ABB LD800HSE 3BDH000320R02 High-Speed Motor Drive | Replacement, Equivalent & Selection Guide
The ABB LD800HSE (Part No. 3BDH000320R02) is a high-speed motor drive module designed for demanding industrial automation and process control applications. As an authorized sourcing partner, Konmask.com provides genuine, tested, and traceable units with full documentation support.
Technical Specifications
- Manufacturer: ABB
- Model / SKU: LD800HSE
- Part Number: 3BDH000320R02
- Series: LD800 High-Speed Drive Series
- Product Type: Motor Drive Module
- Communication Interface: HSE (High Speed Ethernet)
- Protocol: FOUNDATION Fieldbus HSE
- Mounting: DIN Rail / Panel Mount
- Weight: 12 kg (approx.)
- Origin: ABB Group (Sweden/Global)
- Condition: New / Refurbished / Tested Available
Compatible Replacement & Equivalent Models
When the ABB LD800HSE 3BDH000320R02 is discontinued, hard to source, or cost-prohibitive, the following models may serve as functional equivalents or drop-in replacements depending on your system configuration:
- ABB LD800HSE 3BDH000320R01 — Previous revision; functionally equivalent in most installations
- ABB LD800HSE 3BDH000320R03 — Newer revision with firmware enhancements; backward compatible
- ABB AC800M PM891 — Alternative controller platform for system-level migration
- Siemens 6ES7 series — Cross-brand alternative for non-ABB DCS environments (requires engineering review)
- Honeywell C300 Controller — Suitable for Experion PKS migration projects
⚠️ Always verify electrical ratings, firmware version, and communication protocol compatibility before substitution. Contact our engineers for a free compatibility assessment.
Why Choose the Original ABB LD800HSE 3BDH000320R02
- ✅ Proven reliability in ABB 800xA and Symphony Plus DCS environments
- ✅ Native HSE protocol support — no gateway or converter required
- ✅ Full ABB ecosystem integration — seamless with existing I/O modules and controllers
- ✅ Reduced commissioning time — plug-and-play replacement in existing racks
- ✅ Long-term ABB support — firmware updates and technical documentation available
Typical Applications
- Oil & Gas process automation (upstream/downstream)
- Chemical and petrochemical plant control systems
- Power generation and utilities
- Pulp & paper manufacturing
- Water treatment and infrastructure
- Pharmaceutical batch processing
System Compatibility
- ABB 800xA DCS — Full native support
- ABB Symphony Plus — Compatible with HSE network topology
- FOUNDATION Fieldbus HSE networks — Certified interoperability
- ABB AC800F Controller — Designed for use with this drive series
Selection Guide
Use the following criteria to confirm the ABB LD800HSE 3BDH000320R02 is the right choice for your application:
-
Step 1 — Verify Part Number: Confirm the full part number
3BDH000320R02matches your existing module label or BOM. - Step 2 — Check Revision: R02 indicates the second hardware revision. Ensure your firmware and rack are compatible.
- Step 3 — Confirm Protocol: This module uses HSE (High Speed Ethernet). Verify your fieldbus network supports HSE topology.
- Step 4 — Assess Quantity & Lead Time: For critical spares, we recommend holding 1–2 units on-site. Contact us for volume pricing.
- Step 5 — Consult Our Engineers: Unsure? Send us your system architecture or existing module photo for a free pre-sales review.
Quality Assurance & Sourcing
- 🔍 100% tested before shipment — functional and communication verification
- 📦 Original packaging or industrial anti-static packaging for refurbished units
- 📋 Full traceability — serial number, batch records, and test reports available on request
- 🌐 Global sourcing network — authorized distributors and certified secondary market
- 🛡️ Warranty: 12-month warranty on all units; extended warranty available
How to Order
- Add the ABB LD800HSE 3BDH000320R02 to your cart and proceed to checkout.
- For bulk orders (>3 units), email support@konmask.com for a custom quote.
- Need expedited shipping? Select express freight at checkout or contact us directly.
- For replacement/exchange programs, contact our technical team with your defective unit details.
Replacement & Compatibility FAQ
Q: Can the R01 revision replace the R02?
A: In most cases yes, but firmware compatibility must be verified. Contact us for a system-specific assessment.
Q: Is this module compatible with third-party FOUNDATION Fieldbus systems?
A: The LD800HSE is certified for FOUNDATION Fieldbus HSE, but integration with non-ABB hosts requires engineering validation.
Q: Do you offer repair services for faulty LD800HSE units?
A: Yes. Send us your defective unit for evaluation. Repair turnaround is typically 5–10 business days.
Q: What is the lead time for new units?
A: In-stock units ship within 1–3 business days. Out-of-stock lead time is 2–6 weeks depending on sourcing channel.
Q: Can I get a datasheet or wiring diagram?
A: Yes. Request technical documentation via support@konmask.com.
