YOKOGAWA VM1*D S9210AQ-03 – Multipoint Analog I/O Card | CENTUM VP / CS 3000 Platform
Engineering Background
The YOKOGAWA VM1*D S9210AQ-03 is a high-density multipoint analog I/O card engineered for deployment within YOKOGAWA’s CENTUM VP and CS 3000 Distributed Control System (DCS) platforms. Designed to meet the rigorous demands of continuous process industries, this module delivers precise analog signal acquisition and output in a compact, field-proven form factor. It is a critical building block for engineers designing or maintaining large-scale process automation architectures where signal integrity, channel density, and system reliability are non-negotiable.
Product Positioning
Targeted at procurement engineers and MRO specialists in refining, petrochemical, power generation, and advanced manufacturing sectors, the VM1*D S9210AQ-03 serves as a direct OEM replacement or expansion module within existing CENTUM VP / CS 3000 field control stations (FCS). Konmask supplies this module with full traceability documentation, enabling seamless integration into validated and safety-critical control environments.
Complete Technical Specifications
- Part Number: VM1*D S9210AQ-03
- Manufacturer: YOKOGAWA Electric Corporation
- Module Type: Multipoint Analog Input / Output Card
- Compatible Platform: CENTUM VP, CENTUM CS 3000
- Signal Type: Analog (4–20 mA / 1–5 V DC, configurable per channel)
- Channel Configuration: Multipoint (multiple AI/AO channels per card)
- Resolution: 16-bit A/D conversion (typical for YOKOGAWA VM-series)
- Isolation: Channel-to-channel and channel-to-bus isolation
- Communication Bus: Internal FCS V-net / ESB bus
- Power Supply: Supplied via FCS backplane (redundant power compatible)
- Operating Temperature: 0°C to +55°C
- Storage Temperature: -20°C to +70°C
- Humidity: 5% to 95% RH (non-condensing)
- Weight: Approx. 600 g
- Compliance: CE, IEC 61131-2, YOKOGAWA internal quality standards
- Form Factor: Plug-in card for CENTUM VP / CS 3000 FCS node unit
Proven Application Environments
- Oil & Gas: Upstream wellhead monitoring, downstream refinery process control, pipeline SCADA integration
- Petrochemical: Reactor temperature/pressure loop control, distillation column management
- Power Generation: Boiler control, turbine governor feedback, emissions monitoring
- Pulp & Paper / Chemical: Continuous batch process control with high channel-count I/O requirements
- Pharmaceutical / Food & Beverage: FDA-compliant process environments requiring validated DCS configurations
- Water & Wastewater: Flow, level, and pH analog loop management in municipal treatment plants
Engineering Advantages
- High Channel Density: Maximizes I/O capacity per FCS slot, reducing hardware footprint and cabinet space
- Native CENTUM Integration: Zero-configuration compatibility with CENTUM VP / CS 3000 — no third-party gateways or protocol converters required
- Signal Integrity: Galvanic isolation and 16-bit resolution ensure accurate process variable representation across long cable runs
- Hot-Swap Capable: Supports online card replacement in redundant FCS configurations, minimizing process downtime
- Redundancy Ready: Compatible with YOKOGAWA dual-redundant I/O architectures for SIL-rated applications
- Long Service Life: YOKOGAWA’s proven hardware reliability with extended spare parts availability through authorized channels
System Architecture & Signal Flow
The VM1*D S9210AQ-03 installs directly into the I/O node unit of a CENTUM VP or CS 3000 Field Control Station. Field transmitters (4–20 mA HART or standard analog) connect via marshalling cabinets or direct terminal blocks to the card’s input channels. The card performs A/D conversion, applies engineering unit scaling defined in the CENTUM VP builder, and transmits process data over the internal ESB/V-net bus to the FCS CPU. Output channels receive setpoints from the FCS and drive final control elements (control valves, variable speed drives) via D/A conversion. The entire signal chain operates within YOKOGAWA’s deterministic scan cycle, ensuring loop response times consistent with process control requirements.
Sourcing & Quality Verification
- Origin: OEM YOKOGAWA production; sourced through verified industrial supply channels
- Condition: New / Refurbished-to-OEM-spec options available — specify at inquiry
- Inspection: Each unit undergoes functional verification prior to dispatch: power-on test, channel continuity check, firmware version confirmation
- Documentation: Certificate of conformance, test report, and packing list provided with every shipment
- Packaging: Anti-static ESD bag + foam-lined carton; compliant with IEC 61340-5-1 for sensitive electronics
- Traceability: Serial number and batch records retained for 5 years post-shipment
Procurement Process
- Submit RFQ: Contact Konmask via email or phone with your required quantity, delivery timeline, and destination port
- Quotation: Receive a formal quotation within 1 business day including unit price, lead time, and shipping options (DHL / FedEx / sea freight)
- Order Confirmation: Issue PO against quotation; proforma invoice issued for payment processing
- Quality Hold: Unit reserved and inspected upon order confirmation
- Dispatch & Tracking: Shipped with full documentation package; tracking number provided within 24 hours of dispatch
- After-Sales: 12-month warranty on verified new units; technical support available for integration queries
Technical FAQ
Q: Is the VM1*D S9210AQ-03 compatible with CENTUM VP R6.x?
A: Yes. The VM-series I/O cards maintain backward and forward compatibility across CENTUM VP releases. Confirm your FCS node unit generation with Konmask for slot compatibility verification.
Q: Can this card be used in a CS 3000 system being migrated to CENTUM VP?
A: Yes. YOKOGAWA’s migration architecture supports reuse of compatible I/O cards during phased FCS upgrades. Consult your YOKOGAWA system integrator for node unit compatibility mapping.
Q: What is the difference between VM1*D and VM1*E variants?
A: The suffix denotes hardware revision. Functional specifications are equivalent; the revision may affect firmware compatibility with specific FCS CPU generations. Konmask can advise on the correct variant for your installed base.
Q: Do you supply HART-enabled versions?
A: HART multiplexing in CENTUM VP is typically handled at the FCS CPU or dedicated HART interface module level. Confirm your HART requirements at RFQ stage.
Q: What is the minimum order quantity (MOQ)?
A: MOQ is 1 unit. Volume pricing is available for orders of 5 units or more.
Q: Can Konmask provide an exchange / core return program?
A: Yes. Contact us to discuss exchange pricing for units returned in repairable condition.
