ABB 3BHE032285R0102 XVC772 A102 HVD Board Varnished – ACS/DCS Drive Control Module
When a critical HVD control board fails inside an ABB drive system, the entire production line comes to a halt. Variable speed drives lose their gate-firing intelligence, motor control becomes erratic, and in high-power applications — from cement mills to offshore compressors — unplanned downtime can cost tens of thousands of dollars per hour. The ABB 3BHE032285R0102 XVC772 A102 HVD Board Varnished is the precision-engineered replacement that restores full drive functionality, eliminating guesswork and minimizing mean time to repair (MTTR).
Within the ABB XVC772 board family, the A102 variant occupies a specialized position as a high-voltage drive (HVD) interface board with conformal varnish coating — a critical feature for installations in humid, dusty, or chemically aggressive environments. Widely deployed across ABB’s ACS and DCS series medium-voltage and high-power drive platforms, this board is a cornerstone component in global industrial automation infrastructure, trusted by OEMs and end-users across Europe, Asia, and the Americas.
Technical Specifications
- Part Number: 3BHE032285R0102
- Board Type: XVC772 A102 – HVD Control Board
- Surface Treatment: Varnished (Conformal Coating)
- Manufacturer: ABB Ltd.
- Compatible Drive Series: ABB ACS / DCS High-Power Drive Systems
- Form Factor: PCB Module
- Weight: Approx. 200 g
- Condition: New / Refurbished (specify on inquiry)
Key Features & Benefits
- Conformal Varnish Coating: Protects PCB traces and components against moisture, dust, and corrosive gases — essential for harsh industrial environments.
- OEM-Grade Precision: Manufactured to ABB’s exacting tolerances, ensuring drop-in compatibility with existing drive cabinets.
- Reduced MTTR: A direct replacement board eliminates the need for field-level PCB repair, dramatically cutting downtime.
- Rigorous Pre-Shipment Testing: Each unit undergoes functional verification before dispatch.
- Global Availability: Stocked and ready to ship worldwide from Konmask.com’s verified supply chain.
Industry & Equipment Applications
- Cement & Mining: Ball mills, crushers, conveyor drives
- Oil & Gas: Compressor drives, pump control systems
- Marine & Offshore: Thruster drives, winch control
- Steel & Metals: Rolling mill drives, ladle crane systems
- Power Generation: Excitation systems, auxiliary drive panels
- Water & Wastewater: High-power pump station drives
System Integration & Compatible Parts
The 3BHE032285R0102 XVC772 A102 is designed for integration within ABB’s modular drive architecture. Commonly paired or replaced alongside:
- ABB XVC772 series gate driver boards
- ABB AINT / AINP interface boards
- ABB RDCU / RMIO control units
- ABB ACS800 / ACS6000 / DCS800 drive platforms
Contact our technical team to confirm compatibility with your specific drive cabinet configuration before ordering.
Our Quality Assurance Process
- Source Verification: All boards are sourced from authorized channels or certified refurbishers.
- Visual Inspection: PCB examined for physical damage, burnt components, and solder joint integrity.
- Functional Testing: Powered bench test under simulated load conditions where applicable.
- Anti-Static Packaging: Shipped in ESD-safe bags with foam cushioning to prevent transit damage.
- Documentation: Test report and traceability documentation available on request.
How to Order
- Submit an inquiry via the Contact / RFQ form on this page.
- Provide your drive model, serial number, and required quantity.
- Receive a formal quotation within 24 business hours.
- Confirm order and arrange payment via T/T, L/C, or other agreed terms.
- Shipment dispatched with full tracking and export documentation.
Why Choose Konmask.com?
- ✔ Specialized in industrial automation spare parts — not a generalist marketplace.
- ✔ Technical support from engineers with hands-on drive system experience.
- ✔ Competitive pricing with transparent quotation process.
- ✔ Fast global shipping with DHL, FedEx, and freight forwarding options.
- ✔ Long-term partnership approach — we support your maintenance planning, not just one-off sales.
Frequently Asked Questions
- Q: Is the 3BHE032285R0102 a new or refurbished board?
- A: We supply both new and professionally refurbished units. Please specify your preference in the inquiry form, and we will confirm availability and pricing accordingly.
- Q: What does “varnished” mean for this board?
- A: The conformal varnish coating is applied to the PCB surface to protect against moisture, condensation, dust, and mild chemical exposure — extending service life in demanding environments.
- Q: Can I get a warranty on this part?
- A: Yes. We offer a standard 12-month warranty against manufacturing defects. Terms are confirmed at the time of quotation.
- Q: How long does shipping take?
- A: Express courier (DHL/FedEx) typically delivers within 3–7 business days globally. Freight options are available for bulk orders.
- Q: Do you provide installation support?
- A: Our technical team can provide guidance on board replacement procedures. For complex commissioning, we can recommend certified ABB service partners.
