YOKOGAWA SAT145-S65 – Multi-Channel Temperature Input Module | CENTUM VP / CS 3000 DCS Platform
Engineering Background
The SAT145-S65 is a high-precision temperature input module engineered by Yokogawa Electric Corporation — a global leader in industrial automation and process control instrumentation. Designed as a native I/O card for the CENTUM VP and CS 3000 Distributed Control Systems, this module delivers reliable multi-channel thermocouple and RTD signal acquisition in demanding process environments including oil & gas, petrochemical, power generation, and pharmaceutical manufacturing.
Product Positioning
Targeting process automation engineers and DCS integrators who require OEM-grade, drop-in replacement modules with guaranteed compatibility, the SAT145-S65 eliminates the risk of signal drift, firmware mismatch, and integration downtime. Sourced directly through verified industrial channels, this module is a trusted choice for both greenfield installations and brownfield upgrades.
Complete Technical Specifications
| Part Number / SKU | SAT145-S65 |
| Manufacturer | YOKOGAWA Electric Corporation |
| Module Type | Temperature Input Module (Thermocouple / RTD) |
| Compatible Platform | CENTUM VP, CENTUM CS 3000 |
| Signal Types Supported | Thermocouple (B, E, J, K, N, R, S, T), RTD (Pt100, Pt1000, JPt100) |
| Number of Input Channels | Multi-channel (refer to OEM datasheet for channel count) |
| Input Isolation | Channel-to-channel isolation |
| Measurement Accuracy | ±0.1% of span (typical) |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -20°C to +70°C |
| Power Supply | Supplied via DCS backplane bus |
| Communication Interface | Internal DCS bus (CENTUM VP / CS 3000 native) |
| Module Weight | Approx. 1,370 g |
| Country of Origin | Japan |
| Certifications | CE, UL (refer to OEM documentation) |
| RoHS Compliance | Yes |
Proven Application Environments
- Oil & Gas: Upstream wellhead temperature monitoring, downstream refinery process control loops
- Petrochemical: Reactor temperature profiling, distillation column control
- Power Generation: Boiler temperature acquisition, turbine inlet/outlet monitoring
- Pharmaceutical: GMP-compliant temperature logging in batch reactors and clean rooms
- Pulp & Paper: Dryer section temperature control and process optimization
- Water Treatment: Thermal process monitoring in municipal and industrial plants
Engineering Advantages
- Native DCS Compatibility: Plug-and-play integration with CENTUM VP and CS 3000 — no firmware patching or custom configuration required
- Universal Sensor Support: Accepts all major thermocouple types and Pt100/Pt1000 RTD inputs on a single module, reducing spare parts inventory
- High Measurement Accuracy: ±0.1% of span ensures process data integrity for closed-loop PID control
- Channel Isolation: Prevents ground loops and cross-channel interference in multi-sensor installations
- Hot-Swap Capable: Supports online module replacement within CENTUM VP architecture, minimizing process downtime
- Compact Form Factor: Standard CENTUM I/O card footprint for seamless rack integration
System Architecture & Signal Flow
The SAT145-S65 mounts directly into the CENTUM VP or CS 3000 I/O unit (IOU) rack. Field thermocouple and RTD wiring terminates at the module’s front-face terminal block or marshalling cabinet via the associated terminal board. The module performs on-board cold junction compensation (CJC) for thermocouple inputs and 3-wire/4-wire RTD linearization, converting raw sensor signals to engineering-unit values transmitted over the internal DCS bus to the Field Control Station (FCS). The FCS then executes control logic and communicates with the Human Interface Station (HIS) via the Vnet/IP control network.
Typical Signal Path: Field Sensor → SAT145-S65 Terminal Block → A/D Conversion & CJC → DCS Bus → FCS Control Logic → HIS / SCADA
Sourcing & Quality Verification
- All modules are sourced through verified industrial supply channels with full traceability
- Each unit undergoes pre-shipment functional inspection: visual check, label verification, and connector integrity test
- OEM serial numbers and firmware revision labels are preserved — no remarking or refurbishment
- Packaging: original OEM anti-static bag + foam-lined carton for safe international transit
- Certificate of conformance (CoC) available upon request
- Lead time: typically 3–7 business days for in-stock units; 2–4 weeks for sourced orders
Procurement Process
- Confirm Part Number: Verify SAT145-S65 against your CENTUM VP / CS 3000 I/O list or BOM
- Request Quote: Contact support@konmask.com with quantity, delivery address, and required lead time
- Order Confirmation: Receive proforma invoice with unit price, shipping cost, and ETA
- Payment & Dispatch: Payment via T/T or agreed terms; tracking number provided within 24 hours of dispatch
- Incoming Inspection: Recommended: verify serial number, inspect connectors, and perform bench test before installation
Technical FAQ
Q: Is the SAT145-S65 compatible with both CENTUM VP and CS 3000?
A: Yes. The module is designed for use across both CENTUM VP and CS 3000 DCS platforms. Always verify the I/O unit (IOU) model and firmware revision with your Yokogawa system documentation before installation.
Q: Can this module accept both thermocouple and RTD inputs simultaneously?
A: Channel configuration depends on the specific firmware and wiring setup. Consult the Yokogawa SAT145 series datasheet (IM 33J01B30-01EN) for per-channel configuration details.
Q: What is the warranty on this module?
A: Konmask.com provides a 90-day functional warranty on all verified modules. Extended warranty and on-site support can be arranged — contact us for details.
Q: Do you provide installation support?
A: Yes. Our engineering team can provide remote commissioning guidance, I/O list review, and wiring diagram verification. Contact support@konmask.com.
Q: Can I return the module if it is incompatible?
A: Returns are accepted within 14 days of receipt for unused, uninstalled modules in original packaging. Please contact us before returning.
