Fieldbus Automation Solution – YOKOGAWA NFTB5S-00 | STARDOM FCN/FCJ Series
Where This Product Is Used
The YOKOGAWA NFTB5S-00 Fieldbus Communication Module is purpose-built for industrial environments where reliable, deterministic communication between field devices and control systems is mission-critical. Typical deployment scenarios include:
- Oil & Gas Processing Plants – Connecting pressure transmitters, flow meters, and control valves over FOUNDATION Fieldbus H1 segments in upstream and downstream facilities.
- Chemical & Petrochemical Plants – Integrating multi-vendor field instruments into YOKOGAWA STARDOM FCN/FCJ distributed control architectures.
- Power Generation Facilities – Enabling real-time diagnostics and control loop monitoring across turbine and boiler instrumentation networks.
- Water & Wastewater Treatment – Providing robust fieldbus communication in harsh, electrically noisy environments with intrinsic safety requirements.
- Pharmaceutical Manufacturing – Supporting GMP-compliant process control with deterministic data exchange and full audit trail capability.
- Pulp & Paper Mills – Coordinating distributed I/O and field device management across large-scale continuous process lines.
Technical Specifications
- Part Number: NFTB5S-00
- Manufacturer: YOKOGAWA Electric Corporation
- Series: STARDOM FCN / FCJ
- Module Type: Fieldbus Communication Module
- Communication Protocol: FOUNDATION Fieldbus H1
- Fieldbus Segments: Supports multiple H1 segments per module
- Mounting: DIN rail / backplane slot (FCN/FCJ chassis)
- Power Supply: Supplied via FCN/FCJ backplane
- Operating Temperature: 0°C to 55°C
- Storage Temperature: -20°C to 70°C
- Humidity: 5% to 95% RH (non-condensing)
- Weight: Approx. 600 g
- Certifications: CE, UL (refer to YOKOGAWA datasheet for full listing)
- Country of Origin: Japan
Why Engineers Specify This Model
- Native STARDOM Integration – Designed as a first-party module for the FCN/FCJ platform, ensuring zero compatibility risk and full firmware support from YOKOGAWA.
- Deterministic Fieldbus Communication – FOUNDATION Fieldbus H1 delivers time-synchronized, peer-to-peer control at the field level, reducing scan-cycle latency versus traditional 4–20 mA wiring.
- Reduced Wiring Complexity – A single H1 segment supports up to 32 field devices, dramatically cutting cable runs and junction box count in greenfield and brownfield projects.
- Advanced Device Diagnostics – Enables NAMUR NE 107 condition monitoring and predictive maintenance alerts directly from field instruments without additional hardware.
- Long-Term Vendor Support – YOKOGAWA’s global service network and long product lifecycle policy protect capital investment over 10+ year plant operating horizons.
- Interoperability – Compliant with the Fieldbus Foundation interoperability standard, supporting multi-vendor device integration without custom drivers.
Complete System Bill of Materials
For a complete STARDOM FCN/FCJ fieldbus node, engineers typically specify the following alongside the NFTB5S-00:
- YOKOGAWA FCN Autonomous Controller (e.g., NFCP010-S00)
- FCN/FCJ Power Supply Module
- FCN/FCJ Base/Chassis Unit
- FOUNDATION Fieldbus H1 Segment Coupler / Power Conditioner
- Fieldbus-compatible field instruments (transmitters, positioners, analyzers)
- YOKOGAWA FAST/TOOLS or PRM (Plant Resource Manager) for device management
- Shielded Fieldbus cable (Type A, per IEC 61158-2)
Compliance & Industry Standards
- IEC 61158-2 – Physical layer standard for FOUNDATION Fieldbus H1
- IEC 61784 – Communication profile families for industrial networks
- NAMUR NE 107 – Self-monitoring and diagnosis of field devices
- CE Marking – Electromagnetic compatibility and low voltage directive compliance
- UL Listed – North American safety certification (verify current listing with YOKOGAWA)
- RoHS Compliant – Restriction of hazardous substances in electrical equipment
Quality Assurance & Sourcing
Konmask.com specializes in sourcing genuine industrial automation components from verified supply chains. Every YOKOGAWA NFTB5S-00 unit we supply undergoes the following process:
- Visual and dimensional inspection against OEM reference standards
- Label and serial number authenticity verification
- Functional power-on check where applicable
- Anti-static packaging with humidity indicator cards
- Full traceability documentation available on request
We maintain stock of both new-surplus and factory-refurbished units. Condition is clearly stated on each listing. All units ship with a 90-day warranty against defects in materials and workmanship.
How to Source This Part
- Request a Quote: Contact us at support@konmask.com for volume pricing, lead time, and availability confirmation.
- Urgent Requirements: Call or WhatsApp +0086 19859288691 for same-day response on critical spares.
- OEM Cross-Reference: This module is also referenced in YOKOGAWA engineering documents as part of the STARDOM FCN/FCJ I/O expansion family.
- Export & Shipping: We ship worldwide with full export documentation, including commercial invoice, packing list, and certificate of origin.
Application-Specific FAQ
Q: Is the NFTB5S-00 compatible with FOUNDATION Fieldbus HSE (High Speed Ethernet)?
A: No. The NFTB5S-00 is an H1 fieldbus module. For HSE connectivity, refer to YOKOGAWA’s dedicated HSE linking device modules.
Q: How many H1 segments does one NFTB5S-00 support?
A: Please refer to the YOKOGAWA STARDOM FCN/FCJ hardware manual (IM 34M06H11-01E) for the exact segment count per module slot. Contact us if you need the datasheet.
Q: Can this module be used in SIL-rated safety loops?
A: The NFTB5S-00 is a standard process control module. For SIL 2/3 safety instrumented systems, YOKOGAWA’s ProSafe-RS platform should be specified instead.
Q: What firmware version is required on the FCN controller?
A: Firmware compatibility depends on your FCN/FCJ revision. Contact YOKOGAWA or Konmask.com with your controller serial number for a compatibility matrix.
Q: Do you offer installation or commissioning support?
A: We can connect you with certified YOKOGAWA system integrators in your region. Contact us for a referral.
