ADLINK PCI-9810 Analog Input Card – High-Speed Multifunction Data Acquisition
When a critical analog signal chain fails in your industrial control system — whether it’s a thermocouple reading from a furnace, a pressure transducer on a hydraulic press, or a vibration sensor on a CNC spindle — the entire production line can halt within seconds. Without a reliable, high-speed analog input card seated in your PCI bus, your SCADA system goes blind, your PLC loses its feedback loop, and unplanned downtime begins accumulating costs. The ADLINK PCI-9810 is the precision interface that keeps your measurement infrastructure intact and your process data flowing without interruption.
The PCI-9810 occupies a well-established position within ADLINK’s PCI-9800 series of multifunction data acquisition cards — a product line trusted by systems integrators and OEM machine builders across automotive, semiconductor, energy, and process industries worldwide. With its combination of 12-bit resolution, 110 kS/s aggregate sampling rate, and 16 single-ended (or 8 differential) analog input channels, the PCI-9810 delivers the performance-to-cost ratio that makes it a default specification in mid-range industrial DAQ architectures globally.
Technical Specifications
- Model: PCI-9810
- Manufacturer: ADLINK Technology
- Bus Interface: 32-bit PCI (Universal PCI, 3.3V / 5V)
- Analog Input Channels: 16 single-ended / 8 differential (software-selectable)
- ADC Resolution: 12-bit
- Aggregate Sampling Rate: Up to 110 kS/s
- Input Voltage Ranges: ±10V, ±5V, ±2.5V, ±1.25V (software-selectable per channel)
- Input Impedance: 1 MΩ
- On-board FIFO: 1K samples
- Trigger Modes: Software, internal pacer, external digital trigger
- Digital I/O: 16-bit programmable DIO (TTL-compatible)
- Analog Output: 2-channel, 12-bit DAC, ±10V
- Counter/Timer: 1× 16-bit counter (8254-compatible)
- Operating Temperature: 0°C to 60°C
- Power Consumption: +5V @ 800mA typical
- Form Factor: Half-size PCI card
- OS Support: Windows 10/8/7, Windows Server, Linux
- Software: Compatible with ADLINK DAQPilot, LabVIEW, MATLAB, Visual C++, Visual Basic
Key Features & Benefits
- Per-channel programmable gain: Maximize dynamic range across mixed-signal sensor arrays without external signal conditioning hardware.
- 1K on-board FIFO buffer: Prevents data loss during CPU interrupt latency spikes — critical in real-time industrial environments.
- Universal PCI compatibility: Operates in both 3.3V and 5V PCI slots, ensuring backward compatibility with legacy industrial PCs and new-generation embedded controllers.
- Integrated 2-channel DAC: Enables closed-loop control applications without requiring a separate analog output card, reducing BOM cost and slot consumption.
- 16-bit DIO: Supports direct interfacing with relay boards, optocouplers, and digital sensors — eliminating the need for a dedicated digital I/O card in many applications.
- ADLINK DAQPilot SDK: Provides a unified API across the PCI-9800 series, enabling rapid software migration between card variants without rewriting application code.
- Half-size form factor: Fits in compact industrial PCs and embedded chassis with limited card clearance.
Industry & Equipment Applications
- Automotive manufacturing: Engine test bench data acquisition, torque and pressure monitoring on assembly lines.
- Semiconductor fabrication: Process parameter logging in CVD, PVD, and etch equipment.
- Energy & utilities: Vibration and temperature monitoring on turbines, compressors, and pumps.
- Pharmaceutical & food processing: Continuous analog logging for GMP-compliant batch records.
- Machine tool & CNC: Spindle load monitoring, servo feedback verification, and axis position logging.
- Research & laboratory: Multi-channel sensor data acquisition for R&D test rigs and environmental chambers.
- Building automation: HVAC sensor integration and energy metering in BMS systems.
System Integration & Compatible Parts
The PCI-9810 is designed for seamless integration within ADLINK’s broader automation ecosystem and is compatible with the following accessories and companion products:
- ADLINK ACL-10168: 68-pin SCSI-II to terminal block wiring board for direct sensor termination.
