Industrial Safety Automation Solution – Allen-Bradley 1756-L83ES | ControlLogix 5580 Series
Where This Product Is Used
The Allen-Bradley 1756-L83ES Enhanced ControlLogix Safety Controller is purpose-built for mission-critical industrial environments where functional safety and high-speed process control must coexist on a single platform. Typical deployment scenarios include:
- Oil & Gas Processing Plants – Emergency Shutdown Systems (ESD) and Safety Instrumented Systems (SIS) on wellheads, pipelines, and refineries requiring SIL 2 certification.
- Automotive Manufacturing – Robotic welding cells, press lines, and assembly conveyors where machine safety (PLe/Cat.4) and motion coordination run simultaneously.
- Chemical & Pharmaceutical Plants – Batch process control with integrated safety interlocks, compliant with IEC 61511 and FDA 21 CFR Part 11 environments.
- Power Generation & Utilities – Turbine control, boiler management, and substation automation requiring high-availability redundancy.
- Mining & Metals – Conveyor safety, crusher control, and smelter process management with harsh-environment resilience.
- Water & Wastewater Treatment – SCADA-integrated pump station control with safety-rated I/O for chemical dosing systems.
Technical Specifications
| Attribute | Value |
|---|---|
| Catalog Number | 1756-L83ES |
| Series | ControlLogix 5580 |
| Controller Type | Enhanced Safety (ES) |
| User Memory | 40 MB |
| I/O Capacity | Up to 128,000 I/O points |
| Safety Rating | SIL 2 (IEC 61508), PLe / Cat. 4 (ISO 13849) |
| Communication | EtherNet/IP (dual-port), CIP Safety, ControlNet, DeviceNet |
| Backplane Speed | High-speed ControlLogix backplane |
| Programming Software | Studio 5000 Logix Designer v32+ |
| Languages Supported | Ladder Diagram, Function Block, Structured Text, Sequential Function Chart |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% non-condensing |
| Power Consumption | Refer to 1756-SG001 selection guide |
| Weight | Approx. 400 g |
| Certifications | UL, CE, cUL, TÜV, ATEX (Zone 2) |
| Form Factor | ControlLogix chassis-mount module |
Why Engineers Specify This Model
The 1756-L83ES is the preferred choice for engineers who need to consolidate standard process control and functional safety into a single controller chassis — eliminating the cost and complexity of a separate safety PLC:
- Integrated Safety Architecture – Runs standard and safety tasks concurrently on one processor, reducing panel footprint and wiring costs by up to 30%.
- 40 MB User Memory – Supports large, complex programs with extensive Add-On Instructions (AOIs), HMI data tables, and historian tag sets without performance degradation.
- CIP Safety over EtherNet/IP – Enables safety-rated communication across the plant network without dedicated safety fieldbus wiring.
- Scalable I/O Expansion – Compatible with the full 1756 I/O module library including 1756-IB16S, 1756-OB16S safety I/O modules.
- Seamless Rockwell Ecosystem – Native integration with FactoryTalk View, FactoryTalk Historian, and Plex MES for unified data visibility.
- Firmware Revision Management – Supports ControlFLASH Plus for remote firmware updates, minimizing planned downtime.
Complete System Bill of Materials
A typical 1756-L83ES safety control panel includes the following components:
- 1756-L83ES – Enhanced ControlLogix Safety Controller (this item)
- 1756-A10 or 1756-A17 – ControlLogix 10- or 17-slot chassis
- 1756-PA75 or 1756-PB75 – AC or DC power supply module
- 1756-EN2T or 1756-EN2TR – EtherNet/IP communication module (standard or ring topology)
- 1756-IB16S – 16-point 24V DC safety digital input module
- 1756-OB16S – 16-point 24V DC safety digital output module
- 1756-IF16S – 16-channel safety analog input module (optional)
- 1784-SD2 – SD card for program backup and restore
- Studio 5000 Logix Designer License – v32 or higher required
Compliance & Industry Standards
- IEC 61508 – Functional Safety of E/E/PE Safety-related Systems (SIL 2)
- IEC 61511 – Functional Safety for the Process Industry Sector
- ISO 13849-1 – Safety of Machinery: PLe / Category 4
- IEC 62061 – Safety of Machinery: SILCL 2
- UL 508 – Industrial Control Equipment
- CE Marking – EMC Directive 2014/30/EU & Low Voltage Directive 2014/35/EU
- ATEX / IECEx – Zone 2 hazardous area classification
- RoHS Compliant – Restriction of Hazardous Substances Directive
Quality Assurance & Sourcing
At Konmask.com, every Allen-Bradley 1756-L83ES unit is subject to a rigorous multi-point verification process before shipment:
- ✅ Authenticity Verification – Each unit is inspected for genuine Rockwell Automation labeling, holographic seals, and date codes consistent with factory production records.
- ✅ Functional Pre-Test – Power-on test performed to confirm firmware version, LED status, and backplane communication integrity.
- ✅ Anti-Static Packaging – Shipped in ESD-safe bags with foam cushioning inside double-wall corrugated cartons.
- ✅ Traceability Documentation – Certificate of conformance and inspection report available upon request.
- ✅ Warranty – 12-month replacement warranty against manufacturing defects.
How to Source This Part
Ordering the Allen-Bradley 1756-L83ES from Konmask.com is straightforward:
- Step 1 – Add to cart and complete checkout, or contact us directly for volume pricing and lead time confirmation.
- Step 2 – Provide your project PO number and required delivery date. We will confirm stock availability within 24 hours.
- Step 3 – Choose your preferred freight method: DHL Express, FedEx International Priority, or sea freight for bulk orders.
- Step 4 – Receive your shipment with full tracking, commercial invoice, and packing list for customs clearance.
For urgent requirements, same-day dispatch is available for in-stock units ordered before 14:00 CST. Contact our technical sales team for expedited support.
Application-Specific FAQ
Q: Can the 1756-L83ES run both standard and safety tasks simultaneously?
A: Yes. The Enhanced Safety (ES) architecture allows standard control tasks and safety tasks to execute concurrently on the same processor, with hardware-enforced separation to maintain SIL 2 integrity.
Q: What is the maximum safety task period for SIL 2 compliance?
A: The safety task period must be configured per your SIL 2 verification calculation. Rockwell Automation’s SISTEMA library files are available to support your safety lifecycle documentation.
Q: Is the 1756-L83ES backward compatible with older 1756-L7x series programs?
A: Programs written for 1756-L7x controllers can be migrated to the 1756-L83ES using Studio 5000 Logix Designer’s import/export tools, though firmware and AOI compatibility should be verified prior to migration.
Q: Does this controller support ProfiSafe or PROFInet?
A: The 1756-L83ES natively supports CIP Safety over EtherNet/IP. PROFInet/ProfiSafe integration requires a third-party gateway module.
Q: What Studio 5000 version is required?
A: Studio 5000 Logix Designer version 32.00 or higher is required to program and configure the 1756-L83ES.
