ABB 3HAC044513-001 / 3HNA026409-001 / 3HAC157541-004 – Servo Motor with Pinion | ABB IRB Robot Drive System
Engineering Background
The ABB 3HAC044513-001 is a precision servo motor assembly with integrated pinion gear, engineered for ABB’s IRB series industrial robots. Cross-referenced under part numbers 3HNA026409-001 and 3HAC157541-004, this motor unit is a critical axis drive component responsible for delivering accurate torque and positional feedback in high-cycle robotic applications. It is designed to meet the demanding requirements of automotive, electronics, and general manufacturing automation environments.
Product Positioning
As a genuine ABB OEM replacement part, this motor with pinion is the preferred choice for maintenance engineers and procurement teams seeking to restore full robot performance without compromising on specification integrity. Konmask.com sources this component through verified industrial supply channels, ensuring traceability and authenticity for every unit shipped.
Complete Technical Specifications
| Part Number (Primary) | 3HAC044513-001 |
| Cross Reference | 3HNA026409-001 / 3HAC157541-004 |
| Manufacturer | ABB |
| Component Type | Servo Motor with Pinion Gear |
| Platform / Series | ABB IRB Robot Series |
| Function | Axis Drive – Rotary Motion with Integrated Pinion |
| Mounting | Flange-mount, robot joint housing |
| Weight (approx.) | 800 g |
| Condition | New / Refurbished (specify on inquiry) |
| Country of Origin | Sweden / Germany (ABB manufacturing) |
| Compliance | CE, RoHS |
Proven Application Environments
- ABB IRB 1600 / 2400 / 4400 / 6600 series robot joint replacement
- Automotive body welding and assembly lines
- Electronics PCB handling and pick-and-place systems
- Palletizing and material handling automation
- Precision machining and CNC tending cells
- Cleanroom and food-grade robotic applications (where applicable variant)
Engineering Advantages
- OEM Specification Compliance: Manufactured to ABB’s original design tolerances — no performance compromise vs. new robot build.
- Integrated Pinion Design: Pre-assembled pinion eliminates field alignment errors and reduces installation time.
- Multi-Part-Number Compatibility: Verified cross-reference across 3HAC044513-001, 3HNA026409-001, and 3HAC157541-004 for procurement flexibility.
- High Cycle Durability: Engineered for continuous-duty industrial cycles with minimal maintenance intervals.
- Plug-and-Play Replacement: Direct drop-in for compatible IRB robot axis positions — no custom modification required.
System Architecture & Signal Flow
This motor unit interfaces with the ABB robot controller (IRC5 / S4C+) via the axis computer board and drive module. The servo motor receives velocity and torque commands from the axis computer, executes motion through the pinion-gear transmission, and returns encoder feedback (resolver or absolute encoder) to close the position loop. The integrated pinion meshes directly with the robot joint gear ring, transmitting rotary motion to the robot arm segment.
Signal Path: IRC5 Controller → Drive Module → Motor Power & Encoder Cable → 3HAC044513-001 Motor → Pinion → Joint Gear Ring → Robot Arm Axis
Sourcing & Quality Verification
- All units sourced from authorized industrial distributors or verified OEM surplus channels.
- Each unit undergoes visual inspection and part number verification prior to shipment.
- Functional testing available on request — please specify test requirements at time of order.
- Traceability documentation (batch records, test reports) available for qualified buyers.
- Packaging: anti-static bag + foam-lined export carton, suitable for international air/sea freight.
Procurement Process
- Confirm Part Number: Verify your robot’s axis position and confirm compatibility with 3HAC044513-001 / 3HNA026409-001 / 3HAC157541-004.
- Request Quote: Contact support@konmask.com or call +0086 19859288691 for volume pricing and lead time.
- Place Order: Submit PO via the Konmask.com store or by email. Proforma invoice issued within 24 hours.
- Shipping: DHL / FedEx / sea freight options available. Export documentation provided for customs clearance.
- After-Sales: 90-day warranty on verified new units. Technical support available post-installation.
Technical FAQ
Q: Is 3HAC044513-001 the same as 3HNA026409-001?
A: Yes. These are cross-reference part numbers for the same motor assembly used across different ABB robot model generations. 3HAC157541-004 is an additional supersession reference.
Q: Which robot models use this motor?
A: This motor is used in select axis positions of ABB IRB series robots. Please provide your robot model and axis number for exact compatibility confirmation.
Q: Can I order a tested/refurbished unit?
A: Yes. Please specify “tested refurbished” in your inquiry. We will confirm availability and provide test report documentation.
Q: What is the lead time?
A: In-stock units ship within 1–3 business days. Out-of-stock items typically have a 2–4 week lead time. Contact us for real-time stock status.
Q: Do you provide installation support?
A: We provide technical documentation and remote guidance. On-site installation support can be arranged through our partner network.
