQSTANDARD (included)
- Country of Origin: Japan
Proven Application Environments
- Thermal & Environmental Testing: Multi-point temperature profiling in climatic chambers, burn-in racks, and HALT/HASS systems
- Process Industry R&D: Pilot plant monitoring, reaction kinetics measurement, and process validation in chemical and pharmaceutical sectors
- Structural & Mechanical Testing: Strain gauge, load cell, and vibration data logging in automotive and aerospace test rigs
- Quality Assurance Labs: Calibration traceability and SPC data collection in ISO-certified manufacturing facilities
- Energy & Power Monitoring: Voltage and current logging in power electronics test benches and grid simulation environments
- Academic & Research Institutions: High-channel-count data capture for materials science, HVAC research, and sensor characterization
Engineering Advantages
- Modular Scalability: Mix and match up to 6 I/O modules per main unit; expand to multiple units over a single Ethernet network for 100+ channel systems
- High Measurement Accuracy: YOKOGAWA’s proprietary signal conditioning delivers ±0.05% rdg accuracy on voltage inputs, exceeding most competitive DAQ platforms
- Ethernet-Native Architecture: Direct PC integration without proprietary bus cards; compatible with standard IT infrastructure and remote monitoring setups
- Isolated Channel Design: Each module provides channel-to-channel isolation, eliminating ground loop errors in mixed-signal environments
- DAQSTANDARD Software: Intuitive configuration, real-time display, and data export (CSV, Excel) without custom programming
- Long-Term Reliability: YOKOGAWA’s industrial-grade components and rigorous QC ensure MTBF performance suitable for 24/7 continuous operation
System Architecture & Signal Flow
The MX100-E-1F operates as the central controller and communication hub of the MX100 DAQ system. Field signals are conditioned and digitized at the I/O module level (e.g., MX110-V-H8, MX112-T-H8 thermocouple modules), then aggregated by the main unit’s internal bus. Digitized data is timestamped and transmitted via 100BASE-TX Ethernet to a host PC running DAQSTANDARD software. The main unit also manages internal flash storage for standalone logging when PC connectivity is interrupted, ensuring no data loss during network events. Multiple MX100-E-1F units can be synchronized over Ethernet for large-scale distributed measurement campaigns.
Sourcing & Quality Verification
- All YOKOGAWA MX100-E-1F units supplied by Konmask.com are sourced from authorized distribution channels or verified surplus inventories with full traceability documentation
- Each unit undergoes incoming inspection including visual examination, label verification (model, serial number, firmware revision), and functional power-on check prior to dispatch
- Original YOKOGAWA factory calibration certificates and test reports are provided where available; third-party calibration can be arranged upon request
- Packaging: original YOKOGAWA anti-static packaging or equivalent ESD-safe export carton with foam cushioning; weight approx. 1.6 kg
Procurement Process
- Inquiry & Quotation: Submit your RFQ via the product page or email support@konmask.com with quantity, required delivery date, and any special documentation requirements
- Stock Confirmation: Our team confirms availability, lead time, and unit condition (new / refurbished / surplus) within 1 business day
- Order Placement: Proceed via the Konmask.com checkout or request a formal proforma invoice for corporate PO processing
- Quality Inspection & Dispatch: Units are inspected, photographed, and packed; tracking information provided within 24 hours of shipment
- After-Sales Support: Technical assistance, datasheet provision, and warranty claims handled by our engineering support team
Technical FAQ
Q: What I/O modules are compatible with the MX100-E-1F?
A: The MX100-E-1F accepts all MX100-series I/O modules, including voltage (MX110), thermocouple (MX112), RTD (MX114), current (MX116), and digital I/O (MX120) modules. Contact us for module availability.
Q: Can the MX100-E-1F operate without a PC connection?
A: Yes. The main unit includes internal flash memory for standalone data logging. Data can be retrieved via Ethernet once PC connectivity is restored.
Q: What software is required?
A: YOKOGAWA DAQSTANDARD software (Windows-compatible) is the primary interface. The unit also supports communication via standard TCP/IP commands for custom integration.
Q: Is calibration documentation available?
A: Original factory calibration certificates are provided where available. Third-party ISO-17025 calibration can be arranged at additional cost.
Q: What is the warranty policy?
A: Konmask.com provides a 90-day functional warranty on all units. Extended warranty and service contracts are available upon request.
Q: Can you supply multiple units for a large project?
A: Yes. We handle volume procurement inquiries. Please contact support@konmask.com with your project requirements for a tailored quotation.
