Fisher CL6824X1-A2 (12P0767X012) Analog Input Card | Replacement, Equivalent & Selection Guide
The Fisher CL6824X1-A2 (Part No. 12P0767X012) is a high-precision Analog Input Card designed for use in Fisher / Emerson DCS (Distributed Control System) platforms. Engineered for demanding industrial environments, this module delivers reliable multi-channel analog signal acquisition for process control applications in oil & gas, chemical, power generation, and manufacturing industries.
At Konmask.com, we specialize in sourcing original, tested, and certified automation components — including hard-to-find DCS cards like the CL6824X1-A2. Whether you need an exact OEM replacement or a compatible equivalent, our team provides expert selection guidance.
Technical Specifications
- Manufacturer: Fisher Controls (Emerson Electric)
- Model / Part Number: CL6824X1-A2 / 12P0767X012
- Module Type: Analog Input Card (AI)
- Signal Type: 4–20 mA / 1–5 V DC analog input
- Channels: Multi-channel analog input (typically 8 or 16 channels — confirm with datasheet)
- Resolution: 12-bit or higher A/D conversion
- Communication: Backplane bus interface (DCS rack-mounted)
- Power Supply: Supplied via DCS backplane
- Operating Temperature: 0°C to +60°C
- Dimensions: Standard DCS card form factor
- Weight: Approx. 1,210 g
- Certifications: CE, UL (verify with OEM documentation)
Compatible Replacement & Equivalent Models
If the CL6824X1-A2 is discontinued or unavailable, the following models may serve as functional equivalents or drop-in replacements (subject to system verification):
- Fisher / Emerson: CL6824X1-A1, CL6824X1-A3 (same series, different revision)
- Emerson DeltaV: MD Plus Controller AI modules (for DeltaV platform migration)
- Honeywell: MC-TAIH02 / MC-TAIH12 (Analog Input modules for TDC/Experion)
- ABB: AI810 / AI820 (S800 I/O Analog Input modules)
- Siemens: 6DS1612-8AA (TELEPERM analog input card)
- Yokogawa: AAI141-S00 (CENTUM VP Analog Input module)
⚠ Always verify electrical specifications, channel count, and backplane compatibility before substitution. Contact Konmask.com for expert cross-reference support.
Why Choose the Original CL6824X1-A2
- ✅ OEM-certified accuracy — factory-calibrated for Fisher DCS platforms
- ✅ Plug-and-play compatibility — no firmware reconfiguration required in original systems
- ✅ Proven reliability — field-tested in critical process control environments
- ✅ Full technical support — backed by Emerson’s global service network
- ✅ Long service life — designed for 24/7 continuous industrial operation
Typical Applications
- Oil & gas upstream / downstream process monitoring
- Chemical plant temperature, pressure, and flow signal acquisition
- Power plant boiler and turbine control systems
- Pharmaceutical batch process control
- Water treatment and environmental monitoring
- Pulp & paper manufacturing automation
System Compatibility
The CL6824X1-A2 is designed for integration within Fisher / Emerson DCS rack systems. Confirm compatibility with your specific:
- DCS controller model and firmware version
- Backplane / rack type (verify slot and bus interface)
- I/O configuration software version
- Field wiring termination type (screw terminal / marshalling cabinet)
Konmask.com engineers can assist with system compatibility verification — contact us before ordering if unsure.
Selection Guide
Use the following criteria to select the correct analog input card for your DCS system:
- Step 1 — Identify your DCS platform: Fisher / Emerson, Honeywell, ABB, Siemens, or Yokogawa
- Step 2 — Confirm channel count: 8-channel vs. 16-channel AI cards have different part numbers
- Step 3 — Verify signal type: 4–20 mA current loop vs. 1–5 V voltage input
- Step 4 — Check revision level: CL6824X1-A1 / A2 / A3 — confirm firmware compatibility
- Step 5 — Validate backplane slot: Ensure physical and electrical slot compatibility
- Step 6 — Source from verified supplier: Avoid counterfeit parts — purchase from Konmask.com for guaranteed authenticity
Quality Assurance & Sourcing
All modules sold by Konmask.com undergo a rigorous quality process:
- 🔍 Visual inspection — PCB, connectors, and labeling verified
- ⚡ Power-on functional test — signal I/O verified before shipment
- 📦 Anti-static packaging — ESD-safe bags and foam-lined boxes
- 📋 Traceability documentation — batch records and test reports available on request
- 🌐 Global sourcing network — original OEM stock and certified refurbished units
How to Order
- Add the Fisher CL6824X1-A2 (12P0767X012) to your cart
- Or contact us directly for bulk orders, urgent requirements, or cross-reference inquiries
- Provide your DCS system model for compatibility confirmation if needed
- Receive a quotation within 24 hours for non-stock items
📧 Email: support@konmask.com
📞 Phone / WhatsApp: +0086 19859288691
🌐 Website: https://konmask.com
Replacement & Compatibility FAQ
Q: Is the CL6824X1-A2 still in production?
A: This model may be discontinued by Emerson. Konmask.com maintains stock of original and certified refurbished units. Contact us for availability.
Q: Can I use CL6824X1-A1 instead of CL6824X1-A2?
A: Revision A1 and A2 are typically hardware-compatible but may have firmware differences. Verify with your DCS configuration engineer before substitution.
Q: What is the part number 12P0767X012?
A: 12P0767X012 is the Fisher / Emerson OEM part number for the CL6824X1-A2 Analog Input Card. Both numbers refer to the same module.
Q: Do you provide a warranty?
A: Yes. Konmask.com offers a 90-day functional warranty on all tested modules. Extended warranty available on request.
Q: Can you ship internationally?
A: Yes. We ship worldwide with DHL, FedEx, and UPS express options. Export documentation provided for customs clearance.
