ABB IRB460 Axis Reducer Motor & System Components Kit — AB3606-C / DSQC377B / 3HAC025007-001 | IRC5 Palletizing Platform
Engineering Background: The ABB IRB460 is a high-speed, high-payload palletizing robot engineered for end-of-line packaging and logistics automation. Operating at up to 2,190 cycles/hour with a 110 kg payload capacity, the IRB460 demands precision-grade mechanical and electronic components to sustain throughput and positional accuracy over multi-shift production cycles. This listing covers a verified multi-component system kit sourced directly from ABB’s authorized supply chain.
Product Positioning: This kit consolidates six critical ABB part numbers — AB3606-C (axis servo motor), AB-PCI-EIP-S (EtherNet/IP communication module), DSQC377B (IRC5 I/O unit), 3HNE01586-1 (teach pendant cable assembly), IRB460 (robot platform reference), and 3HAC025007-001 (axis reducer assembly) — into a single procurement unit. Designed for maintenance engineers, system integrators, and OEM rebuild teams requiring traceable, specification-matched replacements.
Complete Technical Specifications
| Part Number | Component | Key Parameter |
|---|---|---|
| AB3606-C | AC Servo Motor | Axis drive motor; flange-mount; encoder feedback; compatible with IRC5 drive module |
| AB-PCI-EIP-S | EtherNet/IP Interface Module | PCI-format; EtherNet/IP slave; real-time I/O communication; IRC5 controller integration |
| DSQC377B | IRC5 Digital I/O Unit | 24 VDC; 16 DI / 16 DO; DIN-rail mount; ABB IRC5 cabinet compatible |
| 3HNE01586-1 | Teach Pendant Cable Assembly | FlexPendant interface; shielded; length per ABB standard; IRC5 / IRC5 Compact compatible |
| IRB460 | Palletizing Robot Platform | Payload: 110 kg; Reach: 2,400 mm; Axes: 4; Cycle rate: up to 2,190 cycles/hr |
| 3HAC025007-001 | Axis Reducer Assembly | Precision harmonic/cycloidal reducer; axis-specific gear ratio; backlash <1 arcmin; grease-lubricated |
- Controller Compatibility: ABB IRC5, IRC5 Compact, IRC5 Panel Mounted Controller
- Robot Series: IRB460 (all variants)
- Operating Voltage: 24 VDC (I/O); 400–480 VAC (drive)
- Protection Class: IP54 (motor); IP20 (I/O unit)
- Weight (reducer assembly): ~600 g
- Certifications: CE, UL, RoHS
Proven Application Environments
- Food & Beverage Palletizing: High-cycle end-of-line case palletizing with hygienic-grade sealing requirements
- Consumer Goods Packaging: Mixed-SKU layer formation and stretch-wrap integration lines
- Pharmaceutical Logistics: Serialized carton handling with vision-guided placement accuracy
- Automotive Parts Handling: Heavy-component transfer with precision repeatability (±0.1 mm)
- Cold Chain & Freezer Environments: IRB460 low-temperature variants supported by this component set
- E-Commerce Fulfillment: High-throughput sortation and depalletizing cells
Engineering Advantages
- Drop-in Replacement Accuracy: All part numbers match ABB’s original BOM specifications — no field modification required
- Integrated Communication Architecture: AB-PCI-EIP-S enables seamless EtherNet/IP integration with PLC/SCADA systems (Allen-Bradley, Siemens, Omron)
- Reduced MTTR: Consolidated kit procurement eliminates multi-vendor lead time fragmentation — single shipment, single inspection
- Precision Reducer Longevity: 3HAC025007-001 reducer rated for >20,000 operating hours under rated load with correct lubrication intervals
- Traceable Serial Numbers: Each component ships with ABB factory serial number and production date code for warranty and audit compliance
- Backward Compatibility: DSQC377B and AB-PCI-EIP-S support legacy IRC5 firmware versions 5.x and above
System Architecture & Signal Flow
In a standard IRB460 cell, signal and power flow as follows:
- IRC5 Controller receives motion commands from upstream PLC via AB-PCI-EIP-S (EtherNet/IP)
- Controller processes I/O states through DSQC377B digital I/O unit (gripper, conveyor interlocks, safety signals)
- Motion commands are executed by AB3606-C servo motor, driving the axis through 3HAC025007-001 precision reducer
- Operator intervention and program editing performed via FlexPendant connected through 3HNE01586-1 cable assembly
- Positional feedback loops back to IRC5 drive module, completing the closed-loop servo architecture
Sourcing & Quality Verification
Konmask.com operates a 4-stage incoming inspection protocol for all ABB robotics components:
- Documentation Audit: ABB factory certificate of conformity, serial number cross-reference against ABB’s global parts registry
- Physical Inspection: Label integrity, connector pin condition, housing for impact damage or counterfeit indicators
- Functional Bench Test: Where applicable — I/O units and communication modules are powered and signal-verified prior to dispatch
- Packaging & ESD Control: Anti-static bagging, foam-lined carton, humidity indicator card for sensitive electronics
All components are sourced from ABB authorized distributors, certified MRO suppliers, or directly from ABB’s spare parts division. Counterfeit-zero policy enforced.
Procurement Process
- Submit RFQ: Email support@konmask.com with your required part numbers, quantity, and delivery timeline
- Quotation & Lead Time: Response within 24 business hours with pricing, availability, and estimated ship date
- Order Confirmation: Pro forma invoice issued; payment via T/T, PayPal, or trade finance terms for qualified accounts
- Quality Hold & Dispatch: Components held for final inspection; shipped with full documentation package (CoC, packing list, commercial invoice)
- Post-Delivery Support: 12-month warranty on genuine parts; technical support available for installation queries
Technical FAQ
Q: Are these components new or refurbished?
A: We supply both new (factory-sealed) and professionally refurbished units. Condition is explicitly stated on your quotation. Refurbished units undergo full functional testing and carry a 6-month warranty.
Q: Can DSQC377B replace DSQC377A in my existing IRC5 cabinet?
A: Yes. DSQC377B is the direct successor to DSQC377A with identical form factor and improved firmware compatibility. No hardware modification required.
Q: What firmware version does AB-PCI-EIP-S require?
A: Compatible with IRC5 RobotWare 5.14 and above. EDS file available upon request for PLC-side configuration.
Q: Is 3HAC025007-001 axis-specific or universal?
A: This reducer is axis-specific to the IRB460 platform. Please confirm your robot’s axis number and serial range before ordering to ensure correct gear ratio match.
Q: Do you provide installation documentation?
A: Yes. ABB product manuals, wiring diagrams, and installation guides are provided digitally with every order at no additional charge.
Q: What is your export capability?
A: We ship globally via DHL, FedEx, and UPS Express. Export documentation (EX1, commercial invoice, HS code classification) prepared for all international shipments. Typical transit: 3–7 business days worldwide.
