Allen-Bradley 1336-BDB-SP29A Main Drive Board – 1336 PLUS AC Drive Series
When the main drive board inside an Allen-Bradley 1336 PLUS AC drive fails, the impact on the production floor is immediate and severe. Variable-frequency motor control is lost in an instant — conveyor systems stop, pump stations lose flow regulation, compressor drives trip offline, and process lines dependent on precise speed control go into uncontrolled shutdown. Without a verified replacement board on hand, maintenance teams face extended downtime, emergency sourcing delays, and the cascading costs of halted production. The Allen-Bradley 1336-BDB-SP29A (P/N 74101-169-53) Main Drive Board is the core power-switching intelligence of the 1336 PLUS drive, and restoring operation depends entirely on sourcing the correct, compatible replacement without delay.
The 1336 PLUS series — Rockwell Automation’s widely deployed general-purpose AC drive platform — has accumulated a massive global installed base across manufacturing, infrastructure, and process industries. Within this family, the 1336-BDB-SP29A serves as the main drive board (MDB), responsible for gate-drive signal generation, IGBT switching control, DC bus interface, and power stage protection logic. The suffix SP29A identifies a specific hardware and firmware revision that must be matched to the corresponding power structure and control board assembly. This board is an essential MRO spare for any facility maintaining 1336 PLUS drives in continuous operation.
Technical Specifications
- Manufacturer: Allen-Bradley / Rockwell Automation
- Part Number: 1336-BDB-SP29A
- Reference P/N: 74101-169-53
- Board Type: Main Drive Board (MDB)
- Compatible Drive Series: 1336 PLUS (1336)
- Function: Gate-drive signal generation, IGBT switching control, DC bus interface, power stage protection
- Weight: 1,240 g (approx.)
- Condition: New / Surplus / Refurbished (specify at inquiry)
Note: Specifications are based on published Allen-Bradley documentation. Always verify drive frame revision and power structure compatibility before installation.
Key Features & Benefits
- Direct OEM Replacement: Engineered as a drop-in replacement for 1336 PLUS drives — matched to the SP29A hardware revision for seamless integration with existing power structures.
- IGBT Gate Drive Control: Manages precision switching of the inverter IGBT bridge, ensuring accurate PWM output and motor voltage waveform quality.
- DC Bus Interface & Protection: Monitors DC bus voltage levels and interfaces with precharge and braking circuits to protect the drive during transient conditions.
- Power Stage Fault Detection: Onboard protection logic detects overcurrent, overvoltage, and short-circuit conditions, triggering fault codes for rapid diagnosis.
- Revision-Specific Compatibility: The SP29A designation ensures hardware and firmware alignment with matched control boards and power structures in the 1336 PLUS frame.
- Dual Part Number Traceability: Cross-referenced by catalog number (1336-BDB-SP29A) and internal P/N (74101-169-53) for MRO procurement and audit compliance.
Industry & Equipment Applications
- Manufacturing & Assembly: Conveyor drives, machine tool spindles, and automated assembly line motors controlled by 1336 PLUS VFDs.
- Water & Wastewater: Pump and blower drives in municipal treatment facilities where continuous uptime is a regulatory and operational requirement.
- Oil & Gas: Compressor and fan drive control in upstream and midstream facilities with 1336 PLUS installed base.
- HVAC & Building Automation: Chiller pump drives, cooling tower fans, and air handling units using 1336 PLUS for variable-speed energy management.
- Pulp, Paper & Metals: High-inertia load applications requiring robust power stage control and fault-tolerant drive operation.
- Food & Beverage: Mixer, conveyor, and packaging line drives where precise speed regulation and rapid fault recovery are essential.
System Integration & Compatible Parts
The 1336-BDB-SP29A operates within the modular architecture of the Allen-Bradley 1336 PLUS drive. Common companion components include:
- 1336 PLUS Power Structures (frame-size matched to SP29A revision)
- 1336-MCB Main Control Boards (matched firmware revision)
- 1336-L4E / 1336-L6E I/O Expansion Boards
- 1336-BRF / 1336-BRB Dynamic Braking Modules
- 1336-PB / 1336-PBK Precharge Boards
- 20-COMM-E / 20-COMM-D Communication Adapters (DPI-compatible)
Always verify drive catalog number, frame size, and firmware revision compatibility before installation. Contact our technical team for cross-reference and compatibility support.
Our Quality Assurance Process
At Konmask.com, every Allen-Bradley drive board undergoes a structured verification process before shipment:
- Visual Inspection: PCB examined for physical damage, corrosion, burnt components, and solder joint integrity.
- Part Number Verification: Catalog number and internal P/N cross-checked against Rockwell Automation documentation.
- Functional Test (where applicable): Boards sourced as tested-good are bench-verified on compatible drive test rigs.
- ESD-Safe Packaging: All boards shipped in anti-static bags with foam cushioning to prevent transit damage.
- Documentation: Test reports and condition certificates available upon request for MRO and audit compliance.
How to Order
Konmask.com operates as a B2B inquiry-based platform. To request a quote for the 1336-BDB-SP29A:
- Submit your inquiry via the Contact / RFQ form on this page.
- Include your required quantity, preferred condition (new, surplus, or refurbished), and any urgency requirements.
- Our sourcing team will respond within 1 business day with availability, lead time, and pricing.
- Upon agreement, we issue a proforma invoice and arrange secure international shipping with full tracking.
For urgent requirements, contact us directly at support@konmask.com or +0086 19859288691.
Why Choose Konmask.com?
- Specialized Industrial Focus: We source exclusively in the industrial automation and control systems space — Allen-Bradley, Siemens, ABB, Schneider, and more.
- Global Sourcing Network: Access to surplus, new-in-box, and refurbished inventory across verified international suppliers.
- Technical Expertise: Our team includes engineers with hands-on experience in PLC, VFD, and DCS systems — not just sales staff.
- Fast Response: RFQ responses within 1 business day; expedited sourcing available for critical downtime situations.
- Secure Transactions: Proforma invoice, bank transfer, and escrow payment options for international B2B buyers.
- Export Compliance: Experienced in cross-border documentation, commercial invoices, and customs requirements for industrial components.
Frequently Asked Questions
Q: Is the 1336-BDB-SP29A compatible with all 1336 PLUS drive frames?
A: The SP29A revision is specific to certain 1336 PLUS frame configurations. Compatibility depends on your drive’s full catalog number, frame size, and existing firmware revision. Please provide your complete drive catalog number when submitting an inquiry so we can confirm compatibility before shipment.
Q: What is the difference between a new, surplus, and refurbished board?
A: New boards are unused OEM stock. Surplus boards are new-in-box but may have been stored for extended periods. Refurbished boards have been inspected, repaired if necessary, and tested to OEM specifications. All conditions are clearly disclosed at the time of quotation.
Q: Can you ship the 1336-BDB-SP29A internationally?
A: Yes. Konmask.com ships globally via DHL, FedEx, and UPS with full export documentation. Lead times and shipping costs are confirmed at the quotation stage.
Q: Do you offer a warranty on this drive board?
A: Warranty terms vary by condition and sourcing channel. Tested-good and refurbished units typically carry a 90-day functional warranty. Details are specified in the proforma invoice.
Q: How can I tell if my 1336 PLUS drive needs a new main drive board?
A: Common indicators include persistent power stage fault codes that do not clear after power cycling, IGBT switching errors, DC bus voltage irregularities, or visible damage to the drive board PCB. Our technical team can assist with remote fault diagnosis and part identification.
