Process Automation Input Solution – YOKOGAWA NFAI141-S00 | STARDOM FCN/FCJ Series
Where This Product Is Used
The YOKOGAWA NFAI141-S00 is a field-proven analog current/voltage input module deployed across demanding industrial environments where signal accuracy and system reliability are non-negotiable. Typical application sites include:
- Oil & Gas Upstream/Midstream: Flow transmitter signal acquisition on wellhead RTU panels and pipeline SCADA nodes running STARDOM FCN controllers.
- Power Generation & Utilities: Turbine governor feedback loops, generator excitation monitoring, and substation automation where 4–20 mA loop integrity is critical.
- Chemical & Petrochemical Plants: Pressure, temperature, and level transmitter inputs integrated into DCS/hybrid control architectures alongside CENTUM VP systems.
- Water & Wastewater Treatment: Remote pump station telemetry, flow metering, and dosing control via STARDOM FCJ compact controllers.
- Pharmaceutical & Food Processing: Clean-room process variable monitoring requiring high-resolution analog acquisition with galvanic isolation.
- Marine & Offshore Platforms: Harsh-environment signal conditioning for ballast control, cargo monitoring, and engine room automation.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | NFAI141-S00 |
| Manufacturer | YOKOGAWA Electric Corporation |
| Compatible Platform | STARDOM FCN / FCJ Autonomous Controllers |
| Module Type | Analog Input (AI) |
| Number of Channels | 4 Channels |
| Input Signal Range | 4–20 mA (current) / 1–5 V (voltage) |
| Resolution | 16-bit A/D conversion |
| Isolation | Channel-to-channel and channel-to-bus galvanic isolation |
| Accuracy | ±0.1% of full scale (at 25°C) |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -25°C to +70°C |
| Power Consumption | Supplied via backplane bus |
| Mounting | STARDOM FCN/FCJ base unit slot |
| Weight | Approx. 250 g |
| Certifications | CE, UL, cUL, ATEX (zone 2 capable with barrier) |
Why Engineers Specify This Model
- High-Resolution 16-bit ADC: Delivers ±0.1% full-scale accuracy, meeting the precision demands of custody-transfer metering and safety-critical loops.
- Dual-Mode Input (mA / V): A single module handles both 4–20 mA transmitters and 1–5 V sensors, reducing spare-part SKU count and simplifying panel design.
- Full Galvanic Isolation: Eliminates ground-loop interference in multi-drop field wiring — essential for long cable runs in oil & gas and utility installations.
- Native STARDOM Integration: Plug-and-play slot compatibility with FCN/FCJ base units; no external signal conditioners or marshalling panels required.
- Compact Form Factor: Maximizes I/O density in space-constrained RTU enclosures and offshore junction boxes.
- Long Product Lifecycle: YOKOGAWA’s commitment to 10+ year parts availability reduces lifecycle cost and obsolescence risk for long-horizon plant projects.
Complete System Bill of Materials
For a fully operational STARDOM FCN analog input node, engineers typically specify the following alongside the NFAI141-S00:
- YOKOGAWA FCN Controller Base Unit (e.g., NFBU100-S00)
- YOKOGAWA FCN Power Supply Module (e.g., NFPS100-S00)
- YOKOGAWA FCN CPU Module (e.g., NFCP100-S00)
- Field terminal blocks / marshalling connectors (DIN-rail, 24 VDC loop power)
- HART-compatible field transmitters (pressure, temperature, flow, level)
- Zener barriers or galvanic isolators (for Zone 0/1 hazardous area wiring)
- YOKOGAWA FAST/TOOLS or Exaopc OPC server for SCADA integration
Compliance & Industry Standards
- CE Marking — EMC Directive 2014/30/EU & Low Voltage Directive 2014/35/EU
- UL / cUL Listed — UL 508 Industrial Control Equipment
- IEC 61131-2 — Programmable Controllers: Equipment Requirements & Tests
- IEC 61000-4 Series — EMC Immunity (ESD, EFT, Surge, Conducted RF)
- ATEX / IECEx Zone 2 — Suitable for use in Zone 2 hazardous areas when installed with certified barriers
- RoHS Compliant — Directive 2011/65/EU
Quality Assurance & Sourcing
Every NFAI141-S00 unit offered through Konmask.com undergoes a structured verification process before dispatch:
- Visual Inspection: Connector pins, PCB surface, label legibility, and housing integrity checked against OEM reference standards.
- Functional Verification: Where test fixtures are available, modules are bench-tested for channel response and communication handshake with FCN base units.
- Traceability: Serial number and firmware revision documented; original YOKOGAWA packaging retained where available.
- Sourcing Channels: Procured from authorized distributors, decommissioned plant upgrades, and certified secondary-market partners — never counterfeit or refurbished-without-disclosure.
- Warranty: 90-day operational warranty against DOA defects; extended coverage available on request.
How to Source This Part
- Add to Cart — Stock is allocated on a first-confirmed basis. Submit your order to reserve the unit.
- Request a Quote — For quantities ≥ 3 units or project BOM pricing, email support@konmask.com with your project details.
- Lead Time — In-stock units ship within 1–3 business days (DHL Express / FedEx International Priority). ETA to most destinations: 5–10 business days.
- Export Compliance — YOKOGAWA modules may be subject to export licensing requirements. Buyers are responsible for compliance with applicable regulations in their jurisdiction.
- Payment — T/T (wire transfer), PayPal, and major credit cards accepted. LC available for orders above USD 5,000.
Application-Specific FAQ
Q: Is the NFAI141-S00 compatible with YOKOGAWA CENTUM VP or ProSafe-RS?
A: No. The NFAI141-S00 is designed exclusively for the STARDOM FCN/FCJ platform. For CENTUM VP, specify the AAI141-S00 or AAI143-S00 series. For ProSafe-RS, consult the SCP400 I/O module lineup.
Q: Can this module accept HART signals from smart transmitters?
A: The NFAI141-S00 passes the 4–20 mA analog signal; native HART digital communication requires a HART multiplexer or a HART-enabled variant. Confirm with your YOKOGAWA system integrator.
Q: What is the maximum cable length for field wiring?
A: YOKOGAWA recommends shielded twisted-pair cable with a maximum loop resistance of 600 Ω for 4–20 mA inputs. Practical cable runs of 300–500 m are typical in plant environments.
Q: Is this module suitable for SIL-rated safety loops?
A: The NFAI141-S00 is a standard (non-SIL) module. For IEC 61511 safety instrumented systems, use YOKOGAWA ProSafe-RS SIL-certified I/O modules.
Q: Do you provide a certificate of conformance (CoC)?
A: Yes. A CoC is available upon request for all units. Contact support@konmask.com before placing your order if CoC is a project requirement.