- ADLINK ACL-10168-68: Shielded cable assembly for noise-sensitive environments.
- ADLINK PCI-9812 / PCI-9816: Higher-channel-count siblings in the PCI-9800 series for expanded applications.
- ADLINK DAQPilot Software: Unified driver and configuration utility for all PCI-9800 series cards.
- Third-party compatibility: National Instruments LabVIEW (via NI-DAQmx wrapper), MathWorks MATLAB Data Acquisition Toolbox, and Kepware KEPServerEX OPC driver.
Our Quality Assurance Process
At Konmask.com, every ADLINK PCI-9810 unit we supply undergoes a structured verification process before shipment:
- Source verification: Units are sourced exclusively from authorized ADLINK distributors or certified secondary-market channels with full traceability documentation.
- Visual inspection: PCB, connector pins, and component markings are inspected against ADLINK reference standards to detect counterfeits or refurbished units misrepresented as new.
- Functional pre-check: Where applicable, cards are bench-tested in a PCI host system to confirm ADC channel continuity and driver enumeration prior to packaging.
- Anti-static packaging: All cards are shipped in ESD-safe bags with foam cushioning inside double-wall cartons.
- Documentation included: Original ADLINK datasheet, CE/FCC declaration of conformity, and Konmask inspection checklist accompany every shipment.
How to Order
- Step 1 — Submit an inquiry: Use the contact form on this page or email support@konmask.com with your required quantity and delivery timeline.
- Step 2 — Receive a quotation: Our technical sales team will respond within 1 business day with pricing, lead time, and shipping options.
- Step 3 — Confirm & pay: We accept T/T bank transfer, PayPal, and major credit cards. Pro-forma invoice issued upon order confirmation.
- Step 4 — Shipment & tracking: Orders are dispatched via DHL, FedEx, or UPS Express with full tracking. Export documentation (commercial invoice, packing list) provided for customs clearance.
Why Choose Konmask.com?
- Industrial automation specialists: We focus exclusively on PLC, DCS, HMI, servo, and DAQ components — not a generalist marketplace.
- Global B2B supply: We serve systems integrators, MRO procurement teams, and OEM manufacturers across 40+ countries.
- Hard-to-find parts: We maintain stock and sourcing networks for discontinued and long-lead ADLINK products that standard distributors no longer carry.
- Technical pre-sales support: Our engineers can advise on compatibility, driver configuration, and system integration before you commit to a purchase.
- Responsive communication: Inquiries answered within 24 hours. Dedicated account managers for repeat customers.
Frequently Asked Questions
Q: Is the ADLINK PCI-9810 compatible with Windows 10 and Windows 11?
A: The PCI-9810 is officially supported under Windows 10 (32/64-bit) via ADLINK’s DAQPilot driver package. Windows 11 compatibility depends on the driver version — contact us for the latest driver availability confirmation before ordering for a Windows 11 host.
Q: Can the PCI-9810 be used in a PCIe slot?
A: No. The PCI-9810 uses the legacy 32-bit PCI bus and is not electrically or mechanically compatible with PCIe slots. If your system only has PCIe slots, consider the ADLINK PCIe-9810 or equivalent PCIe-bus DAQ card.
Q: What is the maximum number of analog input channels?
A: The PCI-9810 supports 16 single-ended channels or 8 differential channels, selectable in software. Mixed-mode (some channels SE, some differential) is not supported simultaneously.
Q: Do you supply the wiring terminal board and cable separately?
A: Yes. We can supply the ADLINK ACL-10168 terminal board and matching 68-pin SCSI cable as a bundle. Please specify this requirement in your inquiry.
Q: What is the lead time for the PCI-9810?
A: Lead time varies by stock availability. In-stock units ship within 3–5 business days. For out-of-stock situations, typical sourcing lead time is 2–4 weeks. Contact us for a real-time availability check.
Q: Can Konmask.com provide an ADLINK original warranty?
A: New units sourced through authorized channels carry the standard ADLINK warranty. For secondary-market units, Konmask.com provides a 90-day functional warranty. Warranty terms are stated explicitly on the pro-forma invoice.
