ABB TP830 3BSE018114R1 Base Module | Replacement, Equivalent & Selection Guide
The ABB TP830 (Part No. 3BSE018114R1) is a Base Module designed for the AC800M Distributed Control System (DCS) platform. This guide helps engineers identify compatible replacements, equivalent models, and make the right selection decision for their control system architecture.
Technical Specifications
- Manufacturer: ABB
- Model: TP830
- Part Number: 3BSE018114R1
- Series: AC800M
- Module Type: Base Module
- Weight: 870 g
- Application: DCS / Process Automation
- Mounting: DIN Rail / Rack Mount (AC800M backplane)
- Communication: Compatible with AC800M controller bus
- Operating Temperature: 0°C to +55°C (standard industrial range)
- Condition Available: New, Refurbished, Tested
Compatible Replacement & Equivalent Models
When the TP830 is unavailable or end-of-life, the following models may serve as functional equivalents depending on your system configuration. Always verify firmware and backplane compatibility before substitution.
- ABB TP830 / 3BSE018114R1 — Original OEM (this listing)
- ABB TB820V2 / 3BSE013208R1 — ModuleBus Modem, compatible in AC800M I/O expansion
- ABB TB840A / 3BSE037760R1 — ModuleBus Optical Port, alternative for fiber-based I/O
- ABB TP854 / 3BSE025294R1 — Compact Base Module, check slot compatibility
- Third-party compatible base modules — consult Konmask for cross-reference validation
Note: Replacement suitability depends on firmware version, rack configuration, and system revision. Contact our engineers for a validated cross-reference.
Why Choose the Original Model
- ✅ OEM-guaranteed compatibility with all AC800M controller revisions
- ✅ No firmware re-flashing required — plug-and-play replacement
- ✅ Full ABB diagnostics support via Control Builder M software
- ✅ Longer service life with ABB-certified components
- ✅ Warranty-eligible when sourced from authorized distributors
- ✅ Traceable lot numbers for regulated industries (pharma, nuclear, oil & gas)
Typical Applications
- Oil & Gas — FPSO, refinery DCS base module replacement
- Power Generation — turbine control system I/O expansion
- Chemical & Petrochemical — process automation rack rebuild
- Pulp & Paper — AC800M system upgrade and spare parts stocking
- Water Treatment — SCADA/DCS hybrid control panel integration
- Pharmaceutical — validated control system maintenance (21 CFR Part 11 environments)
System Compatibility
- Platform: ABB AC800M DCS
- Compatible Controllers: PM861, PM864, PM866, PM891 series
- I/O Modules: AI810, AO810, DI810, DO810, and S800 I/O family
- Software: ABB Control Builder M (CBM) v5.x and above
- Redundancy: Supports redundant controller configurations
- Bus: ModuleBus / Optical ModuleBus compatible
Selection Guide
Use the following criteria to confirm the TP830 is the correct module for your application:
- Step 1 — Identify your AC800M revision: Check the controller nameplate for hardware generation (Gen 1 / Gen 2).
- Step 2 — Confirm slot position: TP830 occupies a specific base slot; verify rack layout drawing.
- Step 3 — Check I/O count: Ensure the base module supports your required I/O channel density.
- Step 4 — Firmware alignment: Match Control Builder M version to module firmware baseline.
- Step 5 — Redundancy requirement: If running redundant controllers, confirm paired module part number.
- Step 6 — Contact Konmask: Provide your system serial number for a validated BOM recommendation.
Quality Assurance & Sourcing
- 🔍 100% functional testing prior to shipment
- 📦 Anti-static packaging with humidity indicators
- 🏷️ Original labels preserved — no re-labeling or remarking
- 📋 Inspection report available on request
- 🌐 Global sourcing network — excess inventory, OEM overstock, and decommissioned plant stock
- ⏱️ Lead time: In-stock items ship within 2 business days; sourced items 5–15 business days
How to Order
- Add to cart or contact us directly at support@konmask.com
- Provide your PO number, delivery address, and required quantity
- Request a datasheet, test report, or certificate of conformance if needed
- Our team will confirm availability and issue a proforma invoice within 24 hours
- Payment via T/T, PayPal, or trade assurance accepted
Replacement & Compatibility FAQ
Q: Can I use TP830 to replace TB820V2 directly?
A: Not directly — TP830 and TB820V2 serve different bus roles. Contact our engineers for a validated substitution path.
Q: Is the 3BSE018114R1 still in production?
A: ABB has transitioned some AC800M modules to newer revisions. We maintain stock of both current and legacy part numbers.
Q: Do you provide a warranty?
A: Yes — all tested units carry a 90-day functional warranty. New OEM units carry the standard ABB warranty.
Q: Can you supply multiple units for a plant turnaround?
A: Yes. We support bulk orders and can coordinate phased delivery to match your maintenance schedule.
Q: What documentation is available?
A: ABB datasheet, wiring diagram, test report, and certificate of conformance available upon request.
