HMI & Operator Interface Solution — Allen-Bradley 2711-B5A10 | PanelView 550
Where This Product Is Used
The Allen-Bradley 2711-B5A10 PanelView 550 Standard Operator Terminal is deployed across a wide range of industrial automation environments where reliable human-machine interface (HMI) capability is essential:
- Discrete Manufacturing Lines — Machine status monitoring, alarm acknowledgment, and operator input on assembly and packaging lines.
- Food & Beverage Processing — Hygienic-environment panel stations for batch control, recipe management, and process visualization.
- Water & Wastewater Treatment — Remote pump station HMI for flow control, level monitoring, and fault indication.
- Automotive Body Shops & Paint Lines — Operator terminals integrated with PLC-controlled conveyors and robotic cells.
- HVAC & Building Automation — Facility management panels for chiller, AHU, and BMS control loops.
- Oil & Gas Upstream/Midstream — Wellhead and compressor station local HMI panels in hazardous-area enclosures.
- Pharmaceutical Manufacturing — GMP-compliant operator stations for batch record entry and process parameter display.
- Material Handling & Warehousing — Conveyor and sortation system control panels requiring compact, rugged HMI.
Technical Specifications
| Part Number | 2711-B5A10 |
| Brand / Manufacturer | Allen-Bradley (Rockwell Automation) |
| Series | PanelView 550 |
| Display Size | 5.5-inch monochrome LCD |
| Display Type | Standard (non-touch); keypad input |
| Communication Interface | DH-485 (RS-422/RS-485) |
| Input Voltage | 24 VDC |
| Operating Temperature | 0 °C to 55 °C (32 °F to 131 °F) |
| Storage Temperature | -40 °C to 85 °C |
| Enclosure Rating | NEMA 4/4X, 12, 13 (front face) |
| Memory | 512 KB application memory |
| Programming Software | PanelBuilder 1400e / PanelBuilder32 |
| Weight | Approx. 3.0 kg |
| Catalog / SKU | 2711-B5A10 |
Why Engineers Specify This Model
- Proven DH-485 Ecosystem Compatibility — Seamlessly integrates with SLC 500, MicroLogix, and legacy PLC-5 controllers already installed in the field, eliminating costly network upgrades.
- Rugged NEMA 4/4X Front Face — Withstands washdown, dust, and oil-mist environments without additional enclosure modifications.
- Keypad-Based Input Reliability — Membrane keypad eliminates touchscreen calibration drift issues common in high-vibration or gloved-hand applications.
- Compact 5.5″ Form Factor — Fits standard panel cutouts, reducing retrofit engineering time and panel real estate requirements.
- Long Field Service Life — Extensive installed base means spare parts, replacement units, and trained technicians remain widely available.
- Low Total Cost of Ownership — No licensing fees for runtime; PanelBuilder32 application files are portable and reusable across replacement units.
Complete System Bill of Materials
For a fully operational PanelView 550 DH-485 operator station, engineers typically specify the following complementary components:
- Allen-Bradley SLC 5/03 or SLC 5/04 Processor (DH-485 port) — e.g., 1747-L531 or 1747-L541
- DH-485 Communication Cable — 1747-C10 (10 ft) or 1747-C20 (20 ft)
- 24 VDC Power Supply — e.g., 1606-XLP30E (30 W, 24 VDC)
- Panel Mounting Hardware — 2711-NM10 mounting kit
- PanelBuilder32 Programming Software — 2711-ND3 (if not already licensed)
- Replacement Backlight Lamp (for maintenance stock) — 2711-NL1
Compliance & Industry Standards
- UL Listed — UL 508 (Industrial Control Equipment)
- CE Marked — Compliant with EU Low Voltage Directive and EMC Directive
- NEMA 4 / 4X / 12 / 13 — Front panel ingress protection ratings
- RoHS — Compliant with EU Directive 2011/65/EU (Restriction of Hazardous Substances)
- CSA Certified — Canadian Standards Association approval for North American markets
Quality Assurance & Sourcing
At Konmask.com, every Allen-Bradley 2711-B5A10 unit undergoes a structured quality verification process before dispatch:
- Visual Inspection — Housing, keypad membrane, display, and connector integrity checked against OEM reference standards.
- Functional Power-On Test — Unit powered at rated 24 VDC; display, backlight, and keypad response verified.
- Communication Port Check — DH-485 port continuity and signal integrity tested.
- Firmware Version Logging — Firmware revision recorded and disclosed to buyer prior to shipment.
- Traceability Documentation — Each unit ships with an inspection checklist and sourcing declaration.
We source from authorized distributors, OEM surplus channels, and verified industrial resellers. Counterfeit-risk screening is applied to all inbound stock.
How to Source This Part
- Request a Quote — Email support@konmask.com or call +0086 19859288691 with your required quantity and delivery timeline.
- Receive Stock Confirmation — We confirm availability, firmware revision, and unit condition (new surplus / refurbished / tested used) within 1 business day.
- Place Order — Proceed via this product page or via purchase order (PO) for B2B accounts.
- Inspection & Dispatch — Unit passes QA checklist; ships within 1–3 business days with full tracking.
- Delivery & Support — Post-delivery technical support available for integration and commissioning queries.
Application-Specific FAQ
Q: Is the 2711-B5A10 compatible with ControlLogix or CompactLogix PLCs?
A: Not natively. The B5A10 uses DH-485, which is not a native port on ControlLogix/CompactLogix. A 1761-NET-AIC or 1747-AIC link coupler is required to bridge DH-485 to these platforms. For new projects, consider upgrading to a PanelView Plus 7 with EtherNet/IP.
Q: Can I reuse an existing PanelBuilder32 application file on a replacement 2711-B5A10?
A: Yes. PanelBuilder32 .PBA application files are fully portable across 2711-B5A10 units of the same firmware generation. Verify firmware revision compatibility before transfer.
Q: What is the difference between 2711-B5A10 and 2711-B5A1?
A: The 2711-B5A10 includes 512 KB of application memory (vs. 256 KB on the B5A1), supporting larger and more complex HMI applications with more screens and data tags.
Q: Is this unit available new or only as surplus/refurbished?
A: The PanelView 550 series is discontinued by Rockwell Automation. Units available at Konmask.com are new surplus (unused, original packaging where available) or professionally refurbished and tested. Condition is disclosed per unit at time of quote.
Q: Do you offer a warranty?
A: Yes. All units carry a 90-day functional warranty covering defects identified under normal operating conditions. Extended warranty options are available — contact us for details.
