Indexing Motion Control Solution — Allen-Bradley 2097-V33PR1 | Kinetix 300 Series
Where This Product Is Used
The Allen-Bradley 2097-V33PR1 Kinetix 300 Indexing Servo Drive is purpose-built for single-axis, standalone motion applications where precise, repeatable positioning is critical. Typical deployment environments include:
- Packaging Machinery — rotary indexers, form-fill-seal machines, label applicators, and case erectors requiring deterministic stop-and-go motion.
- Conveyor & Material Handling — indexing conveyors, pick-and-place stations, and transfer systems in automotive and electronics assembly lines.
- Printing & Converting — web-tension control, registration mark tracking, and cut-to-length applications in flexographic and digital printing.
- CNC & Machine Tool Auxiliary Axes — tool changers, rotary tables, and pallet shuttles where a standalone drive offloads the main CNC controller.
- Food & Beverage Processing — portioning, slicing, and filling equipment requiring hygienic, repeatable servo motion without a full PLC motion controller.
- Semiconductor & Electronics Manufacturing — wafer handling, PCB routing, and component placement where micron-level repeatability is required.
Technical Specifications
| Part Number | 2097-V33PR1 |
| Brand / Manufacturer | Allen-Bradley (Rockwell Automation) |
| Series | Kinetix 300 |
| Drive Type | Indexing Servo Drive (standalone, EtherNet/IP configurable) |
| Input Voltage | 200–240 V AC, Single-Phase |
| Continuous Output Current | 3.0 A RMS |
| Peak Output Current | 9.0 A RMS |
| Communication Interface | EtherNet/IP |
| Feedback Supported | Incremental Encoder, Absolute Encoder (Hiperface / EnDat) |
| Indexing Profiles | Up to 32 stored motion profiles (no PLC required) |
| Digital I/O | 8 Inputs / 4 Outputs (24 V DC) |
| Enclosure Rating | IP20 (panel-mount) |
| Operating Temperature | 0 °C to +50 °C |
| Weight | 1.2 kg |
| Certifications | UL, CE, RoHS |
Why Engineers Specify This Model
- No PLC Required for Motion — Up to 32 indexing profiles are stored onboard and triggered via digital I/O, dramatically reducing panel cost and wiring complexity for simple single-axis machines.
- EtherNet/IP Native — Integrates seamlessly into existing Allen-Bradley ControlLogix / CompactLogix networks for supervisory monitoring without consuming motion controller axes.
- Compact Footprint — Slim panel-mount form factor fits in tight control cabinets; ideal for OEM machine builders optimizing enclosure size.
- Broad Motor Compatibility — Works with MPL, MPM, and TL-Series Allen-Bradley servo motors, protecting existing motor investments.
- Simplified Commissioning — Configured via Kinetix 300 Motion Control Workbench software; no ladder logic programming required for standalone indexing tasks.
- Proven Reliability — Rockwell Automation’s Kinetix 300 platform is deployed in thousands of OEM machines globally across food, pharma, and automotive sectors.
Complete System Bill of Materials
For a fully operational Kinetix 300 single-axis indexing system, engineers typically specify the following components alongside the 2097-V33PR1:
| Component | Recommended Part | Function |
|---|---|---|
| Servo Motor | MPL-A310P-MJ72AA | Matched 200V rotary servo motor |
| Motor Power Cable | 2090-CPBM7DF-16AF03 | Motor power flying lead, 3 m |
| Feedback Cable | 2090-CFBM7DF-CDAF03 | Encoder feedback, 3 m |
| AC Line Filter | 2097-F3 | EMC line filter for single-phase input |
| Shunt Resistor (optional) | 2097-R6 | External shunt for high-inertia loads |
| Configuration Software | Kinetix 300 Motion Control Workbench | Free download from Rockwell (Studio 5000 not required) |
Compliance & Industry Standards
- UL 508C — Power Conversion Equipment (North American market compliance)
- CE / EN 61800-3 — EMC Directive for variable-speed electrical power drive systems
- CE / EN 61800-5-1 — Safety requirements for adjustable-speed electrical power drive systems
- RoHS 2011/65/EU — Restriction of hazardous substances in electrical equipment
- REACH — Compliant with EU chemical substance regulations
- EtherNet/IP ODVA Conformance — Certified conformant device for open industrial Ethernet
Quality Assurance & Sourcing
Konmask.com specializes in verified industrial automation components for B2B buyers and MRO procurement teams. Every unit of the 2097-V33PR1 we supply is subject to the following quality process:
- Visual & Label Inspection — Part number, date code, and revision level verified against Rockwell Automation documentation.
- Functional Power-On Test — Where applicable, units are bench-tested for power-up integrity and fault-code-free initialization.
- Authentic Sourcing — Sourced from authorized distributors, OEM surplus, or verified industrial resellers. Counterfeit-risk screening applied.
- Documented Traceability — Lot records and sourcing documentation available upon request for regulated industries (pharma, aerospace, defense).
- Packaging — Anti-static bagged, foam-protected, and shipped in double-wall corrugated cartons. Weight: 1.2 kg.
How to Source This Part
- Add to Cart — Immediate checkout for stocked units. Lead time confirmed at order.
- Request a Quote — For volume orders (5+ units), OEM blanket orders, or project-based procurement, contact support@konmask.com for a formal quotation within 24 hours.
- Expedite / Emergency — Same-day shipping available for in-stock units. Contact us by phone for urgent requirements: +0086 19859288691.
- Global Shipping — DHL Express, FedEx International, and sea freight options available. Export documentation (CO, packing list, commercial invoice) provided.
- Payment — T/T (bank transfer), PayPal, and trade credit terms available for qualified accounts.
Application-Specific FAQ
Q: Can the 2097-V33PR1 operate completely standalone without a PLC or HMI?
A: Yes. Up to 32 motion profiles are stored onboard and triggered via the 8 digital inputs. A PLC is not required for motion execution — only for supervisory data collection if needed.
Q: Which Allen-Bradley servo motors are compatible?
A: The Kinetix 300 is compatible with MPL, MPM, MPF, MPS, and TL-Series motors. Always verify the motor’s continuous current rating against the drive’s 3.0 A continuous output.
Q: Is EtherNet/IP required for operation?
A: No. EtherNet/IP is optional and used for configuration, monitoring, and integration with ControlLogix/CompactLogix systems. The drive operates fully via digital I/O without a network connection.
Q: What is the difference between 2097-V33PR1 and 2097-V33PR3?
A: The PR1 variant is rated for single-phase 200–240 V AC input. The PR3 variant supports three-phase input at higher power ratings. Select PR1 for single-phase panel designs.
Q: Can this drive be used in a CE-marked machine exported to Europe?
A: Yes, provided the system integrator installs the recommended 2097-F3 AC line filter and follows the EMC wiring guidelines in Rockwell publication 2097-UM001.
Q: Do you provide a warranty?
A: Yes. Konmask.com provides a 90-day functional warranty on all verified units. Extended warranty and exchange programs are available — contact us for details.
